MODEL:360484Read all instructions and explanations forthe installation before use. Follow theinstructions carefully. Keep the operationinstructions handy for later use. If theappliance is sold or passed on, ensurethat the new owner always receives this operation instructions.delete installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the product is sold or passed on then ensure that the new owner always receives thismanual.MODEL:

CONTENTS1Safety Instructions Safety Instructions ..................................................Installation Product Description ................................................ Installation ...........................................................Operations Quick Start ............................................................. Before Each Washing .............................................. Detergent Dispenser ............................................... Control Panel ......................................................... Option.................................................................... Programmes .......................................................... Washing Programmes Table .....................................Maintenances Cleaning and Care ................................................. Trouble Shooting .................................................... Technical Specifications ......................................... Testing methods .....................................................2891213141516202122252627

For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life.Explanation of the symbols:

This combination of symbol and signal word indicates a potentially dangerous situation which may result in death or serious injuries unless it’s avoided.Warning!This combination of symbol and signal word indicates a potentially dangerous situation which may result in slight or minor injuries.Note!This combination of symbol and signal word indicates a potentially dangerous situation which may result in slight or minor injuries or damage to property and the environment.Caution!SAFETY INSTRUCTIONSSafety InstructionsWarning!If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent.2

• The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.• Before any maintenance the device, unplug the appliance from the mains.• Always unplug the machine and turn off the water supply after use. The max. inlet water pressure, in pascals. The min. inlet water pressure, in pascals.• To ensure your safety, power plug must be inserted into an earthed three-pole socket. Check carefully and make sure that your socket is properly and reliably earthed.• Make sure that the water and electrical devices must be connected by a qualified technician in accordance with the manufacturer's instructions and local safety regulations. Risk to children!• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.• Children of less than 3years should be supervised to ensure that they do not play with appliance.• Animals and children may climb into the machine. Check the machine before every operation.• Children should be supervised to ensure that they do not play with the appliance.SAFETY INSTRUCTIONSThe electric shock!Warning!3

• Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result.• Glass door may be very hot during the operation. Keep kids and pets far away from the machine during the operation very wet rooms as well as in the rooms with explosive or caustic gas.• Plug must be accessible after installation.Risk of explosion!• • Do not wash or dry articles that have been cleaned in, washed in, soaked in, or dabbed with combustible or explosive substances( such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents, kerosene, etc.) This may result in fire or explosion.Before hand thoroughly rinse items of washing by hand.SAFETY INSTRUCTIONS4

• This washing machine is for indoor use only. • The maximum inlet water pressure:1.0Mpa.• The minimum inlet water pressure:0.05Mpa.• It isn't intended to be built-in using.• The openings must not be obstructed by a carpet.• Washing machine shall not be installed in bath room or very wet rooms as well as in the rooms with explosive or caustic gases.• The washing machine with single inlet valve only can be connected to the cold water supply. The product with double inlet valves should be correctly connected to the hot water and cold water supply.• Plug must be accessible after installation.Installing the product!Caution!• Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result.5SAFETY INSTRUCTIONS

Risk of damaging appliance!• Your product is only for home use and is only designed for the textiles suitable for machine washing.• Do not climb up and sit on top cover of the machine.• Do not lean against machine door.• Cautions during Handling Machine: 1.Transport bolts shall be reinstalled to the machine by a specialized person. 2.The accumulated water shall be drained out of the machine. 3.Handle the machine carefully. Never hold each protruded part on the machine while lifting. Machine door can not be used as the handle during the conveyance. 4.This appliance is heavy. Transport with care. • Please do not close the door with excessive forces. If it is found difficult to close the door, please check if the clothes are put in or distributed well.• It is forbidden to wash carpets.Operating the appliance!• The maximum mass of dry cloth in kilograms: 8.0kg.• Before washing the clothes at first time, the product shall be operated in one round of the whole procedures without the clothes inside.• Flammable and explosive or toxic solvents are forbidden. Gasoline and alcohol etc.Shall not be used as detergents. Please only select the detergents suitable for machine washing, especially for drum.SAFETY INSTRUCTIONS6

• Make sure that all pockets are emptied. Sharp and rigid items such as coin,brooch,nail,screw or stone etc. may cause serious damages to this machine.• Please check whether the water inside the drum has been drained before opening its door.Please do not open the door if there is any water visible.• Be careful of burning when the product drains hot washing water.• Never refill the water by hand during washing.• After the program is completed, Please wait for two minutes to open the door. This marking indicates that this product should not be disposed with other household wastes throughout the EU.To prevent possible harm to the environment or human health from uncontrolled waste disposal,recycle it responsibly to promote the sustainable reuse of material resources.To return your used device, please use the collection systems or contact the retailer where the product was purchased. They return and can take this product for environmental safe recycling.

Packaging/Old appliance

SAFETY INSTRUCTIONS7

AccessoriesProduct DescriptionTransport plughole Supply hosecold water

• The product line chart is for reference only, please refer to real product as standard.

Note!Drum Power supply cordControl panel

Detergent dispenser

Service filterDoor

Water supply hose

Top cover Drain hoseOwner’s manualINSTALLATION8

Installation Before installing the machine, the location characterized follows shall be selected:1.Rigid, dry, and level surface 2.Avoid direct sunlight3.Sufficient ventilation4.Room temperature is above 0℃ 5.Keep far away from the heat resources such as coal or gas.as Unpacking the washing machine1. Remove the cardboard box and styrofoam packing.2. Lift the washing machine and remove the base packing.3. Remove the tape securing the power supply cord and drain hose.4. Remove the inlet hose from the drum.Make sure the small triangle foam is removed with the bottom one together. If not, lay the unit down with side surface, then remove the small foam from the unit bottom manually.Please take the following steps to remove the bolts:1.Loosen 4 bolts with spanner and then remove them.2.Stop the holes with transport hole plugs.3.Keep the transport bolts properly for future use.Remove transport bolts•• Stability is important to prevent the product from wandering!Make sure that the product should not stand on the power cord.Warning!• • Packaging material (e.g. Films, Styrofoam) can be dangerous for children. There is a risk of suffocation ! Keep all packaging well away from children.Warning!

• •product you You must remove the transport bolts from the backside before using the product. You’ll need the transport bolts again if you move the , so make sure keep them in a safe place.
