Mighty Clean MC1500 Manual de usuario

Electric High-Pressure Washer - Operator’s Manual

Before operating this product, please read this manual thoroughly and retain it for

future reference.

MC1500

English 1

1-866-902-9690

www.MightyCleanUSA.com

Do not return product to place of purchase. If you have any

questions, call our toll-free hotline.

1-866-902-9690

www.MightyCleanUSA.com

Before each use, please read all of the safety precautions.

Please pay particular attention to all sections with the following symbols:

Could cause injury or death if not followed.

Could damage machine if not followed.

When using this product, basic precautions should always be followed, including:

1 Read all instructions before using the product.

2 To reduce the risk of injury, do not operate the product near children.

3 Learn how to stop this product and release pressure quickly. Be thoroughly familiar with the controls.

4 Stay alert - watch what you are doing.

5 Do not operate this product when fatigued or under the inﬂuence of alcohol or drugs.

6 Keep operating area clear of all people and pets.

7 Do not stand on unstable surfaces. Do not overreach or stand on unstable support. Keep good

footing and balance at all times.

8 Follow the maintenance instructions speciﬁed in the manual.

9 This product is provided with a Ground Fault Circuit Interrupter (GFCI) built into the

power cord. If replacement of the plug or cord is needed, use only manufacturer replacement parts.

10 This product or its power cord contains lead, a chemical known to cause cancer, birth defects or

other reproductive harm. Wash hands after handling.

English 1

WARNING

CAUTION

Important Safety Instructions..................................................................................................1

Safety Features……………………….....................................................................................4

Parts List and Diagram...........................................................................................................5

Assembly and Operation Instructions.....................................................................................6

Machine Assembly.................................................................................................6

Operation Instructions............................................................................................8

Working with Detergents........................................................................................8

Taking a Break........................................................................................................9

Shutting Down and Cleaning Up............................................................................9

Winterizing and Long-Term Storage.....................................................................................10

Cleaning and Maintenance...................................................................................................11

Troubleshooting.....................................................................................................................12

Technical Data......................................................................................................................16

Warranty................................................................................................................................17

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS

Risk of Injury

Injection Hazard

• Product can cause serious injury if the spray penetrates the skin.

• Do not point the gun at anyone or any part of the body. In case of penetration, seek medical aid

immediately.

Risk of Injury

Do not direct discharge stream at self or other persons.

• High-pressure jet can be dangerous if misused.

• The jet must not be directed at persons, animals, electrical devices, or the product itself.

Risk of Explosion - Do Not Spray Flammable Liquids

• Do not use acids, alkaline, solvents or any ﬂammable material in this product. These products can

cause physical injuries to the operator and irreversible damage to the pressure washer.

Risk of Electric Shock

• High-pressure jet can be dangerous if misused.

• The jet must not be directed at persons, animals, electrical devices, or the product itself.

Gun Kicks Back

• Hold with both hands.

• The trigger handle safety lock prevents the trigger from being engaged accidentally.

• This safety feature DOES NOT lock trigger in the “On” position.

1. Never operate the product without all components properly connected to the product (handle, gun/

wand assembly, nozzle, etc.).

2. Never operate pressure washer with broken or missing parts. Check product regularly and repair

or replace worn or damaged parts immediately.

3. Never put hand or ﬁngers over the nozzle or spray tip while operating the product.

4. Never spray ﬂammable liquids or use pressure washer in areas containing combustible dust, liquids

or vapors. An electric spark could cause an explosion.

5. Never leave the wand unattended while the product is running or switched on.

6. Never disconnect the high-pressure discharge hose from the product while the system is

pressurized. To release pressure from the product, turn power and water supply off, then depress

trigger 2-3 times.

7. Never cover the pressure washer during operation to allow free air cooling.

NOTE: Failure to follow the rules listed below can void the warranty on this product.

WARNING

CAUTION

IMPORTANT SAFETY INSTRUCTIONS

GENERAL SAFETY AND OPERATION RULES

2 English

Connect directly to outlet. Do not use product with extension cord. The use of an extension

cord could override the GFCI built into the plug of the power supply cord resulting in the risk of

electrical shock.

8. Always wear safety glasses or goggles when operating or performing maintenance.

9. Always move switch on product to “Off” position before connecting or disconnecting power cord to

electrical outlets.

10.Always turn water supply on before turning pressure washer on unless draining for storage.

Running pump dry causes serious damage.

11.Always hold trigger handle and wand ﬁrmly when starting and operating the product.

12.Always follow detergent manufacturer’s label recommendations for proper use of detergents. Always

protect eyes, skin and respiratory system from detergent if used.

