NetComm V320W Manual de usuario

NetComm V320W

WLAN VoIP Gateway

Designed for residential and business users the NetComm V320W is a powerful

WLAN VoIP Gateway, providing predictable, real-time, toll-quality voice calls over

the Internet. Perfect for users with broadband DSL/Cable who need the beneﬁt

of a wireless Access Point with the added savings of VoIP. The V320W offers

easy access to the Internet via WLAN or Ethernet, and provides VoIP via standard

analog phones.

The powerful VoIP functionality of the V320W allows calls to be routed to anywhere

in the world – signiﬁcantly reducing or eliminating your long distance charges and

can even save you money on your interstate calls.

Unlike many other alternatives that need you to have your home PC turned on to

take advantage of VoIP, with the V320W you can make phone calls even when

your PC is turned off.

The V320W supports QoS, which provides high quality voice service ensuring

that your call quality is as good as it needs to be. It also provides a solution for all

your network and telephony needs in one compact, integrated unit, clearing away

the clutter of multiple devices and the cost of hardware and cabling.

This makes the NetComm V320W the clear choice if you want to enjoy the

savings of VoIP with the added beneﬁt of a ﬁrst class Router.

KEY FEATURES

VoIP and Router Integrated Supports 3-way conference

Integrated 802.11g AP (backward compatible with 802.11b) DNS SRV

Supports life line: PSTN alive when power off Dial plan

Supports Quality of Service (QoS) for voice Supports VPN Pass-Through

Supports caller ID presentation and restriction Supports Day-time parental control

Supports call hold/call waiting/call forwarding and call transfer

Remote administration & automatic ﬁrmware upgrade & conﬁguration

Centralized conﬁguration and ﬁrmware upgrade via APS (Automatic Provision Sever, optional)

NETCOMM LIMITED ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia

P: 02 9424 2070 F: 02 9424 2010 E: [email protected] W: www.netcomm.com.au

Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Speciﬁcations are

subject to change without notice. Images shown may vary slightly from the actual product.

NetComm V320W

WLAN VoIP Gateway

TECHNICAL SPECIFICATIONS

Your NetComm dealer:

Telephone

Wall Socket

Splitter with

Microfilter

ADSL2+ Broadband

Modem/ Cable Modem

Home

Telephone

(Phone Port 1)

Line in

(FXO port,

Lifeline only)

WAN port

RJ-11 Telephone line

RJ-45 Ethernet cable

Internet PSTN

Wireless Link

LAN 1 LAN 2 LAN 3 LAN 4

Home

Telephone

(Phone Port 2)

V320W - Wireless LAN VoIP Gateway

WAN INTERFACE

• Ethernet x 1

LAN INTERFACE

• Ethernet x 4

WLAN

• MAC Address Filtering, WEP, WPA, WP2,

IEEE 802.1X

• 10, 25, 50, 100mW @ 22MHz channel bandwidth

Output power level can be selected according to

the environment

Standard

• IEEE802.11g, backward compatible with 802.11b

Encryption

• 64, 128-bit Wired Equivalent Privacy (WEP) Data

Encryption

Channels

• 11 Channels (US, Canada)

• 13 Channels (Europe, Australia)

• 14 Channels (Japan)

Data Rate

• Up to 54Mbps

ANALOg INTERFACE

• FXS x 2

• FXO x 1 (Life Line only)

WAN CONNECTION

• PPPoE(RFC 2516)

• DHCP Client

• Static IP

MANAgEMENT

• SNMP, SNTP, Telnet, Web-based management,

Conﬁguration backup and restoration

• Firmware upgrade via HTTP, TFTP client and server,

or FTP server

• Centralized conﬁguraiton and ﬁrmware upgrade via

APS (optional)

ROUTINg FUNCTIONS

• Static route, RIP v1,v2, NAT/PAT, DMZ, DHCP

Client/Server/Relay, DNS Proxy, DDNS, IGMP proxy

SECURITY FUNCTIONS

• Stateful Packet Inspection, Packet ﬁltering, Denial

Of Service protection, Trafﬁc Conditioning

Authentication protocols

• PAP, CHAP

VPN

• PPTP/L2TP/IpSec pass-through

Management

•HTTP proxy

VOICE FUNCTIONS

•QoS

•Life line

•Dial Plan

•Silence suppression

•T.38/Fax pass through

SIP

•RFC 3261

Codec

•G.711a, G.711u, G.729, ILBC

RTP

•RFC 1889

SDP

•RFC 2327

Caller ID

•ETSI based

Echo cancellation

•G.168

DTMF

•RFC2833/in-band

POWER

• External power adapter

• 100-240Vac to 12Vdc /1.5A

ENVIRONMENTAL CONDITIONS

Operating temperature

• 0 ~ 50 degrees Celsius

Relative humidity

• 5 ~ 90% (non-condensing)

DIMENSIONS

• 205 mm (W) x 47 mm (H) x 145 mm (D)
