NETGEAR™ProSafe VPN Client

Release Notes

Version: 10.1.1, build 10 Release Notes Issued on: 09/29/2003

Product Description

The NETGEAR ProSafe VPN Client is a virtual private network (VPN) client for

remote access and secure communications.

New Features and Enhancements

• Smart card removal clears keys option

• Phoenix Device-Connection Authentication support

• WAN maximum transmission unit (MTU) adjust settings for Windows 2000

and XP to better integrate running the client over DSL lines using Point-to-Point

Protocol over Ethernet (PPPoE)

Component Versions

Component Version

CSP Library (FIPS) 3.1.0b22

CSP Library (Non-FIPS) 3.0.1b22

Deterministic Networks (DNE) shim 2.20

Layer 2 Tunneling Protocol (L2TP) 4.29

Security Policy Editor 1.2.1 B10

Certificate Manager 1.2.1 B10

Phoenix Device-Connection Authentication CryptoOSD 1.2.3.2

Before Installing or Upgrading to This Version

When upgrading from an earlier version of the VPN client, take these required steps

before installing the client:

1. Uninstall the existing version through the Control Panel Add/Remove

Programs application.

2. Reboot your computer.

Note: The original Windows installation files may be required during installation,

depending on the specific version of Windows and your configuration. Make sure that

you have the CD-ROMs or files available before you start the installation.

Release Notes

Windows Compatibility

Supported Windows Version

95: versions 4.00.950 B and C Me

98 and 98 SE 2000 Professional

NT 4.0 Workstation: SP 5 and 6 XP Home and Professional

Unsupported Windows Versions (Not Y2K-Compliant)

95, versions 4.00.950 and 950a

NT 4.0, SP 3

Install the latest Windows service pack, dial-up networking

upgrade, and Internet Explorer version.

Network Interface Cards

This version should be compatible with all NDIS-compliant Ethernet network

interface cards (NICs). Plug and play is supported on Windows 95, 98, Me, and 2000

only. Plug and play is not supported on notebook computers running Windows NT.

Compatibility Issues

• Windows XP Internet Connection Firewall with the SafeNet Virtual Adapter

The SafeNet Virtual Adapter must be “firewalled” with the Windows XP

Internet Connection Firewall if the connection used to create VA is Windows

XP “firewalled”; otherwise, packets will not pass.

• Driver signing warnings on Windows XP with Security Patch MS02-50

Description: Earlier versions of the MS02-50 Security Patch on Windows XP

caused unsigned driver messages when installing the client.

Workaround: Download the latest MS02-50 Patch from this page on the

Microsoft web site:

http://www.microsoft.com/technet/treeview/default.asp?url=/technet/securit

y/bullet in/MS02-050.asp

If the patch is no longer on this page, search for this patch on the Microsoft

support web site, support.microsoft.com.

• Nortel Contivity VPN Switch

Description: The elements of the distinguished name sent by the switch are

not in the standard order expected by the client. When entering the

distinguished name in the Connect using Nortel Contivity VPN Switch group,

select the Enter Subject Name in LDAP Format check box. Make sure

that the order of the elements matches the order from the switch, for

example:

LDAP Format

Certificate

Information

CN Name

S State

C City

OU Department

O Company

Workaround: The Nortel switch's firmware version 3.5 or later,

with Keep Alives disabled is required. If a message regarding

invalid hash length appears in the Log View, this means that the

keep alive feature is enabled. The Keep Alives option is controlled

through the IPSec section of the Group profile. The menu item in

IPSec is called Enable Client Failover Tuning.

• PPPoE software for DSL connections must be installed

and operational before the client is installed.

Description: Installing PPPoE software on a computer that the

client is already on removes some network components.

Workaround: If the computer doesn’t have the client installed,

install the PPPoE install the PPPoE software before you install the

client. If the client is already installed, uninstall, and save the

IPSec policy when prompted during the uninstall. After your

computer reboots, install the PPPoE software, and then install the

client again.

• Compatibility issue with 3Com Smart Agent software

Description: If the 3Com Smart Agent software is installed before

the client in

installed, the client doesn’t operate correctly.

Workaround: Install the Smart Agent software before installing

the client

• Errors when the gateway sends certificates with more

than 1024 bits to a client without the Microsoft Enhanced

CSP

Description: Log Viewer errors and connection failures occur on

the client when the gateway sends certificates larger than 1024 bits

on computers that don’t have a 128bit version of Internet Explorer

installed. Log errors can’t acquire enhanced provider verify context,

and signature verification fails.

Workaround: For gateways that send certificates larger than 1024

bits to the client, upgrade to the 128-bit version of Internet

Explorer, which include the Microsoft Enhanced CSP.

• Automatic certificate selection may not work in Aggressive

Mode.

Description: Because Aggressive Mode sends an ID payload in the

first initiator packet, and no explicit certificate is selected, the

session may fail. The client make a best guess, and selects the first

certificate that meets the specified ID type, such as DN, email, or

IP address. This certificate, however, may not be a valid

certificate.

