Mitsubishi Electric LCPU-U-HW Manual de instrucciones

Thank you for purchasing the Mitsubishi Electric programmable

controller MELSEC-L series.

Safety Guidelines

Prior to use, please read this and relevant manuals thoroughly to

fully understand the product.

MODEL LCPU-U-HW

MODEL

CODE 13J240

IB(NA)-0800456-P(1806)MEE

SAFETY PRECAUTIONS

(Read these precautions before using this product.)

Before using the MELSEC-L series products, please read this manual and the

relevant manuals carefully and pay full attention to safety to handle the product

correctly. When equipment is used by the way a maker doesn't designate, the

protection of the equipment may be damaged.

In this manual, the safety precautions are classified into two levels:

" WARNING" and " CAUTION".

Under some circumstances, failure to observe the precautions given under "

CAUTION" may lead to serious consequences.

Observe the precautions of both levels because they are important for personal

and system safety.

Make sure that the end users read this manual and then keep the manual in a safe

place for future reference.

All safety precautions for the MELSEC-L series products are described in this

manual.

[Design Precautions]

WARNING

●Configure safety circuits external to the programmable controller to ensure

that the entire system operates safely even when a fault occurs in the external

power supply or the programmable controller. Incorrect output or malfunction

due to a communication failure may result in an accident.

(1) Emergency stop circuits, protection circuits, and protective interlock

circuits for conflicting operations such as forward/reverse rotations or

upper/lower limit positioning must be configured external to the

programmable controller.

WARNING Indicates that incorrect handling may cause

hazardous conditions, resulting in death or severe

injury.

Indicates that incorrect handling may cause

hazardous conditions, resulting in minor or moderate

injury or property damage.

CAUTION

[Design Precautions]

WARNING

(2) Machine OPR (Original Point Return) of the CPU module’s positioning

function is controlled with two kinds of data: an OPR direction and an OPR

speed. Deceleration starts when the near-point watchdog signal turns on.

If an incorrect OPR direction is set, motion control may continue without

deceleration. To prevent machine damage caused by this, configure an

interlock circuit external to the programmable controller.

(3) When the CPU module detects an error during operation of the CPU

module’s positioning function, the motion slows down and stops.

(4) When the programmable controller detects an abnormal condition, it stops

the operation and the output status is as follows:

• If the overcurrent or overvoltage protection of the power supply

module is activated, all outputs are turned off.

• If the self-diagnostics function of the CPU module detects an error

such as a watchdog timer error, all outputs are held unchanged or

turned off according to the parameter setting.

All outputs may turn on if an error occurs in a part, such as an I/O control

part, where the CPU module cannot detect any error. To ensure safety

operation in such a case, provide a safety mechanism or a fail-safe circuit

external to the programmable controller. For a fail-safe circuit example,

refer to "GENERAL SAFETY REQUIREMENTS" in this manual.

(5) Outputs may remain on or off due to a failure of an output circuit relay or

transistor. Configure an external circuit for monitoring output signals that

could cause a serious accident.

●In an output circuit, when a load current exceeding the rated current or an

overcurrent caused by a load short-circuit flows for a long time, it may cause

smoke and fire. To prevent this, configure an external safety circuit, such as a

fuse.

●Configure a circuit so that the programmable controller is turned on first and

then the external power supply. If the external power supply is turned on first,

an accident may occur due to an incorrect output or malfunction.

●Configure a circuit so that the external power supply is turned off first and then

the programmable controller.

If the programmable controller is turned off first, an accident may occur due to

an incorrect output or malfunction.

[Design Precautions]

WARNING

●For the operating status of each station after a communication failure, refer to

relevant manuals for the network. Failure to do so may result in an accident

due to an incorrect output or malfunction.

●When changing data of a running programmable controller from a peripheral

connected to the CPU module or from an external device such as a personal

computer connected to an intelligent function module, configure an interlock

circuit in the program to ensure that the entire system will always operate

safely.

For other controls to a running programmable controller (such as program

modification or operating status change), read relevant manuals carefully and

ensure the safety before the operation.

Especially, in the case of a control from an external device to a remote

programmable controller, immediate action cannot be taken for a problem on

the programmable controller due to a communication failure. To prevent this,

configure an interlock circuit in the program, and determine corrective actions

to be taken between the external device and CPU module in case of a

communication failure.

●An absolute position return by the CPU module’s positioning function may turn

off the servo-on signal (servo off) for approximately 20ms, and the motor may

run unexpectedly. If this causes a problem, provide an electromagnetic brake

separately to lock the motor during absolute position return.

●Do not write any data to the "system area" or "write-protect area" (R) of the

buffer memory in an intelligent function module.

Also, do not turn on any “use prohibited” signal that is output from the CPU

module to the intelligent function module.

Doing so may cause malfunction of the programmable controller system.

●When setting auto refresh parameters, specify "Y" for the remote output RY

refresh devices. Specifying any other than "Y" (for example, M or L) will hold

the previous device status in the case of a CPU stop. For information on how

to stop the data link, refer to the MELSEC-L CC-Link System Master/Local

Module User's Manual.

