Neol EPowerSwitch-M8 Manual de usuario

ePowerSwitch-8

Power Management

Master

Slave

User's Guide

V.09/2004

ePowerSwitch-8

ePowerSwitch-8 is a couple of power control units made of a Master named ePowerSwitch-M8

and a slave named ePowerSwitch-S8.

ePowerSwitch-M8 (Master) is a power control unit with a built-in Web server, an Ethernet and

a serial RS232 connection. It enables you to control the power supply of 8 power sockets either

remotely through a Network (Intranet or Internet) or locally through its serial RS232 connection.

The number of the controlled sockets can be extended up to 40 by connecting up to 4

ePowerSwitch-S8 (Slave) to the Master.

Thanks to the use of two separate power inlets and the optional Twin mode which allows you to

control at the same time two power sockets, this device is the ideal solution to control the power

of servers using redundant power supplies.

ePowerSwitch-S8 (Slave) is a power control unit with a serial RS232 connection. It enables

you to control the power supply of 8 sockets through its serial RS232 connection. The number

of the controlled sockets can be extended up to 32 by cascading up to 4 ePowerSwitch-S8

(Slave).

Like the Master, this device has two separate power inlets to increase the security and the load

available on the power sockets.

Chapters

1. Safety instructions: to read before use! _____________________________________ 2

2. Installation____________________________________________________________ 3

3. Configuration of the ePowerSwitch-M8 (Master) ______________________________ 4

4. Configuration using the ePowerSwitch Finder program _________________________ 5

5. Configuration using a Terminal connection __________________________________ 7

6. Security parameters configuration ________________________________________ 18

7. Serial port configuration ________________________________________________ 20

8. Command the Power Sockets through a Web browser ________________________ 21

9. Command the Power Sockets through a serial connection _____________________ 22

10. Technical data ______________________________________________________ 25

11. Statement of Conformity_______________________________________________ 27

ePowerSwitch-8 Master and Slave User's Guide Page 1

1. Safety instructions: to read before use!

Remark: In the following instructions "ePowerSwitch device" is used for both devices

ePowerSwitch-M8 (Master) and ePowerSwitch-S8 (Slave).

 The ePowerSwitch devices can only be installed by qualified people with the following

installation and use instructions. The manufacturer disclaims all responsibility in case of a

bad utilisation of the ePowerSwitch devices and particularly any use with equipments that

may cause personal injury or material damage.

 This equipment is designed to be installed on a dedicated circuit that must have a circuit

breaker or fuse protection.

 The electrical power sockets used to plug the power cords of the ePowerSwitch devices must

be close to the ePowerSwitch devices and easily accessible.

 Check that the power cords, plugs and sockets are in good condition.

 The ePowerSwitch devices can only be connected to three-wire 230 VAC (50-60Hz) sockets.

 Always plug the ePowerSwitch devices into properly grounded power sockets (two poles plus

ground).

 Never exceed 10 Amp total load for each group of 4 power sockets of an ePowerSwitch

device.

 If you have to replace an external fuse of an ePowerSwitch device, never use another type of

fuse than 10A/250V T.

 The ePowerSwitch devices are intended for indoor use only. Do NOT install them in an area

where excessive moisture or heat is present.

 Always disconnect the 2 (two) power cords of the ePowerSwitch device if you want to

intervene on the ePowerSwitch device or on the equipment powered from the ePowerSwitch

device.

 The power outlets of the ePowerSwitch devices are not circuit breakers! If you want to

intervene on equipment connected to an ePowerSwitch device you must disconnect this

equipment from the ePowerSwitch device.

 The ePowerSwitch devices contain potentially hazardous voltages. Do NOT attempt to

disassemble them.

 The ePowerSwitch devices contain no user serviceable parts and repairs are to be performed

by factory trained service personnel only.

ePowerSwitch-8 Master and Slave User's Guide Page 2

2. Installation

The ePowerSwitch-M8 (Master) has a built-in Web server, an Ethernet and a serial interface. It

can be used as a stand-alone device to control over IP eight IEC power sockets. The number of

controlled sockets can be extended to 16, 24, 32 or 40 by cascading 1 to 4 ePowerSwitch-S8

(Slave).

The ePowerSwitch-S8 (Slave) has a serial RS232 interface used to control individually its 8

power sockets either through an ePowerSwitch-M8 (Master) or through any device using a

serial RS232 connection (PC, Console server...). By cascading up to 4 ePowerSwitch-S8

(Slave), it is possible to control up to 32 sockets via one serial port.

Connecting ePowerSwitch-M8 (Master)

1. Connect your 10BasteT cable to the RJ-45 network port and to the ePowerSwitch-M8.

If you want to configure the ePowerSwitch-M8 or control its power sockets over a Terminal

connection, connect the supplied serial cable to an available serial port on your PC and to the

serial port of the ePowerSwitch-M8.

2. Plug the 2 power cables into 2 grounded sockets. The A and B LEDs light on to confirm that

power is on and the Pwr LED confirms that the Web server is powered.

