Morphy Richards ESSENTIALS COMPACT BAGLESS VACUUM CLEANER Manual de usuario

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

Essentials compact bagless

vacuum cleaner

Please read and keep these instructions

Getting the best from your new cleaner...

If your cleaner is not picking up as well as it should, please check

FFiilltteerrss

It is important that the filters are cleaned regularly to allow

air through the appliance. Shake to remove dust, the filter

can also be washed in warm water and left to air dry.

IMPORTANT - Ensure filter is totally dry before refitting

into machine.

BBlloocckkaaggeess

Check the tools and hose for blockages.

EEccooSSwwiittcchh

If suction is low and the product has been emptied, the

filters cleaned and the product checked for blockages,

check that the Eco Switch dial is set to maximum.

VC73192 MUK Rev 1

For replacement parts, help with using your Morphy Richards product,

problems and lots more, contact us by phone or through our website.

UUKKHHeellpplliinnee::0088445500777777770000

IIrreellaanndd11880000440099111199

73192 rev1 11/9/07 15:24 Page 1

IMPORTANT

SAFETY

INSTRUCTIONS

The use of any electrical

appliance requires the

following common sense

safety rules.

Primarily there is danger of

injury or death and

secondly the danger of

damage to the appliance.

These are indicated in the

text by the following two

conventions:

WARNING: Danger to

the person!

IMPORTANT: Damage to

the appliance!

In addition we offer the

following safety advice.

Location

• Do not use or keep this

product outside.

• Do not store the appliance

near hot surfaces eg ovens

or heating appliances.

Mains lead

• Do not allow the mains

lead to become strained or

run this appliance over it.

• If the electrical cable

becomes damaged the

cable assembly must be

replaced. Do not attempt

this task yourself, contact

the helpline number that is

found at the bottom of the

page.

Personal safety

•WARNING: Keep loose

clothing, hair, fingers etc.

away from the turbo

nozzle during use.

• The plug must be removed

from the wall socket before

cleaning or maintaining the

appliance.

• Never use in the presence

of explosive liquid or

vapours.

• Never pick up inflammable

or poisonous liquids such

as petrol, copier toner or

other volatile substances.

Never pick up acids,

asbestos or asbestos dust.

• Never touch the plug or

cable with wet hands.

• Unprofessional repairs can

be dangerous for users.

• The appliance must never

be left running

unsupervised.

• This appliance is intended

for domestic use only.

Misuse or use for

commercial or any other

purpose will render the

guarantee invalid.

• Always disconnect the

appliance from the main

supply after use or prior to

emptying, cleaning or

maintaining.

• To protect against fire,

electric shock and personal

injury do not immerse cord,

plug or cleaner in water or

other liquid.

• This appliance is not

intended for use by

persons (including children)

with reduced physical,

sensory or mental

capabilities, or lack of

experience and knowledge,

unless they have been

given supervision or

instruction concerning use

of the appliance by a

person responsible for their

safety.

Product safety

• Never use the appliance

without the filters being

installed.

• Never use the appliance to

vacuum hot ashes, broken

glass, sharp objects or

liquids.

• Use only Morphy Richards

spare parts and

accessories.

• Never modify the cleaner in

any way.

Children

• Children do not understand

the dangers associated

with operating electrical

appliances. Never allow

children to use this

appliance.

• Children should be

supervised to ensure that

they do not play with the

appliance.

ELECTRICAL

REQUIREMENTS

Check that the voltage on

the rating plate of your

appliance corresponds with

your house electricity

supply which must be A.C.

(Alternating Current).

If the socket outlets in your

home are not suitable for

the plug supplied with this

appliance the plug should

be removed and the

appropriate one fitted.

If you cut off the plug and

let go of the cable it will

rewind into the machine,

therefore you must pull out

a length of cable and

secure it before cutting the

plug off and re-fitting a new

one.

WARNING: The plug

removed from the mains

lead, if severed, must be

destroyed as a plug with

a bared flexible cord is

hazardous if engaged

into a live socket outlet.

