Midea MA200W75 Manual de usuario

Read This Manual

Use all instructions and explanations on delete installation

before use. Follow the instructions carefully. Keep the operation

instructions handy for later use. If the product is sold or passed

on then ensure that the new owner always receives this manual.

OWNER’S MANUAL

Fully AUTOMATIC WASHING MACHINE

MODEL:

MA200W75

MA200W85

MA200W95

MA200W105D

MA200W130D

Dual Force Pulsator

Easy-to-clean

Metal Lint Fitler

AirFresh

Washing Machine

Fully AUTOMATIC

Technical Information .........................................

CONTENTS

SAFETY INSTRUCTIONS

Safety instructions ................................................. .... ................

INSTALLATION

Product description .............................................. .....

Installation area ................................................. .......

Unpacking the washing machine ........................................

Levelling the washing machine .............................................

Selection of tap .................................................... .... .. . ................

Connection of inlet hose, tap and washing machine....

Preparation before washing...................................... ..

Washing .......................................................... ...........

After washing................................................. .............

Washing matters needing attention ...................................

The usage of detergent and washing powder................

Control pane ............................................................ .l.

Option............................................................ .............

Personalized setting of washing program...................

Operations of washing process....................................

Washing program table .............................. ................ .............

MAINTENANCE

Cleaning and care .............................................. ........

Cleaning the cabinet............................................ ........ ..............

Cleaning drain pump filter .......................................................

Trouble shooting ............ . ................ .................................... .. ......

Energy efficiency test program..............................................

OPERATIONS

Installation of drain hose .........................................................

Instructions for detergents and softeners............

...............

..................

....

............

...................

..................

.....................

......

..........

................

.............

SAFETY INSTRUCTIONS

For your safety, the information in this manual must be followed

to minimize the risk of fire or explosion, electric shock, or to

prevent property damage, personal injury or loss of life.

SAFETY INSTRUCTIONS

• This appliance is not intended for use by persons(including

children) with reduced physical, sensory or mental capabilities

or lack of experience and knowledge unless they have

been given supervision or instruction concerning use of

the appliance by a person responsible for their safety.

•

• The openings must not be obstructed by a carpet.

• This appliance is intended to be used in household and similar

applications such as:

− staff kitchen areas in shops, offices and other working environments;

− farm houses;

− by clients in hotels, motels and other residential type environments;

− bed and breakfast type environments;

− areas for communal use in blocks of flats or in launderettes.

Children should be supervised to ensure that they do not

play with the appliance.

The new hose-sets supplied with the appliance are to be

used and that old hose-sets should not be reused.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons

in order to avoid a hazard.

SAFETY INSTRUCTIONS

Warning!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

death or serious injuries unless it’s avoided.

Explanation of the symbols:

Caution!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

slight or minor injuries or damage to property and the

environment.

Note!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

slight or minor injuries.

Model Washing Capacity Standard Water Pressure

0.03MPa~0.8MPa

7.5kg

MA200W75

0.03MPa~0.8MPa

8.5kg

MA200W85

MA200W95

0.03MPa~0.8MPa

9.5kg

MA200W105D

10.5kg 0.03MPa~0.8MPa

MA200W130D

13.0kg 0.03MPa~0.8MPa

SAFETY INSTRUCTIONS

The electric shock!

Warning!

•

• Hands shall not be inserted into running spin-dry tub .

• If the spin-dry tub does not stop within 15 seconds after

opening the cover , please stop using the machine and

have it repaired.

• Before any maintenance the device, unplug the appliance

from the mains.

• Always unplug the machine and turn off the water supply

after use. The max. inlet water pressure, in pascals. The

min. inlet water pressure, in pascals.

• To ensure your safety, power plug must be inserted into

an earthed three-pole socket. Check carefully and make sure

that your socket is properly and reliably earthed.

• Make sure that the water and electrical devices must be

connected by a qualified technician in accordance with the

manufacturer's instructions and local safety regulations.

Do not put washing machine at humid place.

This appliance is for indoor use only.

• EN countries: the appliance can be used by children aged

from 8 years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

• Animals and children may climb into the machine. Check

the machine before every operation.

• Young children should be supervised that they do not play

with the appliance.

• Machine may be very hot during the operation. Keep kids

and pets far away from the machine during the operation

• Plug must be accessible after installation.

very wet rooms as well as in the rooms with explosive or

caustic gas.

•

• The washing machine with single inlet valve only can be

connected to the cold water supply. The product

inlet valves should be correctly connected to the hot water

and cold water supply.

with double

Remove all packages before using the appliance. Otherwise,

serious damage may result.

Risk of explosion!

•

Do not wash or dry articles that have been cleaned in, washed

in, soaked in, or dabbed with combustible or explosive

substances( such as wax, oil, paint, gasoline, degreasers,

dry-cleaning solvents, kerosene, etc.) This may result in

fire or explosion.

Before hand thoroughly rinse items of washing by hand.

SAFETY INSTRUCTIONS

Risk to children!

• This washing machine is for indoor use only.

• It isn't intended to be built-in using.

• The openings must not be obstructed by a carpet.

• Washing machine shall not be installed in bath room or

very wet rooms as well as in the rooms with explosive

or caustic gases.

• Remove all packages and transport bolts before using

the appliance. Otherwise, serious damage may result.

• The washing machine with single inlet valve only can be

connected to the cold water supply. The product with

double inlet valves should be correctly connected to the

hot water and cold water supply.

• Plug must be accessible after installation.

Risk of damaging appliance!

SAFETY INSTRUCTIONS

Caution

Installing the product!

• Your product is only for home use and is only designed

for the textiles suitable for machine washing.

• Do not climb up and sit on top cover of the machine.

• Do not lean against machine door.

• Cautions during Handling Machine:

1.Transport bolts shall be reinstalled to the machine by

a specialized person.

2.The accumulated water shall be drained out of the

machine.

3.Handle the machine carefully. Never hold each protruded

part on the machine while lifting. Machine door can

not be used as the handle during the conveyance.

4.This appliance is heavy. Transport with care.

Operating the appliance!

• Before washing the clothes at first time, the product

shall be operated in one round of the whole procedures

without the clothes inside.

• Flammable and explosive or toxic solvents are forbidden.

Gasoline and alcohol etc.Shall not be used as detergents.

Please only select the detergents suitable for machine

washing, especially for drum.

• Make sure that all pockets are emptied. Sharp and rigid

items such as coin, brooch, nail, screw or stone etc. may

cause serious damages to this machine.

• Please check whether the water inside the drum has

been drained before opening its door.Please do not open

the door if there is any water visible.

• Be careful of burning when the product drains hot

washing water.

• Never refill the water by hand during washing.

• After the program is completed, Please wait for two

minutes to open the door.

This marking indicates that this product should not be disposed

with other household wastes throughout the EU.To prevent

possible harm to the environment or human health from

uncontrolled waste disposal,recycle it responsibly to promote

the sustainable reuse of material resources.To return your used

device,please use the collection systems or contact the retailer

where the product was purchased. They return and can take this

product for environmental safe recycling.

Packaging/Old appliance

SAFETY INSTRUCTIONS

• Please do not close the door with excessive forces.

• It is forbidden to wash carpets.

INSTALLATION

Product description

• The product line chart is for reference only, please refer to real product as

standard.

Note!

Frame

Top lid

Drain hose

Control panel

Detergent inlet

Softener inlet

Cabinet

Adjustable foot knob

Handle

Water inlet valve

Power case and plug

MA200W75

INSTALLATION

Product description

• The product line chart is for reference only, please refer to real product as

standard.

Note!

Accessories

Inlet hose ass manual screw

cabinet baseboard

• Note: if the drain hose is already installed on the machine, then there is no

spring clamper and drain hose in the accessories.

• The accessories with” * “are only applicable to some models.

Note!

Frame

Top lid

Drain hose

Control panel

Softener, inletDetergent

Cabinet

Adjustable foot knob

Handle

Water inlet valve

Power case and plug

MA200W85

MA200W95

MA200W105D

MA200W130D

spring clamper drain loose ass

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Arandela de Midea

Midea

Midea MFL80-DU1403B/C14E-EU Manual de usuario

Midea

Midea MF200W90WB Series Manual de usuario

Midea

Midea G06 Manual de usuario

Midea

Midea MFWS512 Manual de usuario

Midea

Midea Sicily Glory G01 Manual de usuario

Midea

Midea MSW-7118P Manual de usuario

Midea

Midea MFL70S12 Manual de usuario

Midea

Midea MT725B Manual de usuario

Midea

Midea RW145 Manual de usuario

Midea

Midea KL13TLE4M Manual de usuario

Midea

Midea MTW55 Manual de usuario

Midea

Midea MFES06W50/W-ES Manual de usuario

Midea

Midea LUNAR 01 Manual de usuario

Midea

Midea MWMTL075ZOF Manual de usuario

Midea

Midea MF200W80B/E Manual de usuario

Midea

Midea MG-52-10508 Manual de usuario

Midea

Midea MTE150-P2004S Manual de usuario

Midea

Midea MF200W85B Series Manual de usuario

Midea

Midea MF100W60/W-MV Manual de usuario

Midea

Midea MLH27N4AWWC Manual

Midea

Midea MAE50-S1102GPS Manual de usuario

Midea

Midea FP-92LFC100GMTH-W2 Manual de usuario

Midea

Midea 360471 Manual de usuario

Midea

Midea MAD160-A2801GPS Manual de usuario

Manuales populares de Arandela de otras marcas

Tricity Bendix

Tricity Bendix AW 1000 W Guía del producto

Panasonic

Panasonic NA-F60L5WRB Manual de usuario

GE WSLP1500 Manual

Electrolux

Electrolux EWF1284EDW Manual de usuario

Bosch

Bosch WAN2829BSN Manual de usuario

LG TV2516DV3B Manual de usuario

LG TH2517DSAV Manual de usuario

VESTEL

VESTEL CMH-XL 7510 TE Manual de usuario

AEG

AEG 74335 Manual de operación

Johnson

Johnson JWF721A Manual de usuario

Beko

Beko WTE7604XLW0 Manual de usuario

Danby

Danby DTT100A1WDB Instrucciones de montaje

Amica

Amica WA 14 Ex Manual de usuario

Daewoo

Daewoo DWD-F1222 Manual de usuario

Bosch

Bosch WAS28461AU Manual de usuario

Miele

Miele PW 6080 Vario Manual de usuario

Finlux

Finlux FLX108CF220 Manual de usuario

Whirlpool

Whirlpool 3LBR5132AN0 Manual de usuario