Workaround: Manually select the certificate when using

Aggressive Mode, or limit your certificates to one in the

Certificate Manager.

• Compatibility issues with EarthLink software

Description: The client is incompatibility with EarthLink Internet

software, version 5.02.

Workaround: EarthLink can still be accessed through a standard

dial-up networking configuration. Uninstall the EarthLink software.

EarthLink Technical Support is aware of the situation; contact

EarthLink for help in setting up a standard dial-up configuration for

EarthLink access.

• Compatibility issues with Sony Vaio and 3COM 3CCFE575CT

CardBus PC Card

Description: The 3COM 3CXFE575CT 10/100 LAN CardBus PC

Card isn’t compatible with Sony Vaio notebook computers; after

the client is installed, the computer requires an Ethernet cable to

be attached to boot. This NIC card works fine in other computers..

Workaround: Use hardware profiles to disable the NIC card, or

remove the NIC card when the computer isn’t attached to the

network.

• On Windows 95/98/Me, the Entrega USB has problems with

suspend/standby.

Description: The Entrega USB has problems when returning from

suspend mode in that the interface is not always present.

Workaround: Unplug the adapter, and then plug it back in.

• AOL 6.0 Compatibility

Description: AOL 6.0 software has installation problems on

Windows 95/98/SE/Me system with DNE. The AOL installation

continuously reinstalls TCP/IP and asks to be restarted.

Workarounds: Try one of these:

 Boot into safe mode, remove DNE, and continue with the AOL

install. After AOL is

installed, reinstall DNE. AOL will still ask to be restarted on every

startup; click

No, and AOL work just fine.

 Upgrade to AOL 7.0. On Windows XP using native XP PPPoE

connections, if an AOL 7.0 upgrade is performed on the client is

installed, repair the client. This will correct the PPPoE settings

that AOL overwrites.

• RequestLocalAddress failure and dialup interfaces are not

detected properly in the Log Viewer on clients that also have

the Nortel client installed and DN is bound to the Nortel

IPSECSHM

Description: Cannot connect using Windows 2000 and XP RAS

connections when DN is bound to the Nortel IPSECSHM.

Workaround: In the Windows Device Manager, if the IPSECSHM -

Deterministic Network Enhancer Miniport is disabled, the dialup interface

will be detected properly and sessions will establish.

Addressed Issues

Priority Classification Definition

C Critical No reasonable workaround exists

H High Reasonable workaround exists

M Medium Medium level priority problems

I Inconvenient Lowest level priority problems

E Enhancement New or changed feature request

In Version 1.2.1 (Build 10)

Issue # Priority Synopsis

QA004745

H Client doesn't guard for NAT-D payload overflow.

QA004746

H Client doesn't guard against buffer overflow in HASH_R

processing.

QA004747

H Client doesn't guard against attribute payload overflow.

QA004748

H Client packet log may contain extraneous characters.

QA004749

L Client pop-up menu may be missing lower Manual Connection

separator.

QA004750

M Client doesn't handle mode config collisions correctly on

Windows XP.

QA004751

L Multiple quick modes during VA session with WINS configuration

QA004752

M MTU settings can result in packet loss. Introduced WAN MTU

adjust settings for all NT platforms.

QA018746

L On Windows NT, the VA connectoid may be created with PPTP

Port Spec.

In Version 1.2.0 (Build 32)

Issue # Priority Synopsis

4005 E Add mechanism to prevent the creation of duplicate connection

names.

4103 H Cannot enter and save PSK on Windows XP; error encrypting

PSK.

4161 E Add inventorying interfaces process after VA hang up to

eliminate residual active VA adapters with no SA.

4162 E Maintain VA while processing Initial Contact and in responder

mode.

4170 M In remote party ID, with Connect using checked, the wrong

default ID types are listed.

4173 H TDES and DES with Manual Keys fail with all hash alg. "Error

importing outbound key entry"

4556 H RGW connections are not recognized in manual connections.

4667 H Clients using VRS (Internal IP) with no VA cannot pass

fragmented UDP traffic.

4668 H NSladapssl32v30.dll included with client is not compatible with

Sun or IPlanet 5.1 or later.

4676 H Interface detection failure on RAS devices introduced after

reboot.

4677 H Quick Mode starting before Extended Authentication completes.

4678 H Multiple XAUTH prompts are presented to user when XAUTH is

not completed.

4679 H CA certs imported into the personal cert store with IE cause Cert

Mgr crash when opening the personal (CA) cert.

4704 H Windows 2000 and XP Net Login Error 5719 in event viewer

causes single sign-on applications to fail. Modified to defer RAS

loading until either a point-to-point interface is detected or VA

activation is required.

4705 H Secure All types of manual connections to 2nd or 3rd connection

tries to establish a connection to the 1st connection. Modified

manual initiation processing to avoid initiating inappropriate

connection for multiple Secure All configurations.

4721 H RSA Secure-ID Passcode is truncated for Secure-ID.

4733 H Windows 2000 and XP DNE MTU Adjust doesn't accommodate

enough overhead for all connection types.