Should the fuse in the 13

amp plug require changing

a 13 amp BS1362 fuse

must be fitted.

FFoorrAAddvviiccee,,SSppaarreessoorrAAcccceessssoorriieess,,tteell::0088445500777777770000((UUKK))oorr11880000440099111199((IIrreellaanndd))

73192 rev1 11/9/07 15:24 Page 2

FEATURES

⁄Dust canister release latch

¤Eco Switch

‹Power on/off switch

›Handle

ﬁCable rewind button

ﬂWheels

‡Dust canister

·Hose inlet

‚Hose release button

„Storage hook

‰Exhaust filter and cover

ÂTube storage slot

Accessories you

should have

ÊFloor nozzle

ÁFlexible hose/handle with

airflow control

ËUpholstery nozzle

ÈCrevice tool

ÍBrush tool

(clips onto crevice tool)

ÎExtension tubes x 2

ÏTool storage clip

ÌSmall turbo nozzle

(certain models only)

ﬂ

„

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

⁄¤‹

›

ﬁ

‡

‰

‚

›

‹

ﬂ

73192 rev1 11/9/07 15:24 Page 3

44FFoorrAAddvviiccee,,SSppaarreessoorrAAcccceessssoorriieess,,tteell::0088445500777777770000((UUKK))oorr11880000440099111199((IIrreellaanndd))

OPERATING THE

APPLIANCE

ASSEMBLY

Your vacuum cleaner has an

efficient suction action to

provide high levels of cleaning

on all types of surface around

the home.

Switch off before fitting or

removing accessories.

Insert the flexible

hose

Insert the flexible hose Áin the

hose inlet duct ·on the front

of the product, press until it

clicks into position A.

To remove the flexible

hose

Press the release button to

release the flexible hose. Pull

the hose firmly from the hose

inlet duct.

Fitting the extension

tubes and

accessories

Join the two extension tubes Î

together and attach the

extension tubes to the handle

end Áof the hose. Some tasks

may be easier with only one

extension tube fitted.

Attach the floor nozzle Êto the

extension tubes. The floor nozzle

can be used for carpets, rugs,

hard floors and tiles.

Other accessories

include:

• Crevice tool Èfor awkward

places, corners and behind

radiators etc.

• Brush attachment Ífor

pelmets, delicate objects etc.

• Upholstery nozzle Ëfor sofas,

armchairs etc.

• Tools can be stored on the tool

storage clip Ïthat fits onto the

extension tubes.

Turbo nozzle Ì

(certain models only)

• This nozzle is ideal for picking

up pet hairs from upholstery or

stairs.

Cleaning the turbo

nozzle

(certain models only)

• The turbo nozzle should be

regularly cleaned and any hairs

or fibres wrapped around the

brush bar removed to maintain

optimum performance.

73192 rev1 11/9/07 15:24 Page 4

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

CONTROLS

On/off control

Press the on/off pedal ‹ to

start the machine, press again to

turn off.

Eco Switch

The Eco Switch allows you to

turn down the power when

cleaning more delicate items

such as curtains and upholstery,

saving energy and reducing

running costs.

Suction control on

the handle

The suction power can be

adjusted using the fingertip

control on the handle B.

Closed : full suction

Open : low suction

2 position wheeled

floor nozzle Ê

The brushes should be retracted

for use on carpets and down for

use on hard floors by adjusting

the lever on the floor nozzle.

After vacuuming

1Switch off the vacuum cleaner.

2Unplug from the mains.

3Use a hand or foot to operate

the cable rewind ﬁ.

WARNING: When using the

cable rewind, always hold

the plug as the cable will

rewind quickly.

Emptying the dust

canister

1Disconnect the cleaner from the

mains socket.

2Disconnect the hose from the

hose inlet duct.

3Remove the dust canister by

pushing the pod release latch

4Remove the filter basket and

empty the pod into a waste bin

If the dust is tightly packed tap

the front cover. Shake the filter

basket into the waste bin, this

will remove most of the dust.

73192 rev1 11/9/07 15:24 Page 5

Replacement filter

basket

To maintain the suction of the

cleaner the filter basket must be

washed regularly (in warm water

only, no detergent).

• Allow the filter basket to air dry

naturally.

IMPORTANT: Both parts MUST

BE THOROUGHLY DRY before

the assembly is re-fitted to the

cleaner.

Reassemble

• Replace the filter basket

ensuring that the seal is good

E. Then replace the pod onto

the main body F.

Motor protection filter

This cleaner is fitted with a

motor protection filter. NEVER

USE THE VACUUM CLEANER

WITHOUT THIS IN PLACE.

To clean the motor

protection filter

1Remove the filter from the filter

grille G.

2Rinse the filter in lukewarm

water and dry the filter

completely.

3Put the filter back into the filter

grille and reassemble.

Storage position

The vacuum cleaner can be

stored in an upright position.

Slide the storage hook „into

the slot on the base of the

product Âand the tubes, hose

and floor nozzle are held

securely H.

FFoorrAAddvviiccee,,SSppaarreessoorrAAcccceessssoorriieess,,tteell::0088445500777777770000((UUKK))oorr11880000440099111199((IIrreellaanndd))

73192 rev1 11/9/07 15:24 Page 6

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

HINTS AND TIPS

Changing and

cleaning the exhaust

filter

This filter should be replaced

every 12 months or sooner if

required.

Remove the exhaust filter grille

by pulling the locking tabs

towards you I. Remove the

used filter. Insert the clean micro

exhaust filter and replace the

filter grille.

IMPORTANT:

• All filters should be checked

regularly for signs of damage,

preferably after each cleaning

task. The filters must be

replaced immediately if they

become damaged.

• Always disconnect the cleaner

from the mains when checking

filters.

• Always make sure all filters are

fitted before use. Failure to do

so may result in damage to your

product.

• If the sound of the cleaner

changes slightly, clean the filters

and check for blockages.

Cleaning and

maintenance

Unplug from the mains before

cleaning. The vacuum cleaner,

especially the dust

compartment and all

accessories can be cleaned

using a damp cloth or a non-

abrasive domestic cleaner and

wiped dry.

To keep the underside of the

floor nozzle clean, vacuum it at

regular intervals using the

crevice tool.

HELPLINE

If you have any difficulty with

your appliance, do not hesitate

to call us.

We are more likely to be able

to help than the store from

where you bought it.

Please have the following

information ready to enable our

staff to deal with your query

quickly:

• Name of the product

• Model number as shown on the

underside of the appliance.

• Serial number as shown on

underside of the appliance.

UK Helpline 0845 077 7700

Ireland Helpline 1800 409 119

73192 rev1 11/9/07 15:24 Page 7

Morphy Richards products are intended for household use only.

Morphy Richards has a policy of continuous improvement in product quality and

design. The company, therefore reserves the right to change the specification of

its models at any time.

The After Sales Division

Morphy Richards Ltd

Mexborough, SouthYorkshire,

England, S64 8AJ

Helpline (office hours)

UK 0845 077 7700

Republic of Ireland 1800 409 119

VC73192 MUK Rev1 08/07

FFoorrddeettaaiillssooffootthheerrpprroodduuccttssiinntthheeMMoorrpphhyyRRiicchhaarrddssrraannggeepplleeaasseesseeeeoouurrwweebbssiittee......

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

YOUR TWO YEAR

GUARANTEE

It is important to retain

the retailer’s receipt as

proof of purchase. Staple

your receipt to this back

cover for future reference.

Please quote the following

information if the product

develops a fault. These

numbers can be found on

the base of the product.

Model no.

Serial no.

All Morphy Richards

products are individually

tested before leaving the

factory. In the unlikely event

of any appliance proving to

be faulty within 28 days of

purchase, it should be

returned to the place of

purchase for it to be

replaced.

If the fault develops after

28 days and within 24

months of original

purchase, you should

contact the Helpline

number quoting Model

number and Serial number

on the product, or write to

Morphy Richards at the

address shown.

You may be asked to return

a copy of proof of

purchase.