3. You can now configure the ePowerSwitch-M8 by following the indications of the paragraph 3

"Configuration of the ePowerSwitch-M8 (Master)" or, if necessary, install the ePowerSwitch-

S8 as indicated hereafter.

Connecting ePowerSwitch-S8 (Slave)

1. Connect the supplied RJ9 link-up cable to the RJ9 Out connector of the Master and to the

RJ9 In connector of the slave.

To cascade several Slaves, link RJ9 Out connector to RJ9 In connector of the next slave.

2. Allocate an address to each Slave by positioning the address selection DIP-switches marked

Slct on the front panel according to the following table.

Remarks

− Unplug the device before changing its DIP switches.

− Do NOT use the same address for two different Slaves.

Slave number DIP-switch 1 DIP-switch 2

1 Off Off

2 On Off

3 Off On

4 On On

Position Off = switch upwards

Position On = switch downwards

Micro-switch 1 is on the left side, micro-switch 2 on the right.

3. Plug the 2 power cables into 2 grounded sockets. The A and B LEDs light on to confirm that

power is on.

ePowerSwitch-8 Master and Slave User's Guide Page 3

3. Configuration of the ePowerSwitch-M8 (Master)

To use the ePowerSwitch-M8 on your network, you must first configure its network parameters.

Ask your network administrator for the parameters to use.

There are two different methods to configure the ePowerSwitch-M8:

Method 1:

Through a network using the ePowerSwitch Finder Program (on the delivered CD).

It is the simplest and fastest configuration method if you use Windows as operating system. We

suggest that you use this program at least during the first configuration: it allows you to

configure your ePowerSwitch-M8 through your local network even if its network parameters (IP

Address, Subnet mask and Port) are not compatible with those of your PC or your local

network.

If you decide to use this method you can directly go to §4 "Configuration using the

ePowerSwitch Finder program".

Default Network parameters:

IP address 192.168.100.100

Subnet mask 255.255.255.0

Gateway no address

Port 80

Method 2:

Through a RS232 serial connection using a Terminal connection. If you use a PC, use the serial

cable supplied with the product and a Terminal program such as Widows HyperTerminal or the

MicroTerminal program on the CD (folder miscellaneous).

If you decide to use this method, you can directly go to §5 "Configuration using a Terminal

connection".

ePowerSwitch-8 Master and Slave User's Guide Page 4

4. Configuration using the ePowerSwitch Finder program

Remarks:

− The ePowerSwitch-M8 and the PC used to configure it have to be connected on the same

segment of the network. The protocol of this program can not be routed so it can not be used

to configure the ePowerSwitch through a WAN or the Internet.

− This program does not work if the administrator has deactivated it in the configuration of the

ePowerSwitch (for security reasons for example).

1. Start the ePS-Finder.exe program on the CD-ROM.

The ePowerSwitch Finder window appears.

2. In the tool bar click on the first left button or choose the File/Scan Menu.

The program browses the segment on which is connected your PC and displays the name,

the type, the IP and MAC Address of the connected ePowerSwitch.

3. In the tool bar click on the second left button or choose the File/Configure Menu.

The properties dialog box appears and you can now configure the network parameters. To

configure all other parameters click on the Options button on the bottom of the dialog box.

ePowerSwitch-8 Master and Slave User's Guide Page 5

General Tab

This tab is used:

 to define all the network parameters of the ePowerSwitch-M8 (IP Address, Subnet Mask,

Default Gateway and Port Number).

 to permit or deny the configuration using the ePowerSwitch Finder program for security

reasons.

Labels Tab

This tab is used:

 to attribute a label to a group of ePowerSwitch devices connected together (a group is

made of 1 ePowerSwitch Master and up to 4 Slaves).

 to attribute a label to each ePowerSwitch and its 8 power sockets (use the left vertical

Tabs to select the ePowerSwitch you want to configure).

Accounts Tab

In combination with the left vertical tab Group, this tab is used:

 to attribute a name and a password to the administrator who has access to all the sockets

within a group of ePowerSwitch.

In combination with one of the left vertical tabs «Device 1» to «Device 5», this tab is used:

 to define 8 user accounts using a name and a password for each one.

 to define the power sockets each user will be able to control.

 to activate or deactivate an ePowerSwitch-S8 (Slave) connected to the Master.

 to define the function modus of each ePowerSwitch (Single mode or Twin mode):

- Single mode enables you to control individually each power socket,

- Twin mode enables you to control two power sockets with one command. This mode is

particularly intended to restart devices using redundant power supplies.

In that case, the 4 sockets powered by the power supply A (sockets 1 to 4) are

automatically associated to the 4 sockets powered by the power supply B (sockets 5 to 8)

and the labels of the first 4 sockets are used.

Security Tab

This tab is used to define addresses which are authorised or denied to access to the

ePowerSwitch over the Network. For all details about this features, please refer to chapter 6

"Security parameters configuration".

