NETGEAR GSS108E Manual

Hardware Installation Guide

8-Port and 16-Port Gigabit Ethernet

(PoE+) Smart Managed Plus Click Switch

Models

GSS108E

GSS116E

GSS108EPP

NETGEAR, Inc.

350 E. Plumeria DriveJanuary 2019

San Jose, CA 95134, USA202-11712-04

Support

Thank you for purchasing this NETGEAR product. You can visit

https://www.netgear.com/support/ to register your product, get help, access the latest

downloads and user manuals, and join our community. We recommend that you use

only official NETGEAR support resources.

Compliance and Conformity

For regulatory compliance information including the EU Declaration of Conformity, visit

https://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Do not use this device outdoors. If you connect cables or devices that are outdoors to

this device, see http://kb.netgear.com/000057103 for safety and warranty information.

Trademarks

Any non-NETGEAR trademarks are used for reference purposes only.

Revision History

CommentsPublish DatePublication Part

Number

•Reorganized the entire guide and published it in a new format.

•Updated the product names.

•Removed information about the resource CD.

•Revised the information in all existing chapters and sections.

•Added in Chapter 1: Overview on page 6.

•Added in Chapter 2: Factory Defaults button on page 18.

•Added in Chapter 3: Network switching on page 20.

•Added in Chapter 4: Step 1: Prepare the site on page 27, Step 2: Protect

against electrostatic discharge on page 28, Step 5: Connect devices to the

switch on page 34, Step 6: Check the installation on page 34, and Step 9:

Manage the switch on page 36.

•Added in chapter 5: PoE troubleshooting suggestions (model GSS108EPP)

on page 39.

January 2019202-11712-04

Made adjustments to illustrations with the new bracket design.April 2017202-11712-03

•Updated illustrations with the new bracket design.

•Made some editorial changes.

March 2017202-11712-02

First publication.October 2016202-11712-01

8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch

Contents

Chapter 1 Introduction

Overview................................................................................................6

Features.................................................................................................7

Safety instructions and warnings........................................................9

Chapter 2 Hardware Overview

Model GSS108E hardware................................................................13

Front panel model GSS108E........................................................13

Status LEDs model GSS108E........................................................13

Back panel model GSS108E.........................................................14

Model GSS116E hardware................................................................14

Front panel model GSS116E........................................................14

Status LEDs model GSS116E........................................................15

Back panel model GSS116E.........................................................15

Model GSS108EPP hardware............................................................16

Front panel model GSS108EPP....................................................16

Status LEDs model GSS108EPP...................................................16

Back panel model GSS108EPP.....................................................17

Switch hardware interfaces...............................................................17

RJ-45 ports for 10/100/1000M BASE-T Ethernet connectivity..17

USB charging ports (model GSS108E)........................................18

Factory Defaults button.................................................................18

Chapter 3 Applications

Network switching..............................................................................20

Static LAG connections (models GSS116E and GSS108EPP).......20

PoE applications (model GSS108EPP).............................................21

PoE overview (model GSS108EPP)..............................................21

Connect PoE equipment in a home (model GSS108EPP)........22

Connect PoE equipment in a business environment (model

GSS108EPP)....................................................................................23

Use the USB charging ports (model GSS108E)..............................24

Chapter 4 Installation

Step 1: Prepare the site......................................................................27

Step 2: Protect against electrostatic discharge..............................28

Step 3: Unpack the switch.................................................................28

Step 4: Install the switch....................................................................29

Mount the switch to a wall stud or to a solid surface.................29

Mount the switch to a drywall.......................................................31

Attach the switch to a pole or table leg......................................32

Step 5: Connect devices to the switch.............................................34

Step 6: Check the installation...........................................................34

Step 7: Apply power and check the LEDs.......................................34

Step 8: Use the straps for cable retention.......................................35

Step 9: Manage the switch................................................................36

Chapter 5 Troubleshooting

Troubleshooting chart.......................................................................38

PoE troubleshooting suggestions (model GSS108EPP)................39

Additional troubleshooting suggestions.........................................39

8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch

Introduction

The NETGEAR Smart Managed Plus Click Switches use the 1-2-3-4 Click Mounting

system, which lets you easily mount the switch vertically or horizontally on a wall, pole,

or table leg. The internal power supply allows for a simple power cord from the switch

to an outlet. The switches are fanless for silent operation and you can turn off the LEDs

to minimize distractions.

This hardware installation guide is for the following switch models:

•GSS108E. 8-Port Gigabit Ethernet Smart Managed Plus Click Switch.

•GSS116E. 16-Port Gigabit Ethernet Smart Managed Plus Click Switch.

•GSS108EPP. 8-Port Gigabit Ethernet Smart Managed Plus Click Switch with

4-Port PoE+.

This hardware installation guide complements the installation guide that came with your

switch.

This chapter serves as an introduction to the switch and includes the following sections:

• Overview

• Features

• Safety instructions and warnings

Note: For more information about the topics that are covered in this manual, visit the

support website at netgear.com/support/.

Note: For technical specifications, see the data sheet at

netgear.com/business/products/switches/web-managed/. For switch documentation,

visit netgear.com/support/download/.

Overview

The switch provides eight or sixteen 10/100/1000BASE-T RJ-45 copper ports that support

nonstop 10/100/1000M Layer 2 networks. On model GSS108EPP, RJ-45 ports 1-4

support PoE+ with a total PoE power budget of 47W for the switch.

For information about application samples, see Applications on page 19.

The switch provides administrative management options that let you configure, monitor,

and control the network. Using the local browser–based management interface, in this

guide referred to as the local browser interface, you can configure the switch and the

network, including the ports, VLANs for traffic control, link aggregation (on models

GSS116E and GSS108EPP) for increased bandwidth, and Quality of Service (QoS) for

prioritizing traffic.

For initial discovery of the switch on the network, use one of the following methods, all

of which are described in detail in the user manual:

•NETGEAR Insight mobile app

•NETGEAR Switch Discovery Tool

•NETGEAR ProSAFE Plus Utility

You can also get the IP address of the switch from the DHCP server in the network or

use an IP scanner utility.

After discovery, you can configure the switch using the local browser interface for

advanced setup and configuration of features, or the NETGEAR ProSAFE Plus Utility for

configuration of most features. For more information, see the user manual, which you

can download from netgear.com/support/download/.

The switch is IEEE compliant and offers low latency. All ports can automatically negotiate

to the highest speed, which makes the switch very suitable for a mixed environment

with Fast Ethernet and Gigabit Ethernet.

Use Category 5e (Cat 5e) or higher-rated Ethernet cables terminated with RJ-45

connectors to make Gigabit connections.

Hardware Installation Guide6Introduction

8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch

Features

The switch supports the following key hardware features:

•8 or 16 Gigabit Ethernet ports.

•PoE+ support on model GSS108EPP:

- 4 Gigabit Ethernet ports that support PoE+ (802.3at).

-Total PoE power budget of 47W for the switch.

•Switching fabric (duplex mode, all ports line-rate) as follows:

-16 Gbps for models GSS108E and GSS108EPP.

-32 Gbps for model GSS116E.

•1-2-3-4 Click Mounting system, which lets you easily mount the switch vertically or

horizontally on a wall, pole, or table leg.

•Full compatibility with IEEE standards:

- IEEE 802.3 Ethernet

- IEEE 802.3i 10BASE-T

- IEEE 802.3u 100BASE-T

- IEEE 802.3ab 1000BASE-T

-IEEE 802.3x Full-duplex flow control

- IEEE 802.1Q VLAN tagging

-IEEE 802.1p Class of Service (QoS)

-IEEE 802.3az Energy Efficient Ethernet (EEE)

-IEEE 802.1af (PoE, model GSS108EPP only)

- IEEE 802.1at (PoE+, model GSS108EPP only)

•AutoSensing and autonegotiating capabilities for all ports.

•Auto Uplink technology is supported on all ports.

•Automatic address learning function to build the packet-forwarding information

table. The table contains Media Access Control (MAC) addresses as follows:

-Up to 8K for models GSS108E and GSS116E.

-Up to 4K for model GSS108EPP.

Hardware Installation Guide7Introduction

8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch

•Store-and-forward transmission.

•Flow control to minimize packet loss and frame drops.

•Half-duplex backpressure control.

•Per-port status LEDs and system status LEDs.

•Per-port PoE status LEDs and system PoE Max LED for model GSS108EPP only.

•NETGEAR green power-saving features:

-Energy efficiency mode that fully conforms to the IEEE802.3az standard.

- Per-port automatic change to a lower power mode when the port link is down.

Among the key software features, the switch provides traffic management and multicast

efficiency:

•Traffic management:

- Dynamic MAC address management.

- IEEE 802.1Q–based or port-based VLAN.

- QoS based on weighted round robin (WRR).

-Port-based and IEEE 802.1p–based Quality of Service (QoS).

-QoS based on Type of Service (ToS).

- DSCP support.

- Rate limiting.

•Multicast efficiency:

-IGMP snooping, v1, v2 and v3 (source filtering is not supported).

-Blocking of unknown multicast traffic.

- Static multicast router port.

Certain features such as USB charging ports, link aggregation, and PoE+ ports are

available on specific switch models, as follows:

•USB charging ports. See USB charging ports (model GSS108E) on page 18.

•Link aggregation . See Static LAG connections (models GSS116E and GSS108EPP)

on page 20.

•PoE+ ports. See PoE applications (model GSS108EPP) on page 21.

Hardware Installation Guide8Introduction

8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch

Safety instructions and warnings

Use the following safety guidelines to ensure your own personal safety and to help

protect your system from potential damage.

