NEC Exastro ITA Manual del operador

ITA_User instruction Manual

Basic Console

－

Version 1.9

－

Exastro-ITA_User instruction Manual Basic Console 1 / 19

Disclaimer

All the contents of this document are protected by copyright owned by NEC Corporation.

Unauthorized reproduction or copying of all or part of the contents of this document is prohibited.

The contents of this document are subject to change without prior notice in the future.

NEC Corporation is not responsible for any technical or editorial errors or omissions in this document.

NEC Corporation do not guarantee accuracy, usability, certainty of the content in this document.

Trademark

Linux is registered trademark or trademark of Linux Torvalds, registered in the U.S. and other

countries.

Red Hat is registered trademark or trademark of Red Hat,Inc. Registered in the U.S. and other

countries.

Apache, Apache Tomcat, and Tomcat are registered trademarks or trademarks of the Apache

Software Foundation.

Ansible is registered trademark or trademark of Red Hat,Inc.

AnsibleTower is registered trademark or trademark of Red Hat,Inc.

The names of other systems, company name and products mentioned in this document are registered

trademarks or trademarks of their respective companies.

The® mark and TM mark are not specified in this document.

※ “Exastro IT Automation” is written as “ITA” in this document.



Exastro-ITA_User instruction Manual Basic Console 2 / 19

Table of contents
Introduction.................................................................................................................................................3
1Overview of ITA basic console ............................................................................................................4
2ITA basic console menu screen configuration ....................................................................................5
2.1 ITA basic console menu list .........................................................................................................5
3ITA basic console user instruction procedure .....................................................................................6
3.1 Work flow .....................................................................................................................................6
4Function and operation method description........................................................................................7
4.1 ITA basic console.........................................................................................................................7
 Device list ...............................................................................................................................7
 Associated menu..................................................................................................................10
 Input operation list ................................................................................................................ 11
 Movement list ....................................................................................................................... 12
 ER Diagram ..........................................................................................................................13
 ER Diagram menu list. .........................................................................................................15
 ER Diagram Item list ............................................................................................................ 16
5Operation notes.................................................................................................................................19
5.1 Routine deletion of operation work history ................................................................................19


Exastro-ITA_User instruction Manual Basic Console 3 / 19

Introduction

This document explains the functions and operation methods of the ITA basic console.

Exastro-ITA_User instruction Manual Basic Console 4 / 19

1 Overview of ITA basic console

This chapter explains the functions and operation methods of the basic console menu.

The basic console provides the following functions that are commonly required to perform work using

ITA.

Exastro-ITA_User instruction Manual Basic Console 5 / 19

2 ITA basic console menu screen configuration

This chapter explains the menu and screen configuration of the ITA basic console.

2.1 ITA basic console menu list

The ITA common / basic console menu is shown below.

Table 2.1-1 ITA screen list

Group

Menu / Screen

Description

ITA basic

console

Device list

Users can maintain the list of managed systems (view / register / update

/ discard).

Input operation list

Users can maintain the operation list (view / register / update / discard).

Movement list

Users can view the list of registered movements.

ER Diagram

Displays the links between all menus and their referred data in an ER

Diagram.

Exastro-ITA_User instruction Manual Basic Console 6 / 19

3 ITA basic console user instruction procedure

3.1 Work flow

The standard workflow in the ITA basic console is as follows.

Details of each operation are described in next section.

Please refer to the details on how to register a Movement in the user instruction manual of each driver.

Figure 3.1-1 Work flow

①Confirm/ Check device information

② Confirm / Check Operation

④ Check Movement

③

Registering Movement in each driver of

ITA

Exastro-ITA_User instruction Manual Basic Console 7 / 19

4 Function and operation method description

4.1 ITA basic console

Device list

In the [Device List] screen, information on the target host is managed.

Please register the required information according to the server type before running the

orchestrators.

If the server information has been changed when re-executing, change the server information in

advance.

Figure 4.1-1 Submenu screen (device list)

Click [Registration] - [Start Registration] button to register device information.

Figure 4.1-2 Registration screen (device list-common items)

Exastro-ITA_User instruction Manual Basic Console 8 / 19

The list of common items on the registration screen is as follows.

Please make sure to enter the target [Host name] and [IP address].

※Registration is required if “Login password” is "●"for “Management”.

Table 4.1-1 List of Registration Screen Items (Device List-Common Items)

Item

Description

Input

Required

Input

type

Restrictions

Managed system item

number

A unique ID that identifies the registration

information is automatically entered.

Autofill

If the managed

system item number

exceeds

10,000,000, the

host group function

will not function

properly.

If you want to use

the host group

function, make sure

that the managed

system item number

is lower than

10,000,000.

HW device type

Select the type of HW device

Manual

input

Maximum length

128 bytes

Host name

Enter the host name

○

Manual

input

IP address

Enter the IP address (xxx.xxx.xxx.xxx format).

○

Manual

input

Maximum length 15

bytes

EtherWa

keOnLan

MAC

address

Enter MAC address

Manual

input

Maximum length 17

bytes

Network

device name

Enter the network device name

Manual

input

Maximum length

256 bytes

Enter the user ID to log in.

Manual

input

Maximum length 30

bytes

password

Managemen

Select “●”to manage the password in ITA

List

selecti

passwords

Specify a password

※

Manual

input

Maximum size 128

bytes

ssh key

credentia

SSH private

key file

Enter the key file when performing key

authentication by specifying the ssh

authentication key file. Provide a key file that

can be authenticated by the root user.

File

selecti

Passphrase

If there is a passphrase set to the ssh key file,

make sure to input it here.

Maximum size 256

bytes

Remarks

Free description field

Manual

input

In addition to the common items, information is registered when using each Driver/orchestrator.

For details on each Driver, Please refer to the usage instruction for each driver.

① Ansible Dedicated information

Exastro-ITA_User instruction Manual Basic Console 9 / 19

Figure 4.1-3 Registration Screen (Device List-Ansible)

・Ansible Dedicated information is a required parameter for Ansible driver.

・For more details, please refer to “Usage Instruction_Manual_Ansible-driver”.
