MRC PM-9100 Manual de usuario

PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION

3, Hagavish st. Israel 58817 Tel: 972 3 5595252, Fax: 972 3 5594529 [email protected]

MRC.VER.02-11.10

INSTRUCTION MANUAL FOR

PM-9100

Dual & Differential Input

TABLE OF CONTENTS

1. FEATURES...............................................................

2. SPECIFICATIONS...................................................... 1

2-1 General Specifications......................................... 1

2-2 Electrical Specifications.......................................

3. FRONT PANEL DESCRIPTION....................................

3-1 Display.............................................................4

3-2 Power Off/On Button........................................

3-3 Hold Button......................................................4

3-4 Zero Button.................................................. 4

3-5 " MAX./MIN. " Button........................................4

3-6 Unit Button............... 4

3-7 P1 input socket................................................

3-8 P2 input socket................................................

3-9 RS-232 Output Terminal...................................

3-10 Battery Compartment/Cover.............................. 4

3-11 PLu

/quick coupler...........................................

4. MEASURING PROCEDURE.........................................

5. AUTO POWER OFF DISABLE......................................6

6. RS232 PC SERIAL INTERFACE................................... 7

7. BATTERY REPLACEMENT..........................................

1. FEATURES

* Dual & differential input, 2000 mbar max. range.

* Application : Industrial, laboratory, heating,

ventilation, medical hospital, used for dry, non-corrosive and

non-ionic air and gas only. Liquid is prohibited.

* Sensor is built inside the housing.

* Single lugs for pipe connection.

* 8 kind display units ( mbar, psi, Kg/cm 2 mm Hg,　

inch Hg, meter HF2 , inch HF2 , Atmosphere ) select　　

by push button on the front panel

* Auto shut off saves battery life.

* Zero button on the front panel, easy to offset the

zero value.

* Microprocessor circuit assures maximum possible

accuracy, provides special functions and features,

* Super large LCD display with contrast adjustment

for best viewing angle.

* Records maximum & minimum readings with recall.

* Data Hold function for stored the desired value on

display.

* Built-in low battery indicator.

* RS232 PC serial interface, can match the personal

computer used as the Data Logger, Recorder.... &

other modern pressure measuring system.

IFI

ATI

2-1 General Specifications

Circuit Microprocessor LSI circuit.

Display 61 mm x 34 mm supper large LCD

display. 15 mm ( 0.6" ) digit size.

Display units mbar, psi, Kg/cm 2 mm Hg, inch Hg,　

meter HF2 , inch HF2 , Atmosphere.　　

Function Dual & differential input, data hold,

zero/relative, memory.

Zero adjust Push button on the front panel.

Sensor * Sensor is built inside the housing.

* Piezoelectric sensor.

* Used for dry, non-corrosive and

non-ionic air and gas only.

Liquid is prohibited.

Data hold By push button.

Data record Record maximum & minimum readings.

Data output RS 232 PC serial interface.

Sampling time Approx. 0.8 second.

Power off Auto shut off, saves battery life or manual off

by push button.

Operating 0 to 50 蚓( 32 to 122 蚌).

temperature

Operating Less than 80% R.H.

humidity

Power supply 006P DC 9V battery ( heavy duty ).

Power current Approx. DC 6.0 mA.

Weight 345 g/0.76 LB .

Dimension 180 x 72 x 32 mm ( 7.1 x 2.8 x 1.3 inch ).

Accessories * Instruction manual......................

1 PC.

included * Hard carryin

case....................... 1 PC.

* PLu

for quick coupler.................

2 PCs.

Optional * Data acquisition software

accessories ( Windows version )........SW-U101-WIN

* RS232 cable.................. UPCB-01

2-2 Electrical Specifications

Unit Max. range Resolution

mbar 2000 mbar 1 mbar

psi 29 psi 0.02 psi

Kg/cm 2　2.040 Kg/cm 2　0.001 Kg/cm 2　

mm Hg 1500 mm Hg 1 mm Hg

inch Hg 59.05 inch Hg 0.05 inch Hg

meter HF2　20.40 meter HF2　0.01 meter HF2　

inch HF2　802 inch HF2　0.5 inch HF2　

Atmosphere 1.974 Atmosphere 0.001 Atmosphere

Unit Max. range Accuracy

mbar 2000 mbar 2 % F. S.

psi 29 psi

Kg/cm 2　2.040 Kg/cm 2　

Note :

mm Hg 1500 mm Hg

* 23 5 蚓.

inch Hg 59.05 inch Hg

* F.S. : full scale

meter HF2　20.40 meter HF2　

* Included linearity,

inch HF2　802 inch HF2　

hysteresis and

Atmosphere 1.974 Atmosphere

repeatability

Remark

Measuring Display unit

unit

mbar m Bar

psi Psi

Kg/cm 2　Kg /cm 2　

mm Hg mm /Hg

inch Hg in/Hg

meter HF2　m HF2　

inch HF2　inch HF2　

Atmosphere ATP

3. FRONT PANEL DESCRIPTION

Fig. 1

3-1 Display 3-7 P1 input socket

3-2 Power Off/On Button 3-8 P2 input socket

3-3 Hold Button 3-9 RS-232 Output

3-4 Zero Button Terminal

3-5 " MAX./MIN. " Button 3-10 Battery Compartment

3-6 Unit Button /Cover

3-11 PLug/ quick coupler

MEASURING PROCEDURE

1)Power on the meter by pressing the " Power Off/On

Button " ( 3-2, Fig. 1 ).

