Quick Start Guide
NetComm CF40
Wi-Fi 6
This guide provides instructions for setting up, connecting,
and conguring your NetComm CF40 Wi-Fi 6.
more.com.au 2
NetComm CF40 Wi-Fi 6 Quick Start Guide
contents:
Get to Know Your NetComm CF40 Wi-Fi 6 ..............................................................................................................................3
Setting Up Your NetComm CF40 Wi-Fi 6 .................................................................................................................................5
Conguring Your NetComm CF40 Wi-Fi 6 ...............................................................................................................................7
Other Important Information About Your NetComm CF40 Wi-Fi 6 ................................................................................8
Need Support? ..................................................................................................................................................................................8
more.com.au 3
NetComm CF40 Wi-Fi 6 Quick Start Guide
get to know your
NetComm CF40 Wi-Fi 6
Top View of Device
LED Indicator Lights
This lights represent the working state and
connectivity of the NetComm Wi-Fi 6 Gateway
• Green = connected
• Red = disconnected
Bottom View of Device
Wi-Fi 6 Gateway Label
Contains your Wi-F network name and Wi-F
password. You’ll need these to connect your
devices to Wi-Fi.
more.com.au 4
NetComm CF40 Wi-Fi 6 Quick Start Guide
Back View of Device
Ethernet LAN
Ports
Ethernet WAN
Ports
Power
Button
DC in Point
Button/Connection Port Description
Power Button Turns the NetComm CF40 Wi-Fi 6 on or o.
DC IN Point Connection point for the included power adapter to connect to the
power supply.
Ethernet WAN Port
Connect to your Network Termination Device (NTD) for high-speed
internet access. Covers xed line technologies such as nbn™ FTTP,
HFC, FTTC and Fixed Wireless.
Ethernet LAN Port
Connect your Ethernet based devices (E.g., computers, servers,
modems, Wi-Fi routers, switches, and other network devices) to one of
these ports for high-speed internet access.
more.com.au 5
NetComm CF40 Wi-Fi 6 Quick Start Guide
seing up your
NetComm CF40 Wi-Fi 6
Step 1:Power on the NetComm CF40 Wi-Fi 6
• Plug the device power adapter into a wall socket.
• Press the power button on the NetComm CF40 Wi-Fi 6 and wait a few minutes for it to start up.
• The power LED indicator will appear green on the top of the NetComm CF40 Wi-Fi 6 if it is on and
operating correctly.
Step 2:Connect your NetComm CF40 Wi-Fi 6
Depending on your nbn™ technology type, your NetComm CF40 Wi-Fi 6 will connect dierently. If you are
unsure of your nbn™ technology type, it is listed in your nbn™ ordered email.
If your NBN connection is: Instructions:
Hybrid Fibre Coaxial (HFC)
Fibre to the Premises (FTTP)
Fibre to the Curb (FTTC) or Fixed Wireless
Connect the ethernet cable from the WAN port on the NetComm CF40
Wi-Fi 6 to the UNI-D port on your nbn™ connection box.
Note: Wait for the lights on the nbn™ connection box to turn blue (this
may take up to 15 minutes).
NBNCo Network
Termination Device
WAN Port
Power Adapter Power Outlet
Ethernet Cable
DC In Point
more.com.au 6
NetComm CF40 Wi-Fi 6 Quick Start Guide
NBNCo Network
Connection Device
WAN Port
Ethernet Cable
Power Adapter Power Outlet
DC In Point
Step 3: Connect your devices to Wi-Fi
• Using your device, scan the QR code on the label and/or WI-FI Security Card and select “Join Wi-Fi
Network” if prompted.
• Alternatively, on your device scan for and select the Wi-Fi Network Name and enter the password outlined
on the label and/or WIFI Security Card to connect.
more.com.au 7
NetComm CF40 Wi-Fi 6 Quick Start Guide
Note: This is only needed if you have factory-reset your modem/router. Otherwise, More has
pre-congured hardware specically for your service and this step is not required.
If you have factory-reset your device or purchased from an alternative retailer, please follow these easy steps
to access the conguration page of your NetComm CF40 Wi-Fi 6.
1. Push the power button on the back of the NetComm CF40 Wi-Fi 6 to turn it on. Wait a few minutes for it to
complete starting up.
2. Connect to the NetComm CF40 Wi-Fi 6 using Wi-Fi or an Ethernet cable to the yellow LAN port.
3. Open a web browser and type https://192.168.20.1 into the address bar, then press Enter.
4. At the login screen, type in the username and password printed on the label on the bottom of the
NetComm CF40 Wi-Fi 6 and click the login button.
5. Select ‘Basic Setup’ from the menu on the left-hand side of the screen to begin set up.
6. Select ‘PPPoE’ as your WAN setting connection type
7. Enter your SSID and password. Note: SSID is your unique network name that appears when you scan for
nearby wireless networks. You can choose and create your own network name.
8. Select your applicable ‘Time Zone Oset’ and ‘Daylight Saving Time’ setting.
9. Review the summary page that will appear and select the ‘Save’ button to complete the setup.
Configuring your
NetComm CF40 Wi-Fi 6
more.com.au 8
NetComm CF40 Wi-Fi 6 Quick Start Guide
Other Important
Information about your
NetComm CF40 Wi-Fi 6
Product Warranty
NetComm oers a two (2) year warranty on xed broadband products commencing from the date of purchase.
For more information read NetComm’s T&Cs here.
Wi-Fi Analytics Platform
The CloudMesh Wi-Fi Analytics Platform is a fully integrated solution that provides visibility into the health
of each individual Wi-Fi home network. It creates superior end-user experiences by enabling proactive
diagnostic, management, and control of the home Wi-Fi environment, helping resolve even the most elusive
Wi-Fi problems.
Wi-Fi Autopilot
Every NetComm CF40 Wi-Fi 6 includes the CloudMesh Wi-Fi AutoPilot. Wi-Fi AutoPilot constantly scans and
analyses your Wi-Fi network environment and if any detrimental changes are detected, the Wi-Fi AutoPilot
adjusts the NetComm CF40 Wi-Fi 6’s Wi-Fi parameters. Any action taken is based on a patented and weighted
algorithm ensuring the internet connection experience is never compromised. It ensures that every Wi-Fi
client device is connected on the best possible channel, using the fastest available band, at the perfect RF
power level, utilising the closest Wi-Fi access point.
For a more comprehensive user guide, you can view the NetComm User Guide here.
Alternatively, for Customer Service and troubleshooting, contact our team on 1800 733 368
Need support?