13.Always lock the trigger of the trigger handle in the safety position when not in use.

14.Do not use pressure that exceeds the operating pressure of any of the parts (hoses, ﬁttings, etc.) in

the pressurized system. Never use with any other manufacturer’s accessories or components.

15.Do not spray electrical apparatus and wiring or the product itself.

16.Do not operate the pressure washer with the inlet water ﬁlter removed. Keep ﬁlter clear of debris and

sediment.

17.Discharge residual pressure by depressing the trigger until no more water comes out of the nozzle.

18.Keep clear of nozzle. Never direct high-pressure spray at any person, animal or self.

19.To minimize the amount of water getting into the pressure washer, the product should be placed as

far as possible from the cleaning site during operation.

This pressure washer is provided with a Ground Fault Circuit Interrupter (GFCI) built into the power

supply cord. This device provides additional protection from the risk of electrical shock. Should

replacement of the plug or cord become necessary, use only manufacturer replacement parts that

include GFCI protection. All services must be done by an Authorized Service Technician. Unauthorized

service will void warranty. See Page 4 for testing procedure.

In a double-insulation product, two systems of insulation are provided instead of grounding.

No grounding is provided on a double-insulated product, nor should a means for grounding

be added to the product.

Servicing a double-insulated product requires extreme care and knowledge of the system,

and should be done only by authorized service technician. Replacement parts of a double-

insulated product must be manufacturer replacement parts. A double-insulated product

is marked with the words “DOUBLE-INSULATION” or “DOUBLE-INSULATED”. The

symbol “ ” may also be marked on the product.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

GROUND FAULT CIRCUIT INTERRUPTER PROTECTION

DOUBLE-INSULATION INSTRUCTION

SAVE THESE INSTRUCTIONS

English 3

The pressure washer is also equipped with a main power On/Off switch located on the

product. It should always be moved to the “Off” position when the pressure washer is not being

used to prevent possible injury or damage.

This product has been designed for use with detergents that are specically approved for

pressure washer use. The use of other cleaning detergents may affect the operation of the

product and void the warranty.

Extension cords are not recommended unless these are plugged into a GFCI protected outlet.

The pressure washer is equipped with a total stop system (TSS) that will sense when the trigger on

the handle is depressed or released. It will open the power circuit to the motor, and cause the pressure

washer motor to stop. The motor will start again when the trigger is depressed.

If possible, do not use extension cords with this product. However, if you must use one, observe all of

the warnings and instructions listed below:

Ground Fault Circuit

Interrupter Protection

This device provides additional protection from the risk of

electrical shock. Plug the Ground Fault Circuit Interrupter

(GFCI) into a power outlet. Indicator should turn red. TEST

BEFORE EACH USE. Press the “TEST” button. Red

indicator should disappear. Press “RESET” button again for

use. Do not use if above test fails.

Use a Sufcient Gauge:

Maximum extension cord length: 50’. Only use 12 or 14 AWG rated extension cords.

• Use only extension cords that are intended for outdoor use. These extension cords are identiﬁed by a

marking that reads “Acceptable for use with outdoor appliances; store indoors while not in use.”

• Use only extension cords having an electrical rating not less than the rating of the product.

• Do not use damaged extension cords. Examine extension cord before using and replace if damaged.

Do not abuse extension cord and do not yank on any cord to disconnect.

• Keep cord away from heat and sharp edges.

• Always disconnect the extension cord from the outlet before disconnecting the product from the

extension cord.

• To reduce the risk of electric shock, keep all connections dry and off the ground. Do not touch plug

with wet hands.

WARNING

CAUTION

WARNING

SAFETY FEATURES

TOTAL STOP SYSTEM

EXTENSION CORD

4 English

PARTS LIST AND DIAGRAM

Item No. Quantity Part Name

1 1 Handle

2 1 Gun Holder

3 1 Power Cord Bracket

*4 1 Water Filter Screen

5 1 Adjustable Wand

6 1 Trigger Handle

7 1 High-pressure Hose

8 1 Detergent Tank

9 4 Screws

10 1 Tip Cleaning Needle

* Water ﬁlter comes pre-attached on the water inlet, located on the front of the pressure

washer.

On/Off

Switch

English 5

Surface Preparation

Before starting any cleaning task, it is important to inspect the area for objects that could create a

hazard. Remove any objects from the work area that could be tripped over, such as toys or outdoor

furniture. Ensure that all doors and windows are closed tightly.

Water Supply (Cold Water Only)

Only draw cold water through the washer. For use with cold water supply only. Water hose must be at

least a 1/2” (13 mm) in diameter. Flow rate of water supply must not fall below 2 GPM (gallons per

minute). Flow rate can be determined by running the water for one minute into an empty 5-gallon

container. Measure the volume of water in the bucket after one minute. The water supply temperature

must not exceed 104°F (40°C).

ASSEMBLY AND OPERATION INSTRUCTIONS

• Never use the pressure washer to draw in water contaminated with solvents (e.g. paint

thinners, gasoline, oil, etc.).

• Dirt in the water inlet will damage the pressure washer. To avoid this risk, we recommend

inspecting and cleaning water inlet regularly.

• Always prevent debris from being drawn into the washer by using a clean water source and an

additional accessory water lter if required.

• To prolong the life of the washer, rest the washer for 5 minutes after every 30 minutes of use.

CAUTION

MACHINE ASSEMBLY

Assemble handle onto pressure washer.

Tighten all screws.

Attach high-pressure hose to the trigger

handle (hand tighten only).

Attach gun holder and power cord bracket.

Attach high-pressure hose to the washer’s

water outlet (hand tighten only).

6 English

ASSEMBLY AND OPERATION INSTRUCTIONS

CAUTION

Attach the garden hose to the water inlet

(hand tighten only).

Make sure the On/Off switch is in the “Off”

position.

To allow air to escape from the hose,

depress the trigger on the trigger handle

until there is a steady stream of water.

Insert adjustable wand to the trigger handle

and twist 1/4 turn to lock in position.

Attach garden hose to water supply and turn

water valve on to the full “On” position.

Completely unwind power cord and plug the

GFCI into an outlet, ensure there are no other

items using the circuit. The GFCI plug light

will turn red if the outlet has power.

Turn switch to “On” position. Note: If no sound

is heard this is normal, follow the Operator’s

Manual for proper operation.

Drain pressure washer after each

use.

For storage: remove water

connection, turn on the washer for

a few seconds and press trigger

handle to purge remaining water in

the pump. Turn off immediately.

ON(I)

OFF(O)

English 7

ASSEMBLY AND OPERATION INSTRUCTIONS

Working with detergent ensures a quick soaking of the dirt, and allows the high-pressure water to

penetrate and remove the dirt more effectively.

To apply detergents you must be operating at low-pressure. This provides a gentle application of

detergent, with the pressure equivalent to a garden hose. The high-pressure setting is used for cleaning,

you cannot apply detergents when working at high-pressure.

Always test detergent in an inconspicuous area before use.

NO BLEACH

Only use cleaning detergents recommended for pressure washers.

Jet spray adjustment is very strong. Do not adjust while spraying.

CAUTION

WORKING WITH DETERGENTS

OPERATION INSTRUCTIONS

Jet

Fan

Adjustable Spray Nozzle

The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted by turning the nozzle.

Insert the male end of the tank wand into

the trigger handle ﬁrmly. While pushing in

the tank ﬁrmly, turn clockwise until tabs

lock into place to ensure a leak free

connection. Fill tank with approved

pressure washer detergents / soaps only.

Engage trigger handle safety lock.

8 English

Tabla de contenidos

Otros manuales de Hidrolavadora de Mighty Clean

Mighty Clean

Mighty Clean MC1800 Manual de usuario

Mighty Clean

Mighty Clean MC2200BL Manual de usuario

Mighty Clean

Mighty Clean MC4050PB Manual de usuario

Manuales populares de Hidrolavadora de otras marcas

Shark

Shark RG-232637 Manual de usuario

Shakti Technology

Shakti Technology S3 Manual de usuario

Kärcher

Kärcher K 4 Pure Manual de usuario

Porter-Cable

Porter-Cable D25806-025-2 Manual de usuario

REM POWER

REM POWER HDEm 662 Manual de usuario

Landa

Landa HS-3000 Manual de usuario

Craftsman

Craftsman 580.752270 Manual de usuario

HIKOKI

HIKOKI AW 100 Manual de usuario

Delco

Delco DC 1302 Manual de usuario

Kärcher

Kärcher K 3 Full Control Manual de usuario

BIEMMEDUE

BIEMMEDUE 120/10 - 170/13 Manual de usuario

ARKSEN

ARKSEN 014-HG-14141-HR Manual de usuario

Black & Decker

Black & Decker PW1700SPX Manual de usuario

Kärcher

Kärcher 595 - SPARE Guía

Kranzle

Kranzle B 10 200 Manual de usuario

Stihl

Stihl RE 90 Manual de usuario

Husky

Husky HU80911 Manual de usuario

PowR-Quip

PowR-Quip PQ-2600 Manual de usuario
