1Insert the IC chip included with the 3 liter ink bottle.
• When you insert the IC chip, the ink remain lamp lights orange and a buzzer sounds.
• Insert the IC chip with the metal part facing rear side and down. If you insert the wrong side by accident, it causes faulty or
damage of the IC chip.
• Do not touch the metal part of the IC chip. It may break the IC chip by static, or may cause read error by stain or flaw.
2IC chip charging starts automatically.
• The information on the IC chip,such as ink volume and expiration date, is loaded and managed
by the printer.
• The ink remain lamp flashes orange.
3When charging is complete, remove the IC chip.
• When charging is complete, the ink remain lamp will flash orange and green, and a buzzer will
sound.
1. The ink remaining amount indicator is only rough standard. For ink filling, it is recommended to check the liquid level from the mouth for adding ink.
2. “INK NEAR END” at 500cc and“INK END” at 300cc.
3. The ink tank set in this unit can replenish the ink by up to 3.6L, but there is a possibility that ink would spill from the mouth for adding ink. When the orange lamp is lit,
please do not replenish the ink.
• Be sure to charge the IC chip whenever ink is added. Otherwise, the
printer will be unable to manage the ink information.
• Do not remove the IC chip or turn off the printer during charging. Doing
so will prevent the information on the IC chip from being charged
correctly.
• After charging is complete, be sure to remove and dispose of the IC
chip. Do not reuse IC chips.
• If the error message “INVALID INK CHARGE”appears on the display
• Charging was not possible for one or more of the following reasons:
(1) Faulty IC chip
(2) When the remaining charge amount, that is managed by the
machine, is greater than or equal to three liters
(3) Attempting to charge ink that has passed its expiration date
• For more information about errors, press the [ENTER] key in Local.
• To retry charging, select the "Ink Charge"maintenance function.
Ink remain
lamp
Metal part facing rear side