●Disconnection of a communication cable (such as a CC-Link dedicated cable)

may make the line condition unstable, causing communication errors on

multiple stations on the network. Configure an interlock circuit in the program

so that the system will operate safely even if these communication errors

occur on multiple stations. Failure to do so may result in an accident due to an

incorrect output or malfunction.

[Design Precautions]

WARNING

Precautions for using digital-analog converter modules

and analog input/output modules

●When a module is faulty, analog outputs may remain on. Configure an external

circuit for monitoring output signals that could cause a serious accident.

Precautions for using high-speed counter modules and

flexible high-speed I/O control modules

●Outputs may remain on or off due to a failure of a transistor for external output.

Configure an external circuit for monitoring output signals that could cause a

serious accident.

Precautions for using positioning modules

●Configure safety circuits external to the programmable controller to ensure

that the entire system operates safely even when a fault occurs in the external

power supply or the programmable controller. Incorrect output or malfunction

due to a communication failure may result in an accident.

(1) Machine OPR (Original Point Return) is controlled by two kinds of data: an

OPR direction and an OPR speed. Deceleration starts when the near-point

watchdog signal turns on. If an incorrect OPR direction is set, motion

control may continue without deceleration. To prevent machine damage

caused by this, configure an interlock circuit external to the programmable

controller.

(2) When the module detects an error, the motion slows down and stops or the

motion suddenly stops, depending on the stop group setting in parameter.

Set the parameter according to the positioning system specifications. In

addition, set the OPR parameter and positioning data within the parameter

setting range.

(3) Outputs may remain on or off, or be undefined due to a failure of a

component such as an insulated element or transistor in an output circuit,

where the CPU module cannot detect any error. Configure an external

circuit for monitoring output signals in a system where an incorrect output

could cause a serious accident.

●An absolute position restoration by the positioning function may turn off the

servo-on signal (servo off) for approximately 60ms + scan time, and the motor

may run unexpectedly. If this causes a problem, provide an electromagnetic

brake to lock the motor during absolute position restoration.

[Design Precautions]

WARNING

Precautions for using flexible high-speed I/O control

modules

●When changing setting data and operating status of the running module from

a personal computer, configure an interlock circuit external to the

programmable controller to ensure that the entire system operates safely.

In addition, before performing online operations for the running module from a

personal computer, determine corrective actions to be taken in case of a

communication failure due to poor contact of cables.

CAUTION

●Do not install the control lines or communication cables together with the main

circuit lines or power cables. Keep a distance of 100mm or more between

them. Failure to do so may result in malfunction due to noise.

●During control of an inductive load such as a lamp, heater, or solenoid valve, a

large current (approximately ten times greater than normal) may flow when the

output is turned from off to on.

Therefore, use a module that has a sufficient current rating.

●Time from when the CPU module is powered on or is reset to when it enters in

RUN status depends on the system configuration, parameter settings, and

program size. Design the program so that the entire system will always

operate safely, regardless of the time.

Precautions for using dual channel isolated high

resolution analog-digital converter modules

●Do not install the analog signal cable together with main circuit lines, power

cables, or load circuit lines of a device other than the programmable controller.

Install the analog output cable 150mm away from the above lines and cables.

Failure to do so may result in malfunction due to noise.

[Design Precautions]

[Installation Precautions]

CAUTION

Precautions for using digital-analog converter modules

and analog input/output modules

●At power-on, a voltage may occur or a current may flow between output

terminals for a moment. In this case, start the control after analog outputs

become stable.

●Power on or off the external power supply while the programmable controller

is on. Failure to do so may result in incorrect output or malfunction.

Precautions for using flexible high-speed I/O control

modules

●Do not install the control lines or communication cables together with the main

circuit lines or power cables. Keep a distance of 150mm or more between

them. Failure to do so may result in malfunction due to noise.

WARNING

●Shut off the external power supply for the system in all phases before

mounting or removing the module. Failure to do so may result in electric shock

or cause the module to fail or malfunction.

[Installation Precautions]

[Wiring Precautions]

CAUTION

●Use the programmable controller in an environment that meets the general

specifications described in this manual. Failure to do so may result in electric

shock, fire, malfunction, or damage to or deterioration of the product.

●To interconnect modules, engage the respective connectors and securely lock

the module joint levers until they click. Incorrect interconnection may cause

malfunction, failure, or drop of the module.

●Do not directly touch any conductive part of the module. Doing so can cause

malfunction or failure of the module.

●Securely connect an extension cable to the connectors of a branch module

and an extension module. After connection, check that the cable is inserted

completely. Poor contact may cause malfunction.

●Securely install the SD memory card pushing the card into the SD memory

card installation slot. After installation, check that the SD memory card is

installed completely. Poor contact may cause malfunction.

●Keep in mind that there is a possibility that the unit is high temperature, during

turning on electricity and immediately after power supply interception.