Subject to the exclusions

set out below (see

Exclusions) the faulty

appliance will then be

repaired or replaced and

dispatched usually within 7

working days of receipt.

If you suspect a fault,

follow the simple checks

detailed below before

retrying the appliance or

calling the helpline.

• Check the filters for

blockages.

• Check the tools / tubes for

blockages.

• Check the plug is firmly in the

socket.

• Check the socket is working

by trying another appliance.

• Check the fuse in the plug.

If for any reason this item is

replaced during the 2 year

guarantee period, the

guarantee on the new item

will be calculated from

original purchase date.

Therefore it is vital to retain

your original till receipt or

invoice to indicate the date

of initial purchase.

To qualify for the 2 year

guarantee, the appliance

must have been used

according to the

instructions supplied.

EXCLUSIONS

Morphy Richards shall not

be liable to replace or

repair the goods under the

terms of the guarantee

where:

1The fault has been caused

or is attributable to

accidental use, misuse,

negligent use or used

contrary to the

manufacturer’s

recommendations or where

the fault has been caused

by power surges or

damage caused in transit.

2The appliance has been

used on a voltage supply

other than that stamped on

the products.

3Repairs have been

attempted by persons

other than our service staff

(or authorised dealer).

4Where the appliance has

been used for hire

purposes or non domestic

use.

5Morphy Richards are not

liable to carry out any type

of servicing work, under

the guarantee.

6The guarantee excludes

consumables such as

some filters.

• This guarantee does not

confer any rights other than

those expressly set out

above and does not cover

any claims for

consequential loss or

damage. This guarantee is

offered as an additional

benefit and does not affect

your statutory rights as a

consumer.

• This guarantee is valid in

the UK and Ireland only.

For electrical products sold within the

European Community. At the end of the

electrical products useful life it should

not be disposed of with household

waste.

Please recycle where facilities exist.

Check with your Local Authority or

retailer for recycling advice in your

country.

73192 rev1 11/9/07 15:24 Page 8

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Aspiradora de Morphy Richards

Morphy Richards

Morphy Richards Supervac gold Manual de usuario

Morphy Richards

Morphy Richards Supervac deluxe Manual de usuario

Morphy Richards

Morphy Richards 70316 Manual de usuario

Morphy Richards

Morphy Richards BAGLESS CYLINDER VACUUM CLEANER - REV 2 Manual de usuario

Morphy Richards

Morphy Richards Supervac Deluxe Manual de usuario

Morphy Richards

Morphy Richards VORTICITY Manual de usuario

Morphy Richards

Morphy Richards IB70041 Manual de usuario

Morphy Richards

Morphy Richards Scoot cylinder vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards IB73300 Manual de usuario

Morphy Richards

Morphy Richards Bagged cylinder Vacuum Manual de usuario

Morphy Richards

Morphy Richards STORM LIGHT UPRIGHT VACUUM CLEANER - REV 3 Manual de usuario

Morphy Richards

Morphy Richards POD VACUUM CLEANER Manual de usuario

Morphy Richards

Morphy Richards IB73120 Manual de usuario

Morphy Richards

Morphy Richards IB73090 Manual de usuario

Morphy Richards

Morphy Richards IB71053 Manual de usuario

Morphy Richards

Morphy Richards GOBLIN 1400W WET AND DRY CLEANER Manual de usuario

Morphy Richards

Morphy Richards PERFORMAIR CYCLONIC VACUUM CLEANER 71062 Manual de usuario

Morphy Richards

Morphy Richards Allergy cylinder vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards IB71051 Manual de usuario

Morphy Richards

Morphy Richards 73380 Manual de usuario

Morphy Richards

Morphy Richards PerformAir Upright Vacuum Manual de usuario

Morphy Richards

Morphy Richards POD CYCLONE VACUUM CLEANER - REV 1 Manual de usuario

Morphy Richards

Morphy Richards BIG POD BAGLESS VACUUM CLEANER - REV 2 Manual de usuario

Morphy Richards

Morphy Richards VORTICITY Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
