Midea MFWS512 Manual de usuario

MFWS512

Front Load Washer 5kg

USER MANUAL

CONTENTS

Safety information ........................................ 2-3

Identifying parts of the Washer ........................................ 4

Installation ........................................ 5-7

Control Features and Functions ........................................ 8

Wash Programs ........................................ 9

Wash Guide ........................................ 10-12

Cleaning & Maintenance ........................................ 13-14

Troubleshooting Guide ........................................ 15-16

Repairs, Service & Warranty ........................................ 17

Speciﬁcations ........................................ 18

SAFETY INFORMATION

Congratulations on your new Midea washer. This manual contains important information

on the installation, use and care of your appliance. Please read this manual carefully

before use. Follow instructions and keep the manual for future reference.

WARNING

The WARNING symbol indicates information that concerns your personal safety

WARNING

CAUTION

CAUTION The CAUTION symbol indicates information on avoiding damage to the appliance

Before using your appliance

Before using your washing machine, we recommend you read through this manual which

provides a description of your appliance and its functions. To avoid risk to yourself or

others, it is important that the washing machine is installed correctly and that you read

the safety instructions carefully.

Do not remove the attached adhesive identiﬁcation label containing model number, serial

number and other information as this label will be used by the Midea authorized service

representative in the event that your washing machine needs servicing.

Information on disposal

Most of the packing material used is recyclable. Please separate the plastic and

cardboard and dispose through your local recycling depot or place in appropriate

recycling collection bins.

If disposing of this appliance, please contact your local authority for safe disposal.

Incorrect disposal may cause injury to the user.

WARNING

Keep packaging materials away from children to eliminate risk of suffocation.

This appliance is not intended for use by persons (including children with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

SAFETY INFORMATION

Safety precautions

-Young children should be supervised to ensure that they do not play with the appliance.

-Keep ventilation openings in the appliance enclosure or in the built in structure clear of obstruction.

-Choose a location that is indoors, completely dry and away from damp environments.

-The washer is designed to operate on a single phase power supply within a voltage range of

220~240V/50Hz.

-Please keep the appliance away from substances which could cause ignition.

-Do not store inﬂammable materials such as ether, benzene, LP gas and glue etc near the appliance.

-Do not splash water on the rear of the appliance, for it may cause malfunction or electric

shock.

-Before cleaning the appliance, always switch off and unplug it.

-Do not disassemble any part of the clothes washer.

-Do not insert your hand and remove items from the washer until it has come to a complete stop.

-Do not splash, wet or hose down the appliance. It is recommended to use a damp cloth when

cleaning the cabinet.

-Do not attempt to wash fabrics that contain latex or rubber material.

-Do not place items that have come in contact with any ﬂammable materials such as

petrol/gasoline, kerosene, cleaning solvents, vegetable oil, cooking oil or any explosive

substances.

-Do not place heat sources (candle, heater, etc.) on top of or near the washer.

-Do not sit children or heavy object on top of the washer.

-Do not pull the power cord out of the power socket by the cord. Always unplug the washer holding

the plug.

-If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or

similarly qualiﬁed persons in order to avoid hazard.

IDENTIFYING PARTS OF THE WASHER

Accessories

cold water inlet hose drain hose support transit bolt caps (x4)

detergent dispenser

drawer

service panel

door

control panel

detergent dispenser

power cord with plug

drain hose

adjustable feet (x4)

cabinet

Unpack the clothes washer

INSTALLATION

Remove the clothes washer from the carton. Please dispose of packaging and plastic

bags responsibly.

Open the washer door and remove the accessories from inside the washer (as listed

on page 4).

Select the location

Remove transit bolts

Before installing & using this washing

machine, the transit bolts must be removed

from the backside.

The clothes washer should be located on a ﬁrm and ﬂat surface. An uneven surface may

cause excess operating noise or vibration and effect the performance of the washer.

-The noise may be increased if the ﬂoor is not ﬁrm.

-It is not recommended to place on carpeted ﬂooring. If this can not be avoided, place a

solid sheet under the appliance.

-Choose a location which is indoors, dry & away from high temperature and high

humidity.

