INSTRUCTION MANUAL
Model: MRPB20B
Read these instructions carefully before
using this appliance for the first time.
STORE THESE INSTRUCTIONS CAREFULLY
Personal Blender
www.morphyrichards.com.au
2
SPECIFICATIONS
Model: MRPB20B
Colour: Blue
Rated Voltage: 7.4V
Rated Power: 50W
Capacity: 300mL
External Dimensions (L x W x H): 95 x 87 x 183mm
Net Weight: 450g
NAMES OF BLENDER PARTS AND ACCESSORIES
USB CHARGER SPECIFIATIONS:
A USB Charger Supply Unit is not supplied with the appliance. To charge
this appliance use a standard USB Charger of DC5V/1A specification with
the USB cable supplied.
3
WARNING
To reduce the risk of fire, electric shock, injury to persons or damage to
property, follow basic precautions including the following:
• Do not fully immerse the motor assembly in water or place in the
dishwasher.
• Read and follow the included specific instructions for use.
• Fill only with cold or room temperature ingredients to avoid bursting,
splashing and scalding on opening the blending cup.
• Always disconnect the blender from the power supply if it is left
unattended and before assembling, disassembling or cleaning.
• Never blend carbonated ingredients or liquids. These can create
a build-up of gases causing the container to burst, resulting in
possible injury.
• This product contains lithium-ion batteries that are not replaceable.
DO NOT attempt to dismantle this appliance or replace the batteries
to avoid possible injury or death.
• This product is intended for standard domestic use only and should
not be used for other purposes.
• Never use the blender to blend without liquid as doing so may
damage it.
• Blending ingredients such as bananas may cause the product to
stall. Should this occur please refer to the Trouble Shooting section
of this manual.
• Rinse blade and cup immediately after use to prevent debris from
drying and sticking to the components.
IMPORTANT SAFETY INSTRUCTIONS
4
• WARNING: The blending blade is sharp! Handle carefully. Use care
when cleaning and handling the blade – do not touch the blade
edges to avoid injury.
• Do not put any parts of this product in a dishwasher, microwave
oven, sterilising unit or hot water over 60°C – or use other equipment
to heat them, in order to avoid deformation or damage to parts.
• The product has built-in lithium batteries and as such the following
instructions should be adhered to:
- Store and use this product in an environment of 0 – 40°C.
- Even if not in regular use, please charge every three months to
prevent damage to the battery.
- Charging speed may be slower in the environment below 10°C, this
is considered a normal phenomenon.
• When discarding product packaging, please re-cycle it as per your
local council requirements.
• Do not open during use.
• When the product is in use, do not attempt to touch movable parts
such as blades and motors, so as to avoid injury or damage to the
product.
• Switch off the appliance and disconnect from the supply before
changing accessories or approaching parts that move in use.
• The cap can be removed only after the blade stops rotating.
• Do not attempt to disassemble or alter this product by oneself.
• After using the product, please rinse blades and cup thoroughly with
clean water.
• WARNING: Blades are sharp. Be careful when emptying and
cleaning the blender – keep hands and utensils away from the
cutting blade to avoid risk of injury or damage to the device.
5
• After charging, please remove charger by grasping and lifting the
plug end. Don’t pull the wire itself – this may lead to damage of the
cord and affect future use.
• Do not place in or near flammable gases / electric stoves or hot
ovens.
• Do not immerse the cord, plug, power adapter or motor unit in water
or other liquids in order to avoid the risk of fire, electric shock or
personal injury.
• This appliance is not intended for use by persons with reduced
physical, sensory or mental capabilities or lack of experience and
knowledge unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their
safety.
• Children should be supervised to ensure that they do not play with
this appliance.
• In the absence of supervision, the cleaning and maintenance work
should not be done by a child.
• Do not allow children to use the blender without supervision.
• Use of accessories not recommended or sold by the original
manufacturer may cause risks of fire, electric shock or personal
injury.
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
• Do not put hot liquid of any kind in the blending cup before
blending. Heated ingredients can cause internal pressure to build
6
inside a sealed blending cup, which may then erupt on opening and
cause burns.
• When adding ingredients, do not exceed the marked MAX fill line.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
• This appliance must be used in accordance with the instructions
and must not be used for other purposes.
• Before using, please make sure that the motor assembly is firmly
attached to the blending cup.
• Never attempt to manipulate the safety interlock.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
7
OPERATION INSTRUCTIONS
There is only one function / speed. To turn on the blender:
1. Double-click the power switch, if the indicator light is white i.e. the blender is fully charged,
the product will turn on and run at full speed. When the blender is not adequately charged for
use, the indicator light will glow red and flash three times. The machine will then stop running.
If the indicator light begins to flash during operation, the unit should be charged again as soon
as possible to ensure continued operation.
Before using this product for the first time, please:
• Use warm soapy water to thoroughly wash the components that will be coming into contact
with food i.e. the blending cup and blade and dry with a soft towel.
NOTE: The motor assembly itself should be wiped over with a damp cloth and should never be
fully immersed in water.
• Ensure that the battery is fully charged.
NOTE: This product has double safety protection. The motor will not operate if the motor
assembly is removed from the cup or if the blending cup and motor assembly are not correctly
aligned/fixed into position. In this instance, the white indicator light will flash. Only when the motor
assembly and the blending cup are rotated and fixed in place correctly, will you be able to double-
click the power switch to start operation, and the indicator light will cease to flash.
NOTE: The dot on the lid must be aligned with the white dot on the cup in order to activate the
product.
CHARGING MODE
WORKING MODE
1. When the charging adapter is first connected, the LED light shows red. The red light remains
during the charging process.
