Motorola MB8600 Manual de usuario

Model MB8600

DOCSIS 3.1

Cable Modem

Quick Start

Packaged with your modem

Power Cube

Coax Wrench

Ethernet Cable

Velcro®Cable Tie

Para una Guía de Inicio Rápido en español, por

favor vaya a

www.motorolanetwork.com/MB8600ir

Let’s get started

If you don’t have cable modem service, please order that

from your cable service provider. Your MB8600 supports

DOCSIS 3.1, the fastest cable modem service standard. Your

MB8600 also supports all speeds of any DOCSIS 3.0 services.

Now connect your modem as shown on the next panel.

Connecting to a Coax Cable

On the next panel you’ll need to connect your

modem to a “live” coax cable. Sometimes a cable

will already be available. Sometimes there’s a coax

wall jack available, and you connect to the jack

with a coax cable. Your modem can also share a

coax cable attached to a TV by using a coax

splitter. Please note that a splitter sometimes

reduces a cable modem’s speed; so if you need to

use a splitter, use a 2-way splitter whose top

frequency is at least 1,000 MHz.

RESET button

ETHERNET (LAN)

Connect this port to a

computer. Alternatively, you

can connect to a WiFi router -

see

If You Want to Connect a

Router

, below. (In the unlikely

event that you are using port

bonding, please remove the

yellow panel label and see

www.motorolanetwork.com/31

for details.)

COAX

Connect a “live” coax

cable to the modem’s COAX

connector as discussed

above. (Tighten the nut so it’s

finger tight. You may

want to use the supplied

wrench. Make the connection

snug but not over-tight.)

ON/OFF button

POWER

Connect the supplied power

cube between the power jack

and an electrical outlet.

Prepare to activate

By now you should have:

•Subscribed to cable Internet service.

•Connected your cable modem.

•Powered up your cable modem. To do this, the On/Off

button needs to be On. Wait for the online connection light

( for 3.0, or for 3.1) to stop flashing and remain solidly

lit. This may take up to 15 minutes.

You should have a recent cable bill handy because it has your

account number and you’ll probably need that.

If you’re asked for information about your cable modem, you

can find this on the label on the bottom of the modem.

Activate

For some service providers, you activate by calling them.

Many service providers including Comcast and Cox prefer

that you activate by first opening the Web browser of a

computer that’s plugged into the MB8600’s Ethernet port.

Once you’ve opened the browser, try to go to

www.motorola.com .This should bring you to the service

provider’s activation page.

For Comcast XFINITY Users Only:

If the activation page does not appear, please go to

www.xfinity.com/activate for more information and to

activate your modem.

Here is a list of phone numbers for some major cable

service providers. (Note that this list is subject to

change.)

Comcast

1 (800) XFINITY

Cox

1 (877) 206-4210

Bright House (Spectrum)

1 (855) 222-0102

Cable One

1 (855) 692-4113

Charter Spectrum

1 (855) 757-7328

MediaCom

RCN

1 (844) 987

-3260

1 (800) 746-4726

Suddenlink

1 (877) 794-2724

Time Warner (Spectrum)

WOW!

1 (855) 707

-7328

1 (800) 343-2076

Once your MB8600 is activated either online or by

phone, your service provider will provision your

MB8600 service. Typically this takes less than 5

minutes, but in some cases this may take 30 minutes

or longer to complete.

Once you have activated, you should have Internet access for

whatever’s plugged into your cable modem. Congratulations!

If your cable modem is NOT working, see Troubleshooting

Tips below.

Note: You can connect this device to a WiFi

router, computer, HDTV, game station, or other

Ethernet-capable device. This product does not

include a router, WiFi, or telephone capability.

If You Want to Connect a Router

Most users will connect a WiFi router to the MB8600. This

connection may be made initially, before activating the

cable modem, or it may be done after the cable modem

has been activated from a PC. A wireless router lets

multiple devices (computers, smartphones, tablets, video

devices, game stations…) share your cable modem’s

Internet connection, either wirelessly or through a direct

Ethernet connection.

1. The cable modem and the router should both be

powered off.

2. Plug one end of the cable modem’s Ethernet cable into

the Ethernet jack of your modem, and plug the other

end of the cable into the router’s WAN port. (You may

need to disconnect the cable from your computer

first.)

3. Power-up the cable modem. Wait for the ONLINE light

( or ) to be solidly lit.

4. Power-up the router. Wait for the router to complete

its power-up sequence.

5. The LAN light on your modem should be lit to show

the Ethernet connection to your router. Note the color

will be green for a single LAN port and blue for

bonded (two or more LAN ports) connections.

6. Follow your router’s instructions for setting up the

router and connected devices.

If you haven’t already activated your Internet service, do

that now. (See Prepare to Activate on page 5.) Using a

computer or other device connected to the router, try

connecting to the Internet. If it works, Congratulations!

Installation is complete.

