Morphy Richards POD VACUUM CLEANER Manual de usuario

Pod vacuum cleaner

Please read and keep these instructions

getting the best from

your new cleaner...

If your cleaner isn’t picking up as

well as it should, please check

• Filter

It is important to clean it everytime you empty the

pod, otherwise the performance of the cleaner will

be impaired. See page 5 - Cleaning the filter. A

spare filter is provided

• Blockages

Check the nozzle, tube and hose for blockages

www.morphyrichards.co.uk

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 1

Important safety

instructions

The use of any electrical appliance requires

the following of common sense safety rules.

Primarily there is danger of personal injury

and secondly danger of damage to the

appliance and property. These are indicated in

the text by the following two conventions:

WARNING: Danger of personal injury

IMPORTANT: Damage to the appliance

In addition we offer the following essential

safety advice.

Location

•Do not use or keep this product outside

when it is raining.

•Do not store the appliance near hot ovens or

heating appliances.

Mains lead

•Do not allow the mains lead to become

strained or run this appliance over it.

•If the electrical cable becomes damaged the

complete cable assembly must be replaced.

Do not attempt this task yourself, contact

Morphy Richards using the helpline number.

Children

•Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use this

appliance.

Other safety considerations

•Never use the appliance without the filter

installed.

•Never use the appliance to vacuum hot

ashes, broken glass, sharp objects or

liquids.

•Never use in the presence of explosive

liquids or vapours.

•Never pick up inflammable or poisonous

liquids such as petrol, copier toner, or other

volatile substances. Never pick up acids,

asbestos or asbestos dust.

•Always disconnect the appliance from the

mains supply after use or prior to cleaning

or replacing dust bags.

•The appliance should never be left running

unsupervised.

•Never modify the cleaner in any way.

•Repairs to electrical appliances are only to

be undertaken by trained personnel.

Unprofessional repairs can be dangerous for

users.

•Use only genuine Morphy Richards spare

parts and accessories

Electrical

requirements

Check that the voltage on the rating plate of

your appliance corresponds with your house

electricity supply which must be A.C.

(Alternating Current).

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance, the plug should be removed and the

appropriate one fitted.

WARNING: The plug removed from the

mains lead, if severed, must be destroyed

as a plug with bared flexible cord is

hazardous if engaged into a live socket

outlet.

Should the fuse in the 13 amp plug require

replacement, a BS1362 13 amp fuse must be

fitted.

Description

Your Pod vacuum cleaner is a versatile

machine that can be used as an upright cleaner

or as a handheld (with or without the shoulder

strap).

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 2

⁄



‹

ﬁ

„

ﬂ

‚

‡

Features

⁄On/off switch

¤Telescopic handle

‹Telescopic handle release button

›Handle locking/release pin

ﬁFlexible hose

ﬂHose storage clips (2)

‡Brush attachment

·Crevice tool attachment

‚Carrying handle

„Dust collection pod

‰Removable washable dust retention filter

(inside Pod)

ÂPod location pins (not visible)

ÊPod open/close lever

ÁCable storage hanger

ËCable storage quick release

ÈCable tidy clip

ÍBody

ÎCleaning head

ÏCleaning head locking/release pin (not

visible)

ÌWheels (2)

ÓRoller

ÔExtension tube

Strap with connector clips

ÒHoles for strap connector clips

›

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 3

Assembly

To use as an upright

1Fit the cleaning head by pressing in the

locking pin and insert the head into the hole

at the base of the body E.

2Locate the telescopic handle into the body

by pushing in the locking pin ›and

pushing the handle in until the locking pin

locates in the locking hole D. To remove,

press in the release pin and pull the handle

out.

3Adjust the telescopic handle by pushing the

release button ‹down and pulling out or

pushing in the lower half F.

To use as a handheld

1Remove the telescopic handle.

2Remove the cleaning head by pressing in

the release pin Ï and pulling the head

away from the body E.

3Remove the hose by pulling it away from the

storage clips on either side.

4Take the end of the hose that is fitted with

the locking/release pin. Holding the pin in

push the hose into the cleaning head

hole G.