2)Select the desired temperature units ( mbar, psi, Kg/cm 2　

mm Hg, inch Hg, meter HF2 , inch HF2 , Atmosphere )　　

by pushing the " Unit Button " ( 3-6, Fig. 1 ).

3)Zero adjusting

Adjust the display reading to zero value by pushing

the " Zero Button " ( 3-4, Fig. 1 )

4)Install the measuring pipe to " Plug/quick coupler "

( 3-11, Fig. 1 ).

5)The meter is build the two input socket ( P1 input socket,

P2 input socket) for accepting the differential pressure

input.

Connecting the pipe along the " Plug " ( 3-11, Fig. 1) to

" P1 input socket " ( 3-7, Fig. 1 ) only

" P2 input socket " ( 3-8, Fig. 1 ) only

Both P1 & P2 input socket

The LCD will show the measuring pressure value.

Note :

If the P1 pressure > P2 pressure, the display will

get positive reading.

If the P1 pressure < P2 pressure, the display will

get negative reading.

6)Data Hold

* During the measurement, pressing the " Hold Button "

( 3-3, Fig. 1 ) will freeze the measured value & the LCD

will show " HOLD " symbol.

* Press the " Hold Button " again to cancel the data hold

function. 5

7)Data Record ( Maximum, Minimum reading )

* The DATA RECORD function displays the maximum

and minimum readings. To start the DATA RECORD

function, press the " MAX./MIN. Button " ( 3-5, Fig. 1 )

once. " REC " symbol will appear on the LCD display.

* With the " REC " symbol on the display :

(a) Press the " MAX./MIN. Button " ( 3-5, Fig. 1 )

once, the " Max " symbol along with the maximum

value will appear on the display.

(b) Press the " MAX./MIN. Button " again, the " Min "

symbol along with the minimum value will appear

on the display.

" MAX./MIN. Button " continuously for at least 2

seconds. The display will revert to the current reading.

8)For quick measurement, follow the procedures

shown below :

Main procedures :

POWER

ZERO ADJUS

DETERMINE UNI

Optional measurin

procedures :

DATA HOLD MEMORY RECORD RS232 OUTPUT

Max., Min.

Power mana

ement

AUTO POWER OFF or MANUAL POWER OFF

(Not activated durin

Memory Record Selection) 6

5. AUTO POWER OFF DISABLE

The instrument has built-in " Auto Power Shut-off " in

order to prolong battery life. The meter will switch off

automatically if none of the buttons are pressed within 10

min.

To de-activate this feature, Select the memory record

function during measurement, by pressing the " MAX./MIN.

Button " ( 3-5, Fig. 1 ).

6. RS232 PC SERIAL INTERFACE

The instrument features an RS232 output via 3.5 mm

Terminal ( 3-9, Fig. 1 ).

The connector output is a 16 digit data stream which

can be utilized to the user's specific application.

An RS232 lead with the following connection will

be required to link the instrument with the PC

serial input.

Meter PC

(3.5 mm jack plug) (9W 'D" Connector)

Center Pin..................................

Pin 2

Ground/shield................................Pin 5

The 16 digit data stream will be displayed in the

following format :

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Each digit indicate the following status :

D0 End Word

D1 to D8 Display readin

, D1=LSD, D8=MSD

For example : If the display readin

is 1234, the

D8 to D1 is 0000123

D9 Decimal Point ( DP ) for Upper display.

0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP

D10 Polarity 0 = Positive 1 = Ne

ative

D11 & D12 Annunciator for Upper Display

mbar = 86 psi = 23

mm Hg = 78 inch Hg = 80

inch HF2 = 25　Kg/cm 2= 77　

Atmosphere = 26 meter HF2 = 79　

D13 1

D14 4

D15 Start Word

7. BATTERY REPLACEMENT

1)When the left corner of LCD display show " LBT ",

it is necessary to replace the battery. However,

in-spec measurement may still be made for several

hours after low battery indicator appears before the

instrument become inaccurate.

2)Slide the Battery Cover ( 3-10, Fig. 1) away from the

instrument and remove the battery.

3)Install a 9 V battery (PP3 type) and replace the cover.
