Morphy Richards LOX VACUUM CLEANER Manual de usuario

Iox vacuum cleaner

Please read and keep these instructions

getting the best from

your new cleaner...

If your cleaner isn’t picking up as

well as it should, please check

• Dustbags

It is important to empty them when full, otherwise the

performance of the cleaner will be impaired. Wash regularly

in warm water and allow to air dry. A spare bag is provided.

• Filters

It is important that the filters are cleaned regularly to allow

air through the appliance

• Blockages

Check the nozzle, tubes and hose for blockages

www.morphyrichards.co.uk

8241 Iox ib 2 21/05/2002 6:19 PM Page 1

Important safety

instructions

The use of any electrical appliance requires

the following of common sense safety rules.

Primarily there is danger of personal injury

and secondly danger of damage to the

appliance and property. These are indicated in

the instructions text by the following two

conventions:

WARNING: Danger of personal injury

IMPORTANT: Damage to the appliance

In addition we offer the following essential

safety advice.

Location

•Do not use or keep this product outside

when it is raining.

•Do not store the appliance near hot ovens

or heating appliances.

Mains lead

•Do not allow the mains lead to become

strained or run this appliance over it.

•If the electrical cable becomes damaged

the complete cable assembly must be

replaced. Do not attempt this task yourself,

contact Morphy Richards using the helpline

number.

Children

•Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use this

appliance.

Other safety considerations

•Never use in the presence of explosive

liquids or vapours.

•Never pick up inflammable or poisonous

liquids such as petrol, copier toner, or other

volatile substances. Never pick up acids,

asbestos or asbestos dust.

•Never use the appliance without the filters

installed.

•Never use the appliance to vacuum hot

ashes, broken glass, sharp objects or

liquids.

•Never modify the cleaner in any way.

•Always disconnect the appliance from the

mains supply after use or prior to cleaning

or replacing dust bags.

•The appliance should never be left running

unsupervised.

•Repairs to electrical appliances are only to

be undertaken by trained personnel.

Unprofessional repairs can be dangerous

for users.

•Use only genuine Morphy Richards spare

parts and accessories

Electrical

requirements

Check that the voltage on the rating plate

of your appliance corresponds with your house

electricity supply which must be A.C.

(Alternating Current).

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance, the plug should be removed and the

appropriate one fitted.

If you cut off the plug and let go of the

cable it will rewind into the machine. Therefore

you must pull out a length of cable and secure

it before cutting off the plug and refitting a new

one.

WARNING: The plug removed from the

mains lead, if severed, must be destroyed

as a plug with bared flexible cord is

hazardous if engaged into a live socket

outlet.

Should the fuse in the 13 amp plug require

replacement, a BS1362 13 amp fuse must be

fitted.

8241 Iox ib 2 21/05/2002 6:19 PM Page 2

‹

⁄Hose inlet

¤Dust compartment cover

‹Dustbag condition indicator

›Cover release buttons

ﬁCarrying handle

ﬂOn/off power foot pedal

‡Cable rewind pedal

·Exhaust filter and cover

‚Dustbag holder

„Dustbag spring clip

‰Dustbag clip

ÂMotor protection filter

ÊTool storage compartment

Accessories you should have:

ÁHose with handle/airflow control

ËWheeled floor nozzle

ÈExtension tubes

ÍCrevice tool with flip-action

furniture brush

ÎUpholstery nozzle

⁄

Ê ›ﬁ

ﬁ

ﬂ ‡ ·

ÍÎ

8241 Iox ib 2 21/05/2002 6:19 PM Page 3

Quick start

1Assemble the nozzle, tubes and hose as

shown A.

2Pull out the cable to it’s full length and plug

in to the mains supply.

3Switch on by pressing the foot pedal ﬂ.

Accessories

1Fit the hose to the cleaner by inserting the

hose end into the hose inlet ⁄. When

removing, squeeze the clips either side and

pull.

2Attach the two tubes to the handle end of

the hose.

The hose handle features a regulator ·

which allows the suction to be reduced as

required B. Closed gives full suction, open

gives reduced suction.

3Attach the wheeled floor nozzle ﬂto the

extension tubes.

The crevice tool (for awkward places,

behind radiators etc.) and the upholstery brush

(for curtains and upholstery) are stored inside

the cleaner under the cover C. Squeeze the

cover release buttons ›to open the cover.

The crevice tool has a flip-action brush

attachment for hard surfaces, pelmets, delicate

objects etc.

Controls

Power

The on/off control is operated by the foot

pedal ﬂ.

Automatic cable rewind

After use, unplug and press the cable

rewind button ‡to retract the cable.

WARNING: When using the cable

rewind, always hold the plug as the cable

will rewind quickly.

Dustbag condition

indicator

If the suction power decreases or if the

dustbag condition indicator ‹ shows fully red

then the bag must be emptied immediately

and/or the motor protection filter cleaned, even

if the bag does not appear full. This will also

occur if the nozzle, tubes or hose have

become blocked.

•The dustbag indicator may occasionally

show red during use - this is quite normal.

8241 Iox ib 2 21/05/2002 6:19 PM Page 4

Reusable dustbags

This model features a dustbag which can

be used many times.

1Open the dust compartment cover.

2Lift the dustbag holder ‚out of the slot D.

3Squeeze the dustbag spring clip „to

release the bag E.

4Slide the clip ‰from the bottom of the bag

and shake the dust into a dustbin F.

5Replace the clip.

6Replace the dustbag by inserting the collar

under the lip of the dustbag holder G, then

clip the other side of the collar under the

spring clip H, ensuring it is firmly secured

and the folds of the bag are opened out.

7Replace the holder into the dustbag

compartment. Ensuring that the dustbag

clip is located at the front of the

compartment.

IMPORTANT: Do not try to operate your

cleaner without a dustbag fitted. A safety

device prevents the cover from closing when

there is no dustbag.

Cleaning the dustbags

To maintain performance, we recommend

that the bag is washed regularly in warm water.

Allow the dustbag to dry naturally as direct

heat may effect the material.

IMPORTANT: Ensure the dustbag is totally

dry before installing it back into the cleaner.

A spare dustbag is provided to allow you to

continue using your vacuum while the other

dustbag is being cleaned.

„

‰

‚

8241 Iox ib 2 21/05/2002 6:19 PM Page 5

Filters

The filters must be cleaned everytime the

bag is emptied to remove the fine dust

particles collected.

The motor protection filter Âis in the

dustbag compartment. With the cover and

dustbag removed, lift out the filter holder and

remove the filter I.

The exhaust filter ·is located at the back

the cleaner. To remove, press in the catch and

pull the cover away to remove the holder J.

Remove the filter from the holder.

Cleaning

Clean the filters by shaking them. To further

maintain performance, wash them regularly by

rinsing in warm water and allowing to dry

naturally.

IMPORTANT: Ensure the filters are

completely dry before replacing.

IMPORTANT: Do not operate your cleaner

without the filters fitted.

Park and storage

positions

During use, you can quickly park the

cleaning head at the back of the cleaner K.

When finished, you can store the vacuum

cleaner and accessories as shown L.

8241 Iox ib 2 21/05/2002 6:19 PM Page 6

Care and

maintenance

Your cleaner is manufactured to withstand

normal day-to-day use, but an occasional wipe

over with a damp cloth will help maintain its

good looks. Abrasive cleaners should not be

used.

Purchasing

replacement parts

Use original Morphy Richards bags and

filters. Replacement packs can be purchased

from specialist retailers. If you have difficulty,

call the order line.

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us. We’re

more likely able to help than the store from

where you bought it.

Please have the following information ready

to enable our staff to deal with your query

quickly:

•Name of the product;

•Model number as shown on the underside

of the appliance;

•Serial number.

Your two-year

guarantee

•It is important to retain the retailers receipt

as proof of purchase. Staple your receipt to

this back cover for future reference.

Please quote the following information if the

product develops a fault. These numbers can

be found on the base of the product.

Model no. Serial no.

All Morphy richards products are individually

tested before leaving the factory. In the unlikely

event of any appliance proving to be faulty

within 28 days of purchase it should be

returned to the place of purchase for it to be

replaced.

If the fault develops after 28 days and within

24 months of original purchase, you should

contact the helpline number quoting model

number and serial number on the product, or

write to Morphy Richards at the address shown.

You will be asked to return the product (in

secure, adequate packaging) along with a copy

of proof of purchase. Subject to the exclusions

set out below (1-5), the faulty appliance will

then be repaired or replaced and dispatched

usually within seven working days of receipt.