●Do not directly touch any conductive part and electronic components of the

module and the SD memory card. Doing so can cause malfunction and failure

of the module and the SD memory card.

WARNING

●Shut off the external power supply for the system in all phases before wiring.

Failure to do so may result in electric shock or cause the module to fail or

malfunction.

●After installation and wiring, attach the included terminal cover to the product

before turning it on for operation. Failure to do so may result in electric shock.

Precautions for using flexible high-speed I/O control

modules

●When connecting a differential output terminal to the differential receiver of a

drive unit, connect a high-speed output common terminal to the common

terminal of the differential receiver of the drive unit. Failure to do so may cause

the module to fail or malfunction because of the potential difference that

occurs between the high-speed output common terminal and the differential

receiver common terminal.

[Wiring Precautions]

CAUTION

●Ground the FG and LG terminals to the protective ground conductor

dedicated to the programmable controller. Failure to do so may result in

electric shock or malfunction.

●Use applicable solderless terminals and tighten them within the specified

torque range. If any spade solderless terminal is used, it may be disconnected

when a screw on the terminal block comes loose, resulting in failure.

●Check the rated voltage and terminal layout before wiring to the module, and

connect the cables correctly. Connecting a power supply with a different

voltage rating or incorrect wiring may cause a fire or failure.

●Connectors for external device connection must be crimped or pressed with

the tool specified by the manufacturer, or must be correctly soldered.

Incomplete connections could result in short circuit, fire, or malfunction.

●Connect the connector to the module securely.

●Do not install the control lines or communication cables together with the main

circuit lines or power cables. Keep a distance of 100mm or more between

them. Failure to do so may result in malfunction due to noise.

●Place the cables in a duct or clamp them.

If not, dangling cables may swing or inadvertently be pulled, resulting in

damage to the module or cables or malfunction due to poor connection.

●Confirm the interface type in advance and connect the cable correctly.

Connecting a cable to a different interface or incorrect wiring will cause failure

of the module and the external device.

●Tighten the screws on the terminal block within the specified torque range.

Undertightening can cause short circuit or malfunction. Overtightening can

damage the screw and/or module, resulting in drop, short circuit, fire, or

malfunction.

●When disconnecting the cable from the module, do not pull the cable by the

cable part.

For a cable with connector, hold the connector by hand and pull it out. For a

cable connected to a terminal block, loosen the terminal block screws first

before removing the cable.

Failure to do so may result in malfunction and damage to the module or cable.

●Prevent foreign matter such as dust or wire chips from entering the module.

Such foreign matter can cause a fire, failure, or malfunction.

[Wiring Precautions]

CAUTION

●A protective film is attached to the top of the module to prevent foreign matter,

such as wire chips, from entering the module during wiring. Do not remove the

film during wiring. Remove it for heat dissipation before system operation.

●For the CC-Link system, use dedicated cables that are specified by the

manufacturer. If any other cable is used, performance of the CC-Link system

is not guaranteed. Also, the maximum overall cable length and the station-to-

station cable length must meet those specified in the MELSEC-L CC-Link

System Master/Local Module User’s Manual. If not, normal data

communication is not guaranteed.

●To use the high-speed counter function of the CPU module, ground the

shielded cable to the encoder (relay box). Failure to do so may cause

malfunction.

●Mitsubishi Electric programmable controllers must be installed in control

panels. Connect the main power supply to the power supply module in the

control panel through a relay terminal block. Wiring and replacement of a

power supply module must be performed by qualified maintenance personnel

who is familiar with protection against electric shock.

For wiring methods, refer to the MELSEC-L CPU Module User's Manual

(Hardware Design, Maintenance and Inspection).

Precautions for using high-speed counter modules

●Ground the shield cable on the encoder side (relay box). Always ground the

FG and LG terminals to the protective ground conductor. Failure to do so may

cause malfunction.

Precautions for using CC-Link/LT master module

●For the CC-Link/LT, use the cables specified by the CC-Link Partner

Association. The performance of the CC-Link/LT cannot be assured if any

other cables than the specified are used. For the network wiring, follow the

specifications described in MELSEC-L CC-Link/LT Master Module User's

Manual. Normal data communication is not guaranteed if the wiring is not

conducted according to the specifications.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Controladores de Mitsubishi Electric

Mitsubishi Electric

Mitsubishi Electric RD77MS2 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F FX5 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric FX2N-32CCL Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC-QS Series Guía del usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Central Controller G-50A Manual de usuario

Mitsubishi Electric

Mitsubishi Electric C80 Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric melsec q26ud(e)hcpu Manual de usuario

Mitsubishi Electric

Mitsubishi Electric FX3U-64CCL Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC FX Series Manual del propietario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric CR750-D Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC LJ72GF15-T2-U-HW Manual de instrucciones

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Manual del propietario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Manual del propietario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R16MTCPU Manual del propietario

Mitsubishi Electric

Mitsubishi Electric CR750 Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F FX6U Instrucciones de uso

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Manual de usuario

Mitsubishi Electric

Mitsubishi Electric AG-150A Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