Attachments

The brush or crevice tool can be fitted

directly to the hose. For extra reach the

extension tube can be fitted to the hose. The

tool is then fitted to the extension tube.

Uses for the brush attachment include

stairs, upholstery, mattresses, curtains and hard

surfaces like door mouldings and skirting

boards.The crevice tool is particularly useful for

cobwebs and in narrow gaps in the car around

the handbrake and seat.

To attach the shoulder strap, attach the

metal clips to the two holes in the body Ò.

›

‹

Locking pin

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 4

Using

Unwind the cable or turn the quick release

lever Ë and plug into a mains socket.

Switch on or off by pressing the switch.

1 = on; O = off.

IMPORTANT: Do not allow the pod to

become too full; do not let dust fill above the

maximum mark.

Dust disposal

Ensure the Pod is switched off and

disconnected from the mains supply.

1Use the pod open/close lever Êto turn the

dust collection pod to the right in the

direction of the open arrow as far as it will

go H.

2Lift out the pod I.

3Pull out the filter J.

4Empty the dust into a bin.

5Clean the filter as described below.

6Replace the filter into the pod.

7Replace the pod into the body by aligning

the arrow face down with the locating pin

and lowering into position K.

8Turn the open/close lever to the left in the

direction of the close arrow.

Cleaning the filter

IMPORTANT

Every time the pod is emptied, clean the

filter by shaking it rigorously, or by using the

brush attachment.

To maintain high suction, the filter should

also be washed regularly in warm water, but do

not use detergent.

Allow the filter to dry naturally and ensure it

is totally dry before installing it back into the

cleaner.

A spare filter is provided to allow you to

continue using your vacuum whilst the original

filter is washed and dried.

‰

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 5

Cleaning the

machine

Use the brush attachment on the hose and

use the Pod to vacuum itself. To keep the

underside of the cleaning head clean, vacuum it

at regular intervals using the crevice tool.

Or, disconnect the Pod from the mains

supply and remove dust by using a soft damp

cloth and wipe dry. Do not use scourers or

abrasive cleaners.

Purchasing

replacement filters

The lifetime of the reusable filter is

dependant largely upon usage of the cleaner.

Should the filter become damaged or if there is

a noticeable drop in performance even after

washing, it should be changed immediately. Use

only Morphy Richards replacement filters which

can be purchased from specialist retailers or by

calling the number on the front page of this

leaflet.

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us. We’re

more likely able to help than the store from

where you bought it.

Please have the following information ready

to enable our staff to deal with your query

quickly:

•Name of the product

•Model number as shown on the underside

of the appliance

•Serial number.

Cleaning the

machine

Use the brush attachment on the hose and

use the Pod to vacuum itself. To keep the

underside of the cleaning head clean, vacuum it

at regular intervals using the crevice tool.

Or, disconnect the Pod from the mains

supply and remove dust by using a soft damp

cloth and wipe dry. Do not use scourers or

abrasive cleaners.

Purchasing

replacement filters

The lifetime of the reusable filter is

dependant largely upon usage of the cleaner.

Should the filter become damaged or if there is

a noticeable drop in performance even after

washing, it should be changed immediately. Use

only Morphy Richards replacement filters which

can be purchased from specialist retailers or by

calling the number on the front page of this

leaflet.

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us. We’re

more likely able to help than the store from

where you bought it.

Please have the following information ready

to enable our staff to deal with your query

quickly:

•Name of the product

•Model number as shown on the underside

of the appliance

•Serial number.

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 6

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 7

442/8673/07 Rev 3 11/01

Your two-year

guarantee

•It is important to retain the retailers

receipt as proof of purchase. Staple your

receipt to this back cover for future

reference.

Please quote the following information if the

product develops a fault. These numbers can

be found on the base of the product.

Model no. Serial no.

All Morphy Richards products are

individually tested before leaving the factory. In

the unlikely event of any appliance proving to

be faulty within 28 days of purchase it should

be returned to the place of purchase for it to be

replaced.

If the fault develops after 28 days and within

24 months of original purchase, you should take

the appliance to your nearest service agent. A

list containing details of your nearest service

agent is included with your appliance but

please contact the helpline quoting model

number and serial number should you require

further assistance. Repair or replacement of the

product is subject to the exclusions set out

below (1-6).

