NARDA NIM-511 Manual de usuario

NIM-511 / NIM-513

Narda Industrial Field Meter

Operating Manual

Distributed by:

Air-Met Scientic Pty Ltd

Work with Confidence

Air-Met Sales/Service

P: 1800 000 744

F: 1800 000 774

E: [email protected]

Air-Met Rental

P: 1300 137 067

E: [email protected]

W: www.airmet.com.au

Narda Safety Test Solutions GmbH

Sandwiesenstraße 7

72793 Pfullingen, Germany

® Names and Logo are registered trade-

marks of Narda Safety Test Solutions GmbH

and L3 Communications Holdings, Inc. –

Trade names are trademarks of the owners.

This product is protected by the following

patents:

United States Patent US6084551

Order no.: 2403/98.22

Edition: 01/09.11, A...

Previous edition: -

Subject to change.

Our normal guarantee and delivery terms

apply.

Printed in Germany

Contents

Narda NIM-51x i

Contents

1 Useful information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 Measuring electromagnetic fields . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2 About this instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.3 About this operating manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Characters and symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Using this operating manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.3 Improper use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.4 Dangers from electromagnetic fields . . . . . . . . . . . . . . . . . . . . . . 9

Strong Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Measurement Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Probe is not operating properly. . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.5 Dangers when handling rechargeable batteries . . . . . . . . . . . . . 10

2.6 Dangers from AC adapter/charger . . . . . . . . . . . . . . . . . . . . . . . 10

3 Preparing the NIM-51x for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.1 Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Items included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Transport damage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

After transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.2 Instrument overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Contents

ii NIM-51x Narda

3.3 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Operation from rechargeable batteries . . . . . . . . . . . . . . . . . . . 16

Charge state and power source indicator . . . . . . . . . . . . . . . . . 18

3.4 Connecting the probe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4 Measuring with the NIM-51x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.1 Avoiding measurement errors . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Electrostatic charges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Changes in temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Strong low frequency fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.2 Switching on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.3 Displaying the instrument configuration . . . . . . . . . . . . . . . . . . . 24

4.4 Self test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.5 Setting the contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.6 Overview of the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.7 Selecting the result type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

ACT (Actual) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

MAX (Maximum) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

AVG (Average) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

SPATIAL (spatial average) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

4.8 Selecting the units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.9 Freezing a result . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.10 Changing the field type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.11 Switching off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Contents

Narda NIM-51x iii

5 Instrument maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

5.1 Cleaning the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

5.2 Replacing / removing the batteries . . . . . . . . . . . . . . . . . . . . . . . 32

5.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Rechargeable batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Instrument. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

5.4 Checking for proper operation . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

6.1 Display and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6.2 Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6.3 Uncertainty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

6.4 General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

6.5 Standards compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

6.6 AC Adapter / Charger Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

6.7 CE Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

6.8 Declaration of origin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

7 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

7.1 NIM-511 and NIM-513 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

7.2 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Contents

iv NIM-51x Narda

Narda NIM-51x 1

1Useful information

This chapter contains basic information about measuring

electromagnetic fields and about using the NIM-51x.

1.1 Measuring electromagnetic fields (page 2)

1.2 About this instrument (page 2)

1.3 About this operating manual (page 4)

1 Useful information

2 NIM-51x Narda

1.1 Measuring electromagnetic fields

In today’s world, practically everyone lives and works in an

environment surrounded by technical equipment that gener-

ates electromagnetic fields. Our recognition of the problems

associated with such fields and our depth of information in

this area has increased as the effects of such fields on the

human body have been examined more closely. Various

authorities have long defined limit values designed to pro-

tect users from the dangers of exposure to such emissions.

1.2 About this instrument

The Narda Industrial Meters NIM-511 and NIM-513 com-

bine an unprecedented ease of operation with powerful

measurement capabilities. It provides the industrial plant

manager and safety professional with an accurate and inex-

pensive solution for proving compliance with regulations

that cover exposure to RF radiation. Both models provide a

complete measurement system comprised of an extremely

easy to operate meter (NIM-510) and a probe (NIM-511 or

NIM-513) that contains sensors to measure both the electric

(E) and magnetic (H) field components of an electromag-

netic wave.

