NETGEAR GS205 Manual de usuario

Optional

modem

Step 1. Position switch

Step 3. Connect power

Step 4. Check status

Step 2. Connect equipment

GS208

5-Port and 8-Port Gigabit Switches GS205/GS208

Optional router

Internet

Computer Server

On

Off

Power LED

Activity (blinking)

No link (off)

Ethernet link

Port LEDs

Installation Guide

Technical Support

Thank you for selecting NETGEAR products.

After installing your device, locate the serial number on the label

of your product and use it to register your product at

https://my.netgear.com.

You must register your product before you can use NETGEAR

telephone support. NETGEAR recommends registering your

product through the NETGEAR website. For product updates

and web support, visit http://support.netgear.com.

NETGEAR recommends that you use only the official NETGEAR

support resources.

Specifications Description

Network interface RJ-45 connectorfor10BASE-T,100BASE-TX,or

1000BASE-T

Network cable Category 5 (Cat 5) or better Ethernet cable

Ports GS205: 5

GS208: 8

Power adapter 12V @ 1.0A DC input

Power consumption GS205: 3.56W

GS208: 3.64W

Weight GS205: 0.12 Kg (0.27 lbs)

GS208: 0.19 Kg (0.43 lbs)

Dimensions

(W x D x H) GS205: 114 mm x 86 mm x 26 mm

(4.49 in. x 3.39 in. x 1.02 in.)

GS208: 152 mm x 93 mm x 26 mm

(5.98 in. x 3.66 in. x 1.02 in.)

Operating temperature 0°–40° C (32°–104° F)

Operating humidity 10%-90% relative humidity, noncondensing

Certifications CE mark, CB, CE Class B, C-Tick Class B

January 2013

For the current EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or

registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States

and/or other countries. Information is subject to change without notice. Other brand

and product names are registered trademarks or trademarks of their respective

holders. © NETGEAR, Inc. All rights reserved.

Intended for indoor use only in all EU member states, EFTA states, and Switzerland.