In Version 1.1.1 (Build 14)

Issue # Priority Synopsis

4858 H Double and Triple XAUTH prompt occurs on connections that

failover to a RGW.

4892 H Enternet PPPoE client doesn't work with client when using the

virtual adaptor, non VA connections work as expected.

5183 H Unable to release and renew IP addresses or renewals of DHCP

leases fail with the firewall build.

5221 H VPN.exe causes fatal application error when running vpn.bat

from a command prompt.

5367 H Auto-retrieval of MSCEP certificate does not work

5419 H SPDedit Gateway IP address box remains enabled after un-

checking Connect Using box

5454 H SpdEdit incorrectly chooses 1st cert with same label,

regardless of container ID

5458 H IPSecMon crashes when retrieving policy or certificate

5435 I VA settings are not retained when moving within various

screens in the policy editor without saving first.

5437 I Secure All and Secure Other Connections display the manual

connect option when first selected or clicking the Secure radio

button.

5438 I Ghost Save and RGW buttons after importing an unlocked

policy over a locked policy; unable to save any changes or add

RGW.

5443 I SPDedit Other Connections ID type set to Any Gateway IP

Address remains enabled after clearing the Connect Using

check box

5457 I Client loads wrong spi when AH and ESP proposed in the same

policy

Known Issues

Priority Classification Definition

C Critical No reasonable workaround

exists

H High Reasonable workaround exists

M Medium Medium level priority problems

I Inconvenient Lowest level priority problems

This is a list of the issues known at time of release:

All Open Issues are prioritized and addressed in future releases when possible.

Known issues listed in the previous release note in the Known Issues section are still

present in this release unless listed in the Addressed Issues section.

Issue# Priority Synopsis

QA018812 Windows XP log-off causes intermittent ifcfg.exe Application

error.

I Description: When logging off of Windows XP, you may

intermittently receive ifcfg.exe application error.

Workaround: Disregard this error, the log-off will complete as

expected.

4506 I Can't specify an interface and use the Virtual Adapter

Description: If the Internet Interface in the MY ID section of a

connection is set to something other than Any, a VA

connections will fail with the following errors: • 15:26:52.998

Failure finding or creating filter entry • 15:26:53.008 Failure

finding or creating filter entry • 15:26:53.008 Key download

failed. • 15:26:53.008 Error downloading key. •

15:26:53.008 Failed loading the keys Workaround: Set the

Internet Interface for the effective connection to Any or set VA

to disabled.

Issue# Priority

Synopsis

4606 M Windows XP "Digital signature not found" for crypto OSD

adapter during install. Description: Selected option to install

Device Connect Authentication and Remote Upgrade for install

of client. During install on Windows 2000 received "Digital

Signature not Found" for Crypto OSD Adapter. Workaround:

Select OK to continue past message, and install will complete

successfully.

4657 H SCEP Request to SMC CA with an underscore in the common

name causes the CN to be corrupt. Description: SCEP request

to SMC in the clear causes with an underscore in the CN causes

the Common Name to be corrupt after retrieval. The Common

Name retrieved is a # sign followed by a long numeric string.

Workaround: Only use numeric and alphanumeric characters

for the CN during SCEP request.

4687 I Windows 9x: Dial-up VA Required sessions complete even

when VA isn't created Description: When attempting a dial-up

VA session with only one dial-up adapter present on the

machine (i.e., improper configuration), the IPSec SA completes

even though the VA adapter is not added. The log shows a

virtual interface constructed but no message for virtual adapter

added. Workaround: Verify that two dial-up adapters are

present on the machine before attempting dial-up VA sessions.

4933 H Unable to Map drives on Windows NT with Enternet 1.5 PPPoE

software over a secure connection. Description: System

hangs when trying to map a drive over a secure PPPoE

connection and may require a system restart. Workaround:

The client will Map drives using RASPPPoE software. Get this

from this free download link: http://user.cs.tu-

berlin.de/~normanb/#Download

5317 H Manual connect fails when connecting to a subnet via a

gateway set to Hostname or an RGW on Windows 9X.

Description: Manual connect on Windows 9x platforms to a

remote subnet (or range) specified with an address, which is

apparently (by address class) a subnet address, will report a

RequestLocalAddress failure. This is because Windows 9X will

not generate traffic to such addresses. Workaround: Initiate

traffic to establish the tunnel such as a ping, web, email, or

FTP traffic.

Otros manuales para VPN

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de NETGEAR

NETGEAR

NETGEAR GS108Tv2 - ProSafe Gigabit Smart Switch Coming... Manual de usuario

NETGEAR

NETGEAR EVA9100 - Digital Entertainer Express Instrucciones de montaje

NETGEAR

NETGEAR ProSafe VPN01L Manual de usuario

NETGEAR

NETGEAR NMS100 - ProSafe Network Management Software Manual de usuario

NETGEAR

NETGEAR GS105E-100NAS - Prosafe Plus 5PORT Manual de usuario

NETGEAR

NETGEAR GS700AT Series Manual de instrucciones

NETGEAR

NETGEAR 7200 Series Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario
