MP-Man MPQC30I Manual de usuario
DE Bedienungsanleitung
For Model No.
MPQC1040i
For Model No.
MPQC30i EN USER MANUAL
Attention:
This handbook contains important security measures and the correct use
of the product information, in order to avoid accidents. Pls make sure to
reading the manual carefully before use the device.
1. Please don’t be in high temperature, moisture or very dust place
2. Please don’t be in high temperature, Especially in summer don't put
the device in the car when Windows closed.
Avoid fall or Violent collision of the device, don’t make the TFT
display screen were violent tremor, This could cause TFT display
screen abnormal or damage.
Please choose the appropriate volume, Use headphones shoulds
not be too big volume, If feel tinnitus, Lower the volume or stop using
it
please charge In the following condition,
4 The battery power ICONS shows have no power
5 The system automatically shut off, startup after power off soon
6 Operation buttons no response
7 The machine that the top right corner show red icons
1. When the device in the format or ongoing upload and downloa
d file, please don't suddenly disconnect, This could cause appli
cation error.
2. For those who because of damage to the product, repair, or other
causes of erased the memory, The company shall not be liable for
any responsibility, please follow the user manual for the
standardized operation to use the device.
3. Don’t disassemble the product, don’t use alcohol、Thinner or
benzene to scrubbing products
4. Don't use the device one of the place of prohibit to use electronic
equipment in regional (such as the plane)
5. Please don't using the Tablet PC when you in driving or walking
down the street,
6. USB just only be used for data transmission
Tablet Part
Name
function
1 Reset
press RESET button,Tablet will force to
shutdown
2 MICRO SD card slot
To insert your TF card
3 HDMI Jack
Mini HDMI TV output to connect an external
screen.
4 Earphone Jack
To connect your earphone
5 Micro USB
Connect to a computer via a USB cable to
transfer data (music,videos,photo,ect.),USB
OTG,supports mouse, Keyboard, USB flash
disk,etc,with a converting cable.
6 Volume -
Press to decrease the volume
7 Volume +
Press to increase the volume
8 Power and lock Key
Hold and press to turn on or turn off the
unit,Briefly press to turn on or turn off the
screen.
Getting Started
Battery Charging
The tablet has a built-in rechargeable Li-polymer battery.
1. To charge connect the AC power adapter to the USB jack on the
right side of the tablet.
2. The battery icon shows the battery status and charging status
3. The tablet can be used even if the battery is being charged.
the above icons indicate the different level of electricity left in the battery
4. no replacement of battery without authorization, or the explosion
hazard might happen.
5. Recharge it for at least half hour if it has been idle for long time and
fails to start itself.
6. Regularly recharge it at least one time monthly
7. 40°—5°is the optimum temperature for the battery recharging or
the battery performance might deteriorate slightly
Disposal
the battery might contain the polluting material, please give it to the
official recycling-station before disposing the tablet pc, and don’t litter.
Power ON/OFF
ON:
press the button for continuous 5 seconds until the tablet turns
“ON”.
OFF:
1.Press the button for continuous 5 seconds and it will appear
2.Click Power off to power off the tablet
Screen Lock
This feature locks the screen, at the same time turn OFF the screen’s
backlight after a few seconds.
Screen locks when:
1. System is idle.
2. Manually activated by pressing the Power button once.
Screen unlock :
Home screen
The Home screen will look similar to the picture below. It is actually five
screens, each of which can have a different layout of icons. To switch
between screens, simply slide your finger left or right across the display.
The status bar and navigation buttons are always visible, no matter
which Home screen you can currently viewing.
The Desktop cn contains shortcuts to your most-used applications and widgets
Touch the screen icon to quickly search the World Wide Web using Google.
The icon will launch the Application menu.
The status bar displays system information, such as current time and battery.
Touch to Expand the status bar for more detailed information.
The button moves back one step to the previous menu/page.
The buttons returns immediately to the Android desktop.
The button display a menu of recently opened applications.
The button decrease the volume.
The button increase the volume,
Settings Menu
The settings menu allows you to adjust Tablet system configuration.
To change settings:
1. Touch the "Settings" menu icon on the Application menu.The
Settings menu will open.
2. Guide your finger up or down the left side of the screen to scroll through the
list of available categories.
3. Touch a category title to view further options on the right side of the screen.
Wi-Fi - Connect to /disconnect from wireless networks, view connection status
Data usage - Enable / disable mobile data, view current usage, set mobile data limit (note:
this function is available only on devices supplied with 3G card)
Sound - Change volume, touch sound, screen lock sounds etc
Display - Change brightness, wallpaper, sleep settings, font size etc
Storage - Manage NAND and Micro SD card, view available capacity etc
Battery - See battery status and powered-on time
Apps - Manage applications, running services etc
Accounts & sync - Switch synchronization on /off, manage accounts etc
Location services - Change approximate location detection, improve search results
Security - Change screen lock type, encryption, password, credential storage etc
Language & input Select language, add to the dictionary, edit on-screen keyboard settings,
vocal search, etc
Backup & reset - Backup & restore data, perform factory reset, etc
Date & time - Set date, time zone, time, clock format etc
Accessibility - Set up large text, auto-rotate screen, speak password etc
Developer options - Advanced functions for Android developers - debugging, HDCP check
etc
About tablet - Information about your Android device
How to Use TF card
1. Insert the TF card into the TF card slot. Gently push TF card into slot
until it clicks into place.
2. A prompt will be seen on the screen saying “ Preparing SD card “
Removing TF card
1. Close all applications and documents which have been opened from
the TF card.
2. Select “Setting” and find “ Storage” then click “Unmount SD card”.
3. A prompt will be seen on the screen saying “ SD card safe to remove”
4. Gently press the TF card to remove and pull out the TF card.
Note: Insert the TF card in correct position, otherwise it will damage the
card and the slot.
Software Keyboard
The tablet has a software keyboard which automatically show up
when you tap the place on screen where text or number are to be
entered.