If you suspect a fault, follow the simple

checks detailed below before returning the

appliance or calling the helpline.

•Check the dust bag and filters for

blockages.

•Check the hose and tubes for blockages.

•Check the plug is firmly in the socket and

the supply is switched on.

•Make sure the socket is working by trying

another appliance.

If for any reason this item is replaced during

the two-year guarantee period, the guarantee

on the new item will be calculated from

original purchase date. Therefore it is vital

to retain your original receipt or invoice to

indicate the date of initial purchase.

To qualify for the two-year guarantee

the appliance must have been used

according to the manufacturers

instructions. For example bags and filters

should be changed or cleaned regularly.

8241 Iox ib 2 21/05/2002 6:19 PM Page 7

VC73165M Rev 2 5/02

The After Sales Division,

Morphy Richards Ltd, Mexborough,

South Yorkshire, England, S64 8AJ

Helpline (office hours)

UK (local rate) 0870 060 2604

Republic of Ireland 1800 409119

Morphy Richards products are

intended for household use only

Morphy Richards has a policy of

continuous improvement in product

quality and design. The Company,

therefore, reserves the right to change

the specification of its models at any

time.

For additional information on Morphy Richards products www.morphyrichards.co.uk

Morphy richards shall not be liable to replace

or repair the goods under the terms of the

Guarantee where:

1The fault has been caused or is attributable to

accidental use, mis-use such as neglecting to

regularly clean filters or used contrary to the

manufacturers recommendations or where the

fault has been caused by power surges or

damage caused in transit.

2The appliance has been used on a voltage

supply other than that marked on the products.

3Repairs have been attempted by persons other

than our service staff (or authorised dealer).

4Where the appliance has been used for hire

purposes or non-domestic use.

5The guarantee excludes consumables such as

bags and filters.

This guarantee does not confer any rights

other than those expressly set out above and

does not cover any claims for consequential

loss or damage. This guarantee is offered as an

additional beneﬁt and does not affect your

statutory rights as a consumer.

•This guarantee is valid in the UK and Ireland

only.

8241 Iox ib 2 21/05/2002 6:19 PM Page 8

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Aspiradora de Morphy Richards

Morphy Richards

Morphy Richards IB70041 Manual de usuario

Morphy Richards

Morphy Richards 73313 Manual de usuario

Morphy Richards

Morphy Richards GrimeBuster steam cleaner Manual de usuario

Morphy Richards

Morphy Richards VC73215 MUK Manual de usuario

Morphy Richards

Morphy Richards SpillMaster Manual de usuario

Morphy Richards

Morphy Richards Ultralight vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards VC73184 Manual de usuario

Morphy Richards

Morphy Richards Ultralight bagless vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards IB73180 Manual de usuario

Morphy Richards

Morphy Richards ESSENTIALS CYCLONIC BAGLESS UPRIGHT VACUUM CLEANER - REV... Manual de usuario

Morphy Richards

Morphy Richards ESSENTIALS COMPACT BAGLESS VACUUM CLEANER Manual de usuario

Morphy Richards

Morphy Richards VC73410 MUK Manual de usuario

Morphy Richards

Morphy Richards VORTICITY Manual de usuario

Morphy Richards

Morphy Richards IB70061 Manual de usuario

Morphy Richards

Morphy Richards IB73105 Manual de usuario

Morphy Richards

Morphy Richards 73281 Manual de usuario

Morphy Richards

Morphy Richards POD CYCLONE VACUUM CLEANER - REV 1 Manual de usuario

Morphy Richards

Morphy Richards 700006 Manual de usuario

Morphy Richards

Morphy Richards 73285 BAGLESS UPRIGHT VACUUM CLEANER Manual de usuario

Morphy Richards

Morphy Richards ESSENTIALS CYLINDER VACUUM CLEANER - REV 3 Manual de usuario

Morphy Richards

Morphy Richards POD COMPACT BAGLESS VACUUM CLEANER - REV 2 Manual de usuario

Morphy Richards

Morphy Richards BAGLESS UPRIGHT VACUUM CLEANER - REV 1 Manual de usuario

Morphy Richards

Morphy Richards Supervac 732009 Manual de usuario

Morphy Richards

Morphy Richards IB70240 Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