2. When fully charged, the LED light shows white.
8
NOTE: If the blades become blocked or are otherwise not able to turn freely, the product will stop
immediately and the white LED indicator will flash. Whilst the light is flashing, the product will not
respond to pressing the button switch. Clear the blades by flipping the unit gently and wait for the
light to stop flashing before attempting to begin the blending process again.
2. Press the power switch at any time during the blending process to stop the machine.
3. In order to protect the motor, the blender is programmed to run for 40 second intervals. If the
motor does not shut down after 40 seconds, turn off manually by pressing the power switch
and restart as required. At full charge, the blender can be operated 5 times (at approx. 3
minutes per use) with recharge being required again after the 5th use.
NOTE: Any fruit and / or vegetables placed into the blending cup should be washed, peeled and
cut into small cubes of approx. 1cm.
4. Put the cut fruit / vegetables into the blending cup, add water or your preferred milk or other
liquids.
NOTE: The total amount of food and liquid should not exceed the maximum mark (300mL) of the
cup.
5. The motor assembly should be twisted into position on the blending cup and hand tightened
in place to ensure that the food will not leak out.
6. Double-click the power switch on the motor assembly, turn the product upside down, hold it in
hand, and the product starts to work.
NOTE: During the blending process, you may click the power switch once, and the product will
stop working immediately. If the blade is stuck at start-up, the product can be placed upright and
then placed upside down after normal start-up.
7. After mixing and once the blade / motor assembly is removed from the blending cup, the
blending cup can then be used directly to consume the juice / smoothie etc.
8. The magnetic suction charging wire is required to be inserted into a standard USB Charger
Supply Unit of DC5V/1A specification, and the magnetic suction head of the charging wire is
to be placed on the charging port of the motor assembly to charge the product.
NOTE: When charging, put the blending cup flat on the table to charge. When charging, the LED
indicator will glow red, and once fully charged, the LED indicator will glow white. The product
cannot be used whilst being charged.
9
Turn the unit off and disconnect the motor assembly from the blending cup.
Do not use abrasive sponges, scouring pads, bleach or acetone-based product to clean this
appliance.
Motor assembly can be simply wiped down after use with a damp cloth – it should not be
immersed in water or placed into a dishwasher for any reason.
Rinse the inside of the blending cup and the parts in contact with food with clean water, and wipe
dry or allow them to air dry.
When storing, please ensure that the product is clean and dry, before being placed in a dry, well
ventilated place out of direct sunlight.
RAPID CLEAN:
Add an appropriate amount of water to the blending cup and attach the motor assembly.
Double-click the power switch and allow to blend for 5 – 10 seconds.
CLEANING
10
TROUBLE SHOOTING
Issue Possible Cause Remedy
Product does not start • Is it used continuously
for a long time?
• Is the food stuck on the
blade?
• Is the motor assembly
and the blending cup not
rotated in place?
• The red light flickered.
• Wait for the motor to cool
down before using.
• Remove the remaining food
and use it again.
• Install the motor assembly
and blending cup in place
before starting.
• Fully charge before use.
When working, the blade is stuck
and the lamp flashes
• The ingredients are too
large and cause the
blade to stick.
• Fruits and liquids exceed
the maximum scale rated
by the product.
• The ingredients are washed,
peeled, and cut into small
cubes of about 1cm. Don’t
let the blade touch the pulp
first, then turn on and put it
in position.
• Reduce the liquid capacity
to not exceed the rated
capacity of the cup.
Burnt smell coming from the
motor
• Continuous use time is
longer than 40 second
intervals.
• The high-powered motor
is inside the main unit.
Due to the friction of the
carbon brush, an odour will
occur, but it is not a product
failure. Please feel free to
use.
Charging without prompt (red light
not on)
• Bad connection of USB data
line.
• Due to the identification
restrictions of some branded
adapters on the electrical
equipment, the actual output
voltage and current do not
meet the requirements.
• Check the connection status
of the USB data line to ensure
that the connection is normal.
• Charge the product with the
universal adapter of DC5V/1A
and above, which is purchased
through regular channels.
Tabla de contenidos
Otros manuales de Licuadora de Morphy Richards
Morphy Richards
Morphy Richards Soup Maker Clarity Manual de usuario
Morphy Richards
Morphy Richards Accents Manual de usuario
Morphy Richards
Morphy Richards CORDLESS HAND BLENDER - REV 1 Manual de usuario
Morphy Richards
Morphy Richards Easy Blend 48415 Manual de usuario
Morphy Richards
Morphy Richards Easyblend Deluxe Manual de usuario
Morphy Richards
Morphy Richards Easyblend Deluxe Manual de usuario
Morphy Richards
Morphy Richards Accents 48544 Manual de usuario
Morphy Richards
Morphy Richards Cordless hand blender Manual de usuario
Morphy Richards
Morphy Richards Accents FP48988 MUK Manual de usuario
Morphy Richards
Morphy Richards Accents Manual de usuario
Morphy Richards
Morphy Richards 48821 SOUP MAKER Manual de usuario
Morphy Richards
Morphy Richards Smooth Manual de usuario
Morphy Richards
Morphy Richards 402050 Total Control Manual de usuario
Morphy Richards
Morphy Richards BLENDER - MANUAL 3 Manual de usuario
Morphy Richards
Morphy Richards Easy Blend 48415 Manual de usuario
Morphy Richards
Morphy Richards Nutri Fusion Manual de usuario
Morphy Richards
Morphy Richards Total Control Manual de usuario
Morphy Richards
Morphy Richards Compact Food Processor Manual de usuario
Morphy Richards
Morphy Richards 501027 Manual de usuario
Morphy Richards
Morphy Richards MRPBW24EG Manual de usuario