MB8600 Lights

LIGHT

COLOR

DESCRIPTION

Power

Green

ON:

Cable modem power on

OFF:

Cable modem power off

Downstream

Green or

Blue

Green

Blinking:

Scanning for DS channel

Green

ON:

Connected on

1 downstream channel

Blue

Blinking:

Negotiating

bonded channel(s)

†

Blue ON:

Bonded with 2 or more

channels

Upstream

Green or

Blue

Green

Blinking:

Ranging in progress

Green

ON:

Connected on 1 channel

Blue

Blinking:

Negotiating bonded

channel(s)

†

Blue ON:

Bonded with 2 or more channels

OFF:

Upstream not connected

Online

Green

Blue

Blinking:

Trying to go online

Green:

Online with DOCSIS 3.0

Blue:

OFF:

Online with DOCSIS 3.1

Offline

LAN

Green

Blue

Blinking:

Ethernet data is flowing

Green:

Ethernet ports linked but not

bonded

Blue:

Ethernet ports linked and

bonded

Rear Panel

Ethernet LAN

port(s)

Green or

Amber

Blinking:

Ethernet data is flowing

Green:

Connected at 1 Gbps

Amber:

Connected at 10 or 100 Mbps

OFF:

No connection

†If a blue Upstream or Downstream light blinks continuously, this indicates

partial service (at least one designated channel has not completed

bonding). You should still get high Internet speeds, but your service

provider may want to know so they can adjust their network.

Troubleshooting Tips

What if I can’t make an Internet connection right after

installation?

•First turn your cable modem off for at least 8 seconds, then

on, to see if that fixes the problem.

•Check the connections you’ve made to your cable modem –

power, Ethernet, and coax. Are those connections good?

•Check that the modem’s power cube is plugged into a live

outlet, and that the Ethernet cable is connected securely.

•Make sure that your coax cable is live. You can check that by

using it with a TV.

•Check that you provided the correct setup information to

your cable service provider.

•Contact your cable service provider to make sure they’ve

turned on your Internet service.

What if my cable modem has been working, and then

stops working?

•First turn your cable modem off for at least 8 seconds, then

on, to see if that fixes the problem.

•If the modem’s lights don’t come on, check that the modem

is getting power from its power cube and that the modem’s

power button is on.

•Check your cable modem cables.

•Check with your service provider. Sometimes there’s a

service outage or some other service issue.

What if I’m getting Internet service but my speed is

disappointing?

•Be sure you know what speed you’re paying for.

•Check the speed with a computer plugged into the modem.

Use one of the tools found when you search the phrase:

broadband speed test.

•No matter who your service provider is, check Comcast

XFINITY’s Internet Minimum System Recommendations here:

https://www.xfinity.com/support/internet/requirements-

to-run-xfinity-internet-service/

•If you get good speed when a computer’s plugged into the

modem, you may have a router problem.

•Some video streaming services get bottlenecked, especially

at busy times like after dinner. See whether you have the

speed problem at less busy times.

•Try connecting your cable modem nearer to where the

coaxial cable comes into your home. This lets you see

whether your home’s cabling is a problem.

•If you’re using a splitter with your cable modem, try the cable

modem without the splitter to see if that helps. If it does, you

may need to get a better splitter, one with a top frequency of

at least 1000 MHz.

•Make sure your computer’s or router’s LAN port supports

gigabit rates (1000BT or GE). The throughput of a single

gigabit Ethernet port is limited to about 940 Mbps. If your

service supports higher speeds, you will need to use bonded

Ethernet ports (LAG) to reach these speeds. See

www.motorolanetwork.com/31

What if I'm told that my cable modem isn't approved for

my cable modem service?

That’s probably not true. Leading cable service providers

have a list of certified cable modems, and you can check the

list for your service provider. You can also find information

about certifications at www.motorolanetwork.com/services

Do you have any other questions? We have lots more

information at www.motorolanetwork.com/mentor

Tabla de contenidos

Otros manuales de Módem de Motorola

Motorola

Motorola SBV5322 SURFBOARD DIGITAL VOICE MODEM - annexe... Manual de lista de piezas

Motorola

Motorola SB6120 - SURFboard - 160 Mbps Cable Modem Manual de usuario

Motorola

Motorola SURFboard SB4000 Manual de usuario

Motorola

Motorola SBG6580 Series Manual de usuario

Motorola

Motorola MT7711 Manual de usuario

Motorola

Motorola CPEI 150 series Manual de usuario

Motorola

Motorola ARRIS SBG6782-AC Manual de usuario

Motorola

Motorola SURFboard SBV5120 Manual de usuario

Motorola

Motorola SURFboard 574808-001-c Manual de usuario

Motorola

Motorola SURFboard SB6121 Guía de solución de problemas

Motorola

Motorola SBG1000 Manual de usuario

Motorola

Motorola SURFboard SBV5122 Instrucciones de montaje

Motorola

Motorola CPEI 25150 Manual de usuario

Motorola

Motorola WMC6300 Manual de usuario

Motorola

Motorola SURFboard SB6182 Manual de usuario

Motorola

Motorola SB5120 - SURFboard - 38 Mbps Cable Modem Manual de usuario

Motorola

Motorola 3460 Fast'R Manual de usuario

Motorola

Motorola V.3400 Manual de usuario

Motorola

Motorola SURFboard SBV5222 Manual de usuario

Motorola

Motorola SBV5121 Manual de usuario

Motorola

Motorola SB5100 - SURFboard - 38 Mbps Cable Modem Manual de usuario

Motorola

Motorola MT8733 Manual de usuario

Motorola

Motorola SB4200 - SURFboard - 38 Mbps Cable Modem Manual de usuario

Motorola

Motorola SB5101 - SURFboard - 30 Mbps Cable Modem Manual de usuario

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario
