Moxa Technologies EtherDevice EDS-2016-ML Series Manual de usuario

P/N: 1802020160010

*1802020160010*

EDS-2016-ML Series

Quick Installation Guide

Moxa EtherDevice Switch

Version 1.0, November 2019

Technical Support Contact Information

www.moxa.com/support

Moxa Americas:

Toll

-free: 1-888-669-2872

Tel:

1-714-528-6777

Fax:

1-714-528-6778

Moxa China (Shanghai office):

Toll

-free: 800-820-5036

Tel:

+86-21-5258-9955

Fax:

+86-21-5258-5505

Moxa Europe:

Tel:

+49-89-3 70 03 99-0

Fax:

+49-89-3 70 03 99-99

Moxa Asia-Pacific:

Tel:

+886-2-8919-1230

Fax:

+886-2-8919-1231

Moxa India:

Tel:

+91-80-4172-9088

Fax:

+91-80-4132-1045



- 2 -

Overview

The EDS-2016-ML Series industrial Ethernet switches have 16 10/100M

ports and up to two optical fiber ports with SC/ST connector type

options.

The EDS-2016-ML provides 12/24/48 VDC redundant power inputs, and

the switches are available with a standard operating temperature range

from -10 to 60°C, or with a wide operating temperature range from -40

to 75°C. The switches are rugged enough to operate reliably in harsh

industrial environments.

To provide greater versatility for use with applications from different

industries, the EDS-2016-ML also allow users to enable or disable

broadcast storm protection, Quality of Service (QoS) function, and port

break alarm function with DIP switches on the outer panel.

The EDS-2016-ML switches can be easily installed with DIN-Rail

mounting as well as distribution boxes. The DIN-rail mounting

capability and IP30 metal housing with LED indicators make the plug-

and-play EDS-2016-ML switches reliable and easy to use.

NOTE

Throughout this

Quick Installation Guide, we use

EDS

as an

abbreviation for Moxa EtherDevice Switch:

EDS = Moxa EtherDevice Switch

ATTENTION

This device complies with part 15 of FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may c

ause

undesired operation.

Package Checklist

Your EDS is shipped with the following items. If any of these items are

missing or damaged, please contact your customer service

representative for assistance.

•Moxa EtherDevice™ Switch

•Quick installation guide (printed)

•Warranty card

•Protective caps for unused ports

- 3 -

Features

High Performance Network Switching Technology

•10/100BaseT(X) auto-negotiation speed, full/half duplex mode,

auto MDI/MDI-X connection, and 100BaseFX (SC/ST type,

Multi/Single mode).

•IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and

100BaseFX.

•IEEE 802.1p for Quality of Service (QoS) traffic prioritized function.

•Store-and-forward switching process type.

Industrial-grade Reliability

•Power failure, port break alarm by relay output

•Redundant dual DC power inputs

•Broadcast storm protection to prevent network devices from

crashing

Rugged Design

•Operating temperature range from -10 to 60°C, or extended

operating temperature from -40 to 75°C for “-T” models

•IP30, rugged high-strength case

•DIN-rail or panel mounting ability

WARNING

The

power for this product is intended to be supplied by a

Listed Power Supply, with output marked LPS, and rated to

deliver 12 to 48 VDC at a maximum

of 0.62 A.

The DC

jack should be used with an LPS unit that is rated to

deliver 12 to 48 VDC at a minimum of 1.1A. The product should

not be disassembled by operators or service people.

