MGate 5103

Quick Installation Guide

Edition 1.0, December 2017

Technical Support Contact Information

www.moxa.com/support

Moxa Americas:

Toll

-free: 1-888-669-2872

Tel:

1-714-528-6777

Fax:

1-714-528-6778

Moxa China (Shanghai office):

Toll

-free: 800-820-5036

Tel:

+86-21-5258-9955

Fax:

+86-21-5258-5505

Moxa Europe:

Tel:

+49-89-3 70 03 99-0

Fax:

+49-89-3 70 03 99-99

Moxa Asia-Pacific:

Tel:

+886-2-8919-1230

Fax:

+886-2-8919-1231

Moxa India:

Tel:

+91-80-4172-9088

Fax:

+91-80-4132-1045



- 2 -

Overview

The MGate 5103 is an industrial Ethernet gateway for Modbus

RTU/ASCII/TCP, EtherNet/IP, and PROFINET network communications.

Package Checklist

Before installing the MGate 5103, verify that the package contains the

following items:

•1 MGate 5103 gateway

•1 serial cable: DBL-RJ45F9-150

•Documentation

•Quick installation guide (printed)

•Warranty card

Please notify your sales representative if any of the above items is

missing or damaged.

Optional Accessories (can be purchased separately)

•CBL-F9M9-150: DB9-female-to-DB9-male serial cable, 150 cm

•CBL-F9M9-20: DB9-female-to-DB9-male serial cable, 20 cm

•CBL-RJ45SF9-150: RJ45-to-DB9-female shielded serial cable, 150

•ADP-RJ458P-DB9F: DB9-female-to-RJ45 connector

•ADP-RJ458P-DB9F-ABC01: DB9-female-to-RJ45 connector

•Mini DB9F-to-TB: DB9-female-to-terminal-block connector

- 3 -

Hardware Introduction

LED Indicators

LED

Color

Description

Ready

Off

Power is off or a fault condition exists

Green

Steady: Power is on, and the MGate is

functioning normally

Red Steady: Power is on, and the MGate is booting

Blinking slowly: Indicates an IP conflict, or the

DHCP or BOOTP server is not responding

properly

Flashing quickly: the microSD card failed

MB/EIP

Off

Modbus: No communication with Modbus device

EtherNet/IP: No I/O data exchange

Green

(Blinking)

Modbus: Communication in progress

EtherNet/IP: I/O data is exchanging

Red

(Blinking)

Communication error

When MGate 5103 acts as Modbus

Client/Master:

1. Slave device returned an error (exception)

2. Received a frame error (parity error,

checksum error)

3. Timeout (slave device is not responding or

TCP connection timed out)

When MGate 5103 acts as Modbus

Server/Slave:

1. Received invalid function code

2. Master accessed invalid register address or

coil addresses

3. Received frame error (parity error, c

hecksum

error)

When MGate 5103 acts as EtherNet/IP adapter:

1. Refuses connection due to incorrect

configuration

Off

No connection with PROFINET I/O controller

Green

(Blinking)

PROFINET I/O is connected and the

controller is

in RUN mode

Red

(Blinking)

PROFINET I/O is connected, but the controller is

in STOP mode

- 4 -

Dimensions

Unit: mm (inch)

Reset Button

Restore the MGate to factory default settings by using a pointed object

(such as a straightened paper clip) to hold the reset button down until the

Ready LED stops blinking (approximately five seconds).

Pull-up, Pull-down, and Terminator for RS-485

Beneath the MGate 5103’s top cover, you will find DIP switches to adjust

each serial port’s pull-up resistor, pull-down resistor, and terminator.

Pull-up

resistor

Pull-down

resistor

Terminator

1 kΩ

120 Ω

OFF

150 kΩ*

–*

*Default

Hardware Installation Procedure

1. Connect the power adapter. Connect the 12-48 VDC power line or

DIN-rail power supply to the MGate 5103’s terminal block.

2. Use a serial cable to connect the MGate to the Modbus device.

3. Use an Ethernet cable to connect the MGate to the PROFINET IO

controller.

4. The MGate 5103 is designed to be attached to a DIN rail or mounted

on a wall. For DIN-rail mounting, push down the spring and properly

attach it to the DIN rail until it “snaps” into place. For wall mounting,

install the wall-mounting kit (optional) first and then screw the device

onto the wall.

The following figure illustrates the two mounting options:

- 5 -

Software Installation Information

The MGate 5103 also supports login via a web browser.

Default IP address: 192.168.127.254

Default account: admin

Default password: moxa

Pin Assignments

Modbus Serial Port (Male DB9)

Pin RS-232

RS-422/

RS-485 (4W)

RS-485 (2W)

DCD

TxD-(A)

–

RXD

TxD+(B)

–

TXD

RxD+(B)

Data+(B)

DTR

RxD-(A)

Data-(A)

GND

DSR

–

RTS

–

CTS

–

*Signal ground

Ethernet Port (RJ45)

Signal

Tx+

Tx-

Rx+

Rx-

Power Input and Relay Output Pinouts

- 6 -

V2+ V2-

V1+ V1-

Shielded

Ground

Power

Input 2

Power

Input 2

N.O. Common

N.C.

Power

Input 1

Power

Input 1

Specifications

Power Requirements

Power Input

12 to 48 VDC

Power Consumption

455 mA @ 12 VDC, 125 mA @ 48 VDC

Operating Temperature

Standard models:

0 to 60°C (32 to 140°F)

Wide temp. models:

-40 to 75°C (-40 to 167°F)

Ambient Relative Humidity

5 to 95% RH

Dimensions

36 x 105 x 140 mm (1.42 x 4.13 x 5.51 in)

Reliability

Alert Tools

Built-in buzzer and RTC

MTBF

859,422 hrs.

1. DEMKO Certification number: 13 ATEX 1307610X

IEC Certification Number: IECEx UL 13.0051X;

2. Ambient Temperature Range:

0°C to 60°C (for models without suffix –T)

-40°C to 75°C (for models with suffix –T only)

3. Certification String: Ex nA nC IIC T3 Gc

4. Standards Covered: EN 60079-0:2013+A11:2013/IEC 60079-0 6th

Ed. AND EN 60079-15:2010/IEC 60079-15 4th Ed.

5. The conditions of safe use:

a. Ethernet Communications Devices are intended for mounting in a

tool-accessible IP54 enclosure and use in an area of not more

than pollution degree 2 as defined by IEC/EN 60664-1.

b. Conductors suitable for use in an ambient temperature greater

than 86°C must be used for the power supply terminal.

c. A 4mm2conductor must be used when a connection to the

external grounding screw is utilized.

d. Provisions shall be made, either in the equipment or external to

the equipment, to prevent the rated voltage from being exceeded

by the transient disturbances of more than 140% of the

peak-rated voltage.

Terminal block (plug matched with socket): rated at 300 V, 15 A, 105°C,

12-28 AWG (0.0804 mm2to 3.31 mm2) wire size, torque value 4.5 lb-in

(0.509 N-m). The input terminal cable size: 14 AWG (2.1 mm2).

- 7 -

ATTENTION

For installation

s in hazardous locations (Class 1, Division 2):

These devices are to be installed in an enclosure with

tool-removable cover or door, suitable for the environment.

NOTE

This equipment is suitable for use in Class

1, Division

2, Groups A,

B, C, D or nonhazardous locations only

WARNING

EXPLOSION HAZARD

Do not disconnect

the equipment unless the power has been

switched off, or the area is known to be nonhazardous.

WARNING

EXPLOSION HAZARD

The s

ubstitution of any components may impair suitability for

Class 1, Division 2.

WARNING

EXPOSURE TO SOME CHEMICALS MAY DEGRADE THE SEALING

PROPERTIES OF MATERIALS USED IN THE FOLLOWING DEVICE:

Sealed Relay Device U21.

Moxa Inc.

Fl. 4, No. 135, Lane 235, Baoqiao Rd.

Xindian Dist., New Taipei City, 23145

Taiwan, R.O.C.