To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment,

observe the following precautions:

•This product is designed for indoor use only in a temperature-controlled and

humidity-controlled environment. For more information, see the environmental

specifications in the appendix or the data sheet.

Any device that is located outdoors and connected to this product must be properly

grounded and surge protected.

Failure to follow these guidelines can result in damage to your NETGEAR product,

which might not be covered by NETGEAR’s warranty, to the extent permissible by

applicable law.

•Observe and follow service markings:

- Do not service any product except as explained in your system documentation.

Some devices should never be opened.

-If applicable to your device, opening or removing covers that are marked with

the triangular symbol with a lightning bolt can expose you to electrical shock.

We recommend that only a trained technician services components inside these

compartments.

•If any of the following conditions occur, unplug the product from the electrical outlet

and replace the part or contact your trained service provider:

- Depending on your device, the power adapter, power adapter cable, power

cable, extension cable, or plug is damaged.

-An object fell into the product.

- The product was exposed to water.

- The product was dropped or damaged.

-The product does not operate correctly when you follow the operating

instructions.

•Keep your system away from radiators and heat sources. Also, do not block cooling

vents.

•Do not spill food or liquids on your system components, and never operate the

product in a wet environment. If the system gets wet, see the appropriate section in

your troubleshooting guide, or contact your trained service provider.

Hardware Installation Guide9Introduction

8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch

•Do not push any objects into the openings of your system. Doing so can cause fire

or electric shock by shorting out interior components.

•Use the product only with approved equipment.

•If applicable to your device, allow the product to cool before removing covers or

touching internal components.

•Operate the product only from the type of external power source indicated on the

electrical ratings label. If you are not sure of the type of power source required,

consult your service provider or local power company.

•To avoid damaging your system, if your device uses a power supply with a voltage

selector, be sure that the selector is set to match the power at your location:

-115V, 60 Hz in most of North and South America and some Far Eastern countries

such as South Korea and Taiwan

- 100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan

-230V, 50 Hz in most of Europe, the Middle East, and the Far East

•Be sure that attached devices are electrically rated to operate with the power available

in your location.

•Depending on your device, use only a supplied power adapter or approved power

cable:

If your device uses a power adapter:

-If you were not provided with a power adapter, contact your local NETGEAR

reseller.

-The power adapter must be rated for the product and for the voltage and current

marked on the product electrical ratings label.

If your device uses a power cable:

-If you were not provided with a power cable for your system or for any

AC-powered option intended for your system, purchase a power cable approved

for your country.

-The power cable must be rated for the product and for the voltage and current

marked on the product electrical ratings label. The voltage and current rating of

the cable must be greater than the ratings marked on the product.

•To help prevent electric shock, plug the system and peripheral power cables into

properly grounded electrical outlets.

•If applicable to your device, the peripheral power cables are equipped with

three-prong plugs to help ensure proper grounding. Do not use adapter plugs or

remove the grounding prong from a cable. If you must use an extension cable, use

a three-wire cable with properly grounded plugs.

Hardware Installation Guide10Introduction

8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch

Otros manuales para GSS108E

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de NETGEAR

NETGEAR

NETGEAR DG632 - ADSL Modem Router Manual de usuario

NETGEAR

NETGEAR N450 WNR2500 Manual de usuario

NETGEAR

NETGEAR XEB1004 - 85 Mbps Powerline EN Switch Manual de usuario

NETGEAR

NETGEAR MBRN3000 Manual de usuario

NETGEAR

NETGEAR RH348 Manual de usuario

NETGEAR

NETGEAR Nighthawk C7100V Manual de usuario

NETGEAR

NETGEAR WGR624v3 Manual de usuario

NETGEAR

NETGEAR Orbi Pro SXS80 Manual de usuario

NETGEAR

NETGEAR XE102 - Wall-Plugged EN Bridge Manual de usuario

NETGEAR

NETGEAR R7900 Manual de usuario

NETGEAR

NETGEAR Orbi Pro SRR60 Manual de usuario

NETGEAR

NETGEAR FS308 - Switch Manual de usuario

NETGEAR

NETGEAR RT328 Manual de usuario

NETGEAR

NETGEAR Orbi RBR20 Manual de usuario

NETGEAR

NETGEAR ProSafe FVX538 Instrucciones de instalación y funcionamiento

NETGEAR

NETGEAR Wireless ADSL Modem Router Guía del usuario

NETGEAR

NETGEAR R6400v2 Manual de usuario

NETGEAR

NETGEAR Nighthawk X10 Guía de solución de problemas

NETGEAR

NETGEAR RAX49 Manual de usuario

NETGEAR

NETGEAR ProSafe FVS318N Manual de usuario

NETGEAR

NETGEAR R6100 Manual de usuario

NETGEAR

NETGEAR RP614 - Web Safe Router Manual de usuario

NETGEAR

NETGEAR D8500 Manual de usuario

NETGEAR

NETGEAR Orbi RBK753 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad

LevelOne

LevelOne FBR-1416 Manual de usuario