Options Tab

This tab is used to:

 define the restart delay valid for all power sockets of all ePowerSwitch connected together;

 configure an Email address to which the user can manually send a message in case of

problem.

Miscellaneous Tab

In combination with one of the left vertical tabs "Device 1" to "Device 5" to know how many

times an ePowerSwitch has been powered ON and how many times its power sockets have

been switched from OFF to ON. These values can not be reset by the user.

ePowerSwitch-8 Master and Slave User's Guide Page 6

5. Configuration using a Terminal connection

The RS232 serial port of the ePowerSwitch-M8 can be used to control its power socket and to

configure its Web server.

To configure the Web server using a PC and a Terminal connection:

1. Use the supplied RS232 serial cable to connect the ePowerSwitch-M8 to an available serial

port of your PC.

2. Run a terminal program such as Windows HyperTerminal or the MicroTerminal program on

the CD (folder miscellaneous).

3. Configure the appropriate serial port with the following settings:

9.600 bauds, 8 bits, no parity, 1 stop bit and no flow control.

If you use the MicroTerminal program on the CD (folder miscellaneous) you only have to

choose the used serial port, this program is already configured at 9600,n,8,1.

4. On your computer, press <ENTER> until the prompt «>» appears on your screen.

(the ePowerSwitch-M8 is now in Command mode and is waiting for commands to switch the

power sockets. The serial command mode is explained in § 9).

5. Press the <TAB> key on your keyboard.

The Configuration menu appears on your screen and the ePowerSwitch-M8 is now in the

Configuration mode. Follow the menu to configure the Web server of your ePowerSwitch-M8.

All commands start with the slash «/»

ex.: type the command /NP to go to the Network Parameters settings menu.

To display the current menu again, press <ENTER>.

To go to the previous menu and to display it, press <ESC>.

ePowerSwitch M8

Commands :

Configuration

/NP Network Parameters Settings

/PS Passwords Settings

/NS Group, Device and Socket Names Settings

/DP Device Parameters Settings

/RD Socket Restart Delay Settings

/IS IP Security Settings

/RS Restart the Device

Enter Selection

Remark: to leave the configuration mode, type the restart command /RS. This is particularly

important if you want to control the power socket later through the serial connection.

The configuration of the serial port is explained in § 7 (Serial port configuration).

ePowerSwitch-8 Master and Slave User's Guide Page 7

MAIN CONFIGURATION MENU

The Main menu of the configuration mode displays all the commands that can be used.

 All commands start with the character slash «/»

(ex.: type the command /NP to go to the Network Parameters settings menu.

 To display the current menu again, press <ENTER>.

 To return to the previous menu and display it, press <ESC>.

ePowerSwitch

Commands :

Configuration

/NP Network Parameters Settings

/PS Passwords Settings

/NS Group, Device and Socket Names Settings

/DP Device Parameters Settings

/RD Socket Restart Delay Settings

/IS IP Security Settings

/RS Restart the Device

Enter Selection

ePowerSwitch-8 Master and Slave User's Guide Page 8

NETWORK PARAMETERS SETTINGS MENU

Command /NP

This Menu is used to configure all network parameters (IP Address, Subnet Mask, Gateway and

Port) and to permit or prevent the configuration over a local area network using the special

ePowerSwitch Finder program.

NETWORK PARAMETERS SETTINGS

MAC Address 00.01.9A.F1.00.0F

1. IP Address 192.168.100.100

2. Subnet Mask 255.255.255.0

3. Gateway 0.0.0.0

4. Port 80

5. Finder Activated

Enter Selection or <ESC> to exit

Command 1

NETWORK PARAMETERS SETTINGS

IP Address is: 192.168.100.100

Enter IP Address or <ESC> to exit

You must restart the device (Command /RS) to valid the new parameters

Command 2

NETWORK PARAMETERS SETTINGS

Subnet Mask is: 255.255.255.0

Enter subnet mask or <ESC> to exit

You must restart the device (Command /RS) to valid the new parameters

Command 3

NETWORK PARAMETERS SETTINGS

Gateway is: 0.0.0.0

Enter gateway address or <ESC> to exit

You must restart the device (Command /RS) to valid the new parameters

ePowerSwitch-8 Master and Slave User's Guide Page 9

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Neol

Neol

Neol ePowerSwitch 8XM R2 Manual de usuario

Neol

Neol 8XS R2 Manual de usuario

Neol

Neol ePowerSwitch 8M+R2 Manual de usuario

Neol

Neol 8XM Master Manual de usuario

Neol

Neol ePowerSwitch 1GR2 Manual de usuario

Neol

Neol ePowerSwitch M8 Manual de usuario

Neol

Neol ePowerSwitch-1 Guard Manual de usuario

Neol

Neol ePowerSwitch 1GR2 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario

Neol ePowerSwitch-M8 Manual de usuario

Manuales populares de Cambiar de otras marcas