If you suspect a fault, follow the simple

checks detailed below before returning the

appliance or calling the helpline.

•Check the dust bag and filters for

blockages.

•Check the hose and tubes for blockages.

•Check the plug is firmly in the socket and

the supply is switched on.

•Make sure the socket is working by trying

another appliance.

If for any reason this item is replaced during

the two-year guarantee period, the guarantee

on the new item will be calculated from original

purchase date. Therefore it is vital to retain your

original receipt or invoice to indicate the date of

initial purchase.

To qualify for the two-year guarantee the

appliance must have been used according to

the manufacturers instructions.

Morphy Richards shall not be liable to replace

or repair the goods under the terms of the

Guarantee where:

1The fault has been caused or is attributable to

accidental use, mis-use, negligent use or used

contrary to the manufacturers

recommendations or where the fault has been

caused by power surges or damage caused in

transit.

2The appliance has been used on a voltage

supply other than that stamped on the

products.

3Repairs have been attempted by persons other

than our service staff (or authorised dealer).

4Where the appliance has been used for hire

purposes or non-domestic use.

5The guarantee excludes consumables such as

bags and filters.

6Morphy Richards are not liable to carry out any

type of servicing work, under the guarantee.

This guarantee does not confer any rights

other than those expressly set out above and

does not cover any claims for consequential

loss or damage. This guarantee is offered as an

additional beneﬁt and does not affect your

statutory rights as a consumer.

•This guarantee is valid in the UK and Ireland

only.

The After Sales Division,

Morphy Richards Ltd, Mexborough,

South Yorkshire, England, S64 8AJ

Helpline (office hours)

UK (local rate) 08450 777700

Republic of Ireland 1800 409119

Morphy Richards products are

intended for household use only

Morphy Richards has a policy of

continuous improvement in product

quality and design. The Company,

therefore, reserves the right to change

the specification of its models at any

time.

For additional information on Morphy Richards products www.morphyrichards.co.uk

8017 Upright pod ib 3 27/11/2001 12:31 PM Page 8

Tabla de contenidos

Otros manuales de Aspiradora de Morphy Richards

Morphy Richards

Morphy Richards 70317 Manual de usuario

Morphy Richards

Morphy Richards IB73120 Manual de usuario

Morphy Richards

Morphy Richards IB73301 Manual de usuario

Morphy Richards

Morphy Richards STORM CYCLONIC vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards Essentials Bag Vacuum Cleaner Manual de usuario

Morphy Richards

Morphy Richards 73199 Manual de usuario

Morphy Richards

Morphy Richards IB73105 Manual de usuario

Morphy Richards

Morphy Richards Boxer wet & dry vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards Bagged cylinder Vacuum Manual de usuario

Morphy Richards

Morphy Richards ESSENTIALS CYCLONIC BAGLESS UPRIGHT VACUUM CLEANER - REV... Manual de usuario

Morphy Richards

Morphy Richards 71077 VACUUM CLEANER Manual de usuario

Morphy Richards

Morphy Richards ESSENTIALS CYLINDER VACUUM CLEANER - REV 3 Manual de usuario

Morphy Richards

Morphy Richards Scoot cylinder vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards SpillMaster Manual de usuario

Morphy Richards

Morphy Richards IB73350 Manual de usuario

Morphy Richards

Morphy Richards Topo compact vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards 73355 PERFORMAIR ENDURANCE UPRIGHT VACUUM... Manual de usuario

Morphy Richards

Morphy Richards 73313 Manual de usuario

Morphy Richards

Morphy Richards ECO PRIUS Manual de usuario

Morphy Richards

Morphy Richards IB73300 Manual de usuario

Morphy Richards

Morphy Richards Scoot bagless vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards Allergy cylinder vacuum cleaner Manual de usuario

Morphy Richards

Morphy Richards CYCLONIC BAGLESS VACUUM CLEANER - REV 4 Manual de usuario

Morphy Richards

Morphy Richards Ultralight vacuum cleaner Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
