CloudMesh Hybrid Gateway

NL19MESH MOBILE BROADBAND

2

GETTING

STARTED

PRE-CONFIGURED?

If you received your gateway from your service provider

and they have provided you with their own instructions,

refer to those to complete the setup. In some cases, the

gateway has been pre-congured for you and is ready to use.

Otherwise, you will need to complete the setup yourself.

3

BEFORE YOU BEGIN

Ensure that you have the following information

from your service provider:

- How your Internet service will physically connect to your gateway

- The Settings specic to your type of service.

There are three primary ways to connect your

gateway to the Internet service:

Mobile Broadband

This uses the cellular network to connect to the Internet,

just like a smartphone does. Requires a valid carrier

SIM card be inserted in the gateway to work.

Ethernet WAN

This is the most common access type in Australia and New Zealand

and covers xed line technologies such as nbn™ FTTP, HFC, FTTC

as well as UFB Fixed Wireless and Sky Muster™ satellite services.

This type of Internet service uses the red WAN port on the

back of the gateway to connect to the dedicated connection

box installed by your access network provider.

ADSL or VDSL

These access types are provided by nbn™ FTTB, FTTN

or ADSL/VDSL over a traditional telephone line.

This connection uses the grey DSL port on the back of the gateway.

CW

4

ATTACHING

THE ANTENNAS

CW

5

ATTACHING THE ANTENNAS

To use Mobile Broadband attach the two antennas in the sockets on

the back of your gateway by turning them in a clockwise direction

on the antenna sockets, as shown in the following diagram:

INSERTING

YOUR SIM CARD

Mobile Broadband

If you intend to use a cellular connection you will

need to have a Mini SIM card issued by a service

provider and attach the two antennas.

6

7

INSERTING YOUR SIM CARD

Insert the SIM card into the SIM card slot on the side of the

gateway in the orientation shown in the following diagram:

Note - Your carrier may have inserted the SIM card prior to shipping.

8

ETHERNET WAN

CONNECTIONS

Here’s how things connect for Ethernet WAN connections

9

nbn™ Connection box

/ UFB Optical Network

Terminal (ONT)

10

ADSL / VDSL

CONNECTIONS
