MP-Man MPQCG77 Manual de usuario

EN USER MANUAL

For Model No.

MPQCG77

Tablet of Contents

Specifications………………………………………………………………….

Tablet Parts……………………………………………………………………

Getting started………………………………………………………………...

How to use TF card …………………………………………………………

How to connect to PC ………………………………………………………

Connection to Internet………………………………………………………..

Camera……………………………………………………………………….

Trouble Shooting…………………………………………………………….

Warnings…………………………………………………………….……

Specifications

Display: 7 inch HD (1024x600) Capacitive multi-touch screen

CPU: Spreadtrum&SC7731G Quad Cortex A7@ 1.3GHz

RAM: 512M/1 GB DDR III

GPU Mali-400 mp2

Internal Storage:4GB/ 8GB

Expansion Memory: Micro SD card up to 32GB (not supplied)

Built-In Wireless: 802.11b/g/n

SIM 3G module

Built-in Bluetooth (2.0 +EDR)

Built-in GPS (GPS + AGPS)

FM Radio

Double camera: front 0,3 Mpixels and back 2 Mpixels

AC Adapter: DC 5V-2A

Operating System: Android 5.1

Tablet Part

Name

function

Volume +

Press to increase the volume

Volume -

Press to decrease the volume

Power

Keep pressed to turn on/off the tablet; shortly

press to activate standby

Reset

Reset the system in case of device stuck and

restart

Earphone jack

Connect earphone to this standard 3.5mm jack

Micro USB port/OTG

port

PC connection / Peripheral connection through

HOST cable (for example keyboard, USB

device)

Back camera

2 Mpixels camera

Front camera

0,3 Mpixels camera

Micro SD input

Insert a micro SD card (up to 32GB)

SIM slot

SIM card port

Getting Started

Battery Charging

The tablet has a built-in rechargeable Li-polymer battery.

1. To charge connect the AC power adapter to the DC 5V jack on the

right side of the tablet.

2. The battery icon shows the battery status and charging status

3. The tablet can be used even if the battery is being charged.

the above icons indicate the different level of electricity left in the battery

4. no replacement of battery without authorization, or the explosion

hazard might happen.

5. Recharge it for at least half hour if it has been idle for long time and

fails to start itself.

6. Regularly recharge it at least one time monthly

7. 40°—5°is the optimum temperature for the battery recharging or

the battery performance might deteriorate slightly

Disposal

the battery might contain the polluting material, please give it to the

official recycling-station before disposing the tablet pc, and don’t litter.

Power ON/OFF

ON:

press the button for continuous 5 seconds until the tablet turns

“ON”.

OFF:

1.Press the button for continuous 5 seconds and it will appear

2.Select OK to power off the tablet

Screen Lock

This feature locks the screen, at the same time turn OFF the screen’s

backlight after a few seconds.

Screen locks when:

1. System is idle.

2. Manually activated by pressing the Power button once.

Screen unlock :

Home screen

The Home screen will look similar to the picture below. It is actually five

screens, each of which can have a different layout of icons. To switch

between screens, simply slide your finger left or right across the display.

The status bar and navigation buttons are always visible, no matter

which Home screen you can currently viewing.

The Desktop contains shortcuts to your most-used applications and widgets

Touch the screen icon to quickly search the World Wide Web using Google.

The icon will launch the Application menu.

The status bar displays system information, such as current time, wireless

connectivity and battery.

Touch to Expand the status bar for more detailed information.

The button moves back one step to the previous menu/page.

The buttons returns immediately to the Android desktop.

The button display a menu of recently opened applications.

Settings Menu

The settings menu allows you to adjust Tablet system configuration.

To change settings:

1. Touch the "Settings" menu icon on the Application menu.The

Settings menu will open.

2. Guide your finger up or down the left side of the screen to scroll through the

list of available categories.

3. Touch a category title to view further options on the right side of the screen.

Wi-Fi - Connect to /disconnect from wireless networks, view connection status

Data usage - Enable / disable mobile data, view current usage, set mobile data limit (note:

this function is available only on devices supplied with 3G card)

Sound - Change volume, touch sound, screen lock sounds etc

Display - Change brightness, wallpaper, sleep settings, font size etc

Storage - Manage NAND and Micro SD card, view available capacity etc

Battery - See battery status and powered-on time

Apps - Manage applications, running services etc

Location services - Change approximate location detection, improve search results, GPS

satellites

Security - Change screen lock type, encryption, password, credential storage etc

Language & input Select language, add to the dictionary, edit on-screen keyboard settings,

vocal search, etc

Backup & reset - Backup & restore data, perform factory reset, etc

Date & time - Set date, time zone, time, clock format etc

Turn on/off – automatic turning on / off settings

Accessibility - Set up large text, auto-rotate screen, speak password etc

Developer options - Advanced functions for Android developers - debugging, HDCP check

etc

About telephone - Information about your Android device

Telephone function

1. in off mode insert SIM card in the slot.

2. after inserting SIM card turn on the tablet and wait to display the cell reception icon.

3. once the connection with the operator open the application and dial the

number.