The NIM-513 operates from 10 MHz to 42 MHz and is

adjusted to the reference calibration frequency at

27.12 MHz. The NIM-511 has a much broader sensor that

operates from 300 kHz to 100 MHz and is adjusted to the

reference calibration frequency at 13.56 MHz.

1.2 About this instrument

Narda NIM-51x 3

Applications

Major safety standards worldwide require that both the elec-

tric and the magnetic field components (E and H fields) be

measured for equipment operating below 300 MHz. Most

high power industrial equipment operates at one of the fre-

quencies allocated for Industrial, Scientific, and Medical

(ISM) applications. Two ISM frequencies – 27.12 MHz and

13.56 MHz – are used extensively. The majority of heat

sealers and induction heaters operate at 27.12 MHz while

most semiconductor processing equipment operates at

13.56 MHz.

Examples:

• RF or High Frequency Heat Sealers

• Vinyl Welders

• Semiconductor Process Equipment

• Glass Deposition

• RF Induction Heating

• Dielectric Dryers and Heaters

• Plasma Generation Systems

RF energy can cause the body to be heated beyond its abil-

ity to thermally regulate itself. Since 1987 OSHA has had

the authority to cite employers for exceeding the limits spec-

ified by “state-of-the-art, scientific standards.” OSHA has

chosen the IEEE C95.1-2005 Standard for enforcement of

non-ionizing radiation safety. This IEEE standard includes

many changes from earlier standards and is considerably

more complex.

The Maximum Permissible Exposure (MPE) limits for Con-

trolled Environments are:

Table 1 IEEE C95.1-2005 exposure limits for controlled

environment

Frequency E Field

(mW/cm2)

H Field

(mW/cm2)

13.56 MHz 4.89 54.4

27.12 MHz 1.22 13.6

40.68 MHz 1.00 6.04

1 Useful information

4 NIM-51x Narda

For countries which follow the ICNIRP recommendations

the exposure limits are:

Table 2 ICNIRP 1998 Reference levels for occupational

exposure (extract)

1.3 About this operating manual

Characters and symbols used

Various elements are used in this operating manual to indi-

cate special meanings or particularly important passages in

the text.

Symbols and terms used in warnings

According to the American National Standard

ANSI Z535.6-2006, the following warnings, symbols, and

terms are used in this document:

Frequency f E Field

(V/m)

H Field

(A/m)

1 - 10 MHz 610 / f (f in MHz) 1.6 / f (f in MHz)

10 - 400 MHz 61 0.16

The general danger symbol warns of risk of serious injury

when used with the signal words CAUTION, WARNING,

and DANGER. Follow all the instructions in order to avoid

injuries or death.

NOTICE Indicates a danger that results in damage to or destruction

of the instrument.

CAUTION Indicates a hazardous situation which, if not avoided,

could result in minor or moderate injury.

WARNING Indicates a hazardous situation which, if not avoided,

could result in death or serious injury.

DANGER Indicates a hazardous situation which, if not avoided, will

result in death or serious injury.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de NARDA

NARDA

NARDA IDA Manual de usuario

NARDA

NARDA SRM-3006 Manual de funcionamiento

NARDA

NARDA AMS-8061 Manual de usuario

NARDA

NARDA FieldMan Manual de usuario

NARDA

NARDA PMM 6600 Manual de usuario

NARDA

NARDA 8061 Manual de usuario

NARDA

NARDA NRA Series Manual de instrucciones

NARDA

NARDA 8718B Manual de usuario

NARDA

NARDA NBM-550 Manual de usuario

NARDA

NARDA FieldMan Manual de usuario

NARDA

NARDA ESM-10 RadMan Mobile Manual de usuario

NARDA

NARDA RadMan 2LT Manual de usuario

NARDA

NARDA L3HARRIS SMARTS II Manual de usuario

NARDA

NARDA EHP-50F Manual de usuario

NARDA

NARDA nbm-520 Manual de usuario

NARDA

NARDA nbm-520 Manual de usuario

NARDA

NARDA 8718 Manual de usuario

NARDA

NARDA SignalShark 3310 Manual de usuario

NARDA

NARDA nbm-520 Manual de usuario

NARDA

NARDA EFA-200 Manual de usuario

NARDA

NARDA SRM-3000 Manual de usuario

NARDA

NARDA AMS-8063 Series Manual de usuario

NARDA

NARDA PMM PL-01 Manual de usuario

NARDA

NARDA NBM-550 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