- 4 -

Panel Layout of EDS-2016-ML (Standard type)

1. Grounding screw

2. Terminal block for power input

(PWR1, PWR2) and relay output

3. DIP switch

4. Power input PWR1 LED

5. Power input PWR2 LED

6. Fault LED

7. Port number

8. 10/100 BaseT(X) Port

9. TP port’s 100 Mbps LED

10. TP port’s 10 Mbps LED

11. Model name

- 5 -

Panel Layout of EDS-2016-ML (SC type)

1. Grounding screw

2. Terminal block for power input

(PWR1, PWR2) and relay output

3. DIP switch

4. Power input PWR1 LED

5. Power input PWR2 LED

6. Fault LED

7. Port number

8. 10/100 BaseT(X) Port

9. TP port’s 100 Mbps LED

10. TP port’s 10 Mbps LED

11. 100BaseFX Port

12. FX port’s 100 Mbps LED

13. Model name

- 6 -

Panel Layout of EDS-2016-ML (ST type)

1. Grounding screw

2. Terminal block for power input

(PWR1, PWR2) and relay output

3. DIP switch

4. Power input PWR1 LED

5. Power input PWR2 LED

6. Fault LED

7. Port number

8. 10/100 BaseT(X) Port

9. TP port’s 100 Mbps LED

10. TP port’s 10 Mbps LED

11. 100BaseFX Port

12. FX port’s 100 Mbps LED

13. Model name

- 7 -

Mounting Dimensions

EDS-2016-ML Series

EDS-2016-ML Fiber Series

- 8 -

DIN-Rail Mounting

There are two options for DIN-rail mounting that can be used on an

EDS. Option 1 is the default type when the product is shipped.

Option 1 (Default):

When shipped, the metal DIN-rail mounting kit is fixed to the back

panel of the EDS. Mount the EDS on the corrosion-free mounting rail

that adheres to the EN 60715 standard.

Suggested Installation Method

TEP 1:

Insert the upper lip of the DIN

rail kit into the mounting rail.

TEP 2:

Press the device towards the

mounting rail until it snaps into

place.

Suggested Removal Method

STEP 1:

Pull down the latch on the DIN

rail

kit with a screwdriver.

STEP 2:

Slightly pull the device forward

and lift up to remove it from the

mounting rail.

Option 2 (when side cabling is needed):

The metal DIN-rail mounting kit can be fixed to the side panel (mold

side) of the EDS (horizontal or vertical). Mount the EDS on the

corrosion-free mounting rail that adheres to the EN 60715 standard.

- 9 -

Suggested Installation Method

STEP 1:

Detach the metal DIN-rail mounting kit from the back panel and attach

it to the side panel (mold side) in either the horizontal or vertical

direction as indicated in the figure below.

STEP 2:

Insert the upper lip of the DIN

-rail kit

into the mounting rail.

STEP 3:

Press the device towards the mounting

rail until it snaps into place

Suggested Removal Method

STEP

Pull down the latch on the DIN

-rail kit

with a screwdriver.

STEP 2:

Slightly pull the device forward and lift

up to remove it from the mounting rail.

NOTE

Screws that are used to fix the DIN-rail kit on the EDS should

be securely fastened before

mounting on the mounting rail.

Please make sure that if you remove the DIN

-rail, it must be

securely fastened when it is reattached.

- 10 -

Wall Mounting (optional)

For some applications, you will find it convenient to mount EDS on the

wall, as illustrated below.

STEP 1:

Remove the aluminum DIN-Rail attachment plate from EDS’s rear

panel, and then attach the wall mount plates, as shown in the diagram

below.

EDS-2016-ML Series

EDS-2016-ML Fiber Series

STEP 2:

Mounting EDS

on the wall requires 4 screws. Use the

switch, with wall mount plates attached, as a guide

to mark the correct locations of the 4 screws. The

heads of the screws should be less than 6.0 mm in

diameter, and the shafts should be less than 3.5 mm

in diameter, as shown in the figure at the right.

NOTE

Before tightening screws into the wall, make sure the screw

head and shank size are suitable by inserting th

e screw into

one of the keyhole

-shaped apertures of the Wall Mounting

Plates.

Do not screw the screws in all the way—leave about 2 mm to allow

room for sliding the wall mount panel between the wall and the screws.

STEP 3:

Once the screws are fixed in the

wall, insert the four screw heads

through the large parts of the

keyhole

-shaped apertures, and

hen slide EDS downwards, as

indicated. Tighten the four

screws for added stability.

WARNING

External metal parts can be hot. Take necessary precautions if

it is necessary to touch.