-Ensure room temperature is not below 0°C.

-Make sure that air circulation around the machine is not impeded by carpets, rugs etc.

-Check that the machine does not touch the wall or cupboard.

CAUTION

All transit bolts & packaging must be removed before using the appliance.

Loosen all 4 bolts with a spanner to

remove them.

Plug the holes with transit hole caps

provided.

Keep the transit bolts for future use to

protect the drum during transportation.

INSTALLATION

Install the water inlet hose

CAUTION

Be sure to install the inlet hose to COLD water only. Incorrect installation can

reduce performance or damage the clothes washer.

Level the washer

For optimal washing performance, reduced noise

and to minimise vibration, it is important to ensure

the washer is completely ﬂat and level before use.

Use a sprit level to check both horizontal and

vertical stability.

To adjust the feet:

Loosen the lock nut(A).

Adjust each foot(B). Turn left to raise or right to

lower as necessary. Once levelled, try to rock it

from corner to corner. If the washer rocks,

continue to adjust the feet until it is levelled and

no longer rocks.

Once all four feet have been adjusted and the

washer is completely level, tighten the lock

nut(A).

Fasten one end of the inlet hose to the tap.

Ensure there is a rubber washer inside the

hose before fastening. The washer prevents

water leakage.

Securely tighten the other end of the inlet hose

to the clothes washer inlet valve. Ensure the

rubber washer is inside the hose before

tightening.

When tightening the clamping nut, apply even

pressure. Do not apply too much force or twist

the valve as this may damage or break the

valve joint.

INSTALLATION

WARNING

Ensure the clothes washer is securely plugged

into the mains power supply and it is switched to

the ON position.

Ensure your hands are completely dry

before touching the mains outlet, any

electrical plugs or cables.

Connect to a power source

Ensure the water mains are in the open position

and a steady water supply is available to the

clothes washer.

Open the main water supply

Position drain hose

When placing the drain hose, ensure it is above

600m and below 1000mm. Otherwise, the

washer may not drain correctly and an error will

occur.

Ensure the drain hose is placed in a drain with a

diameter of at least 30mm to meet minimum

drainage ﬂow requirements.

Secure the drain hose in place to avoid leaking

and spilling as the water drains.

Do not immerse the drain hose in water.

sink/basin

secure in

place here

bind

drain at least 30mm

diameter

Max. 1000mm

Min. 600mm

Max. 1000mm

Min. 600mm

Program Selector Dial

Turn this dial to select a wash program, the machine will

automatically select the spin speed and temperature for the

selected program. The selector dial can be turned either clockwise

or anticlockwise.

Spin Speed Button

Press this button repeatedly to increase or decrease the spin

speed if you want your laundry spun at a different speed from the

machines default setting on the selected program.

Temperature Button

Press this button repeatedly to increase or decrease the water

temperature if you want your laundry washed at a different

temperature to the machines default setting of the selected

program.

Note: When the light is off, the water temperature will be COLD.

Start/Pause Button

Press this button to start the selected wash program. Once a

wash has begun, press this button to pause the program. Press

again to resume.

Power Button

Press this button to switch the washer on and off. Press once to

switch on, when ﬁnished a wash program, press to switch off.

CONTROL FEATURES AND FUNCTIONS

Foam Detection

Excess soap suds will occur when too much detergent has been added. The Foam

Detection function will automatically sense this and increase the rinse to eliminate

excess suds.

Buzzer Sound

The buzzer sounds once a program has completed. To disable the buzzer function,

power on the washer, press the "Temp" button for 3 seconds, you will hear a

beep, the buzzer will now be disabled. Repeat this process to restore the buzzer

function.

WASH PROGRAMS

Please note: the table above is intended as a reference guide only, individual results may

vary. Total time includes ﬁlling and draining of water. The times mentioned are based on

averages and can be effected by water pressure and drainage speed.

(* See diagram page 11)

Program

Description

Max.

load

(Kg)

Detergent dispenser*

Temp.

Default

Spin

Speed

(RPM)

Total

time

Case

Softener

Cotton

For moderately soiled everday

cottons, bedsheets and towels.

5.0

●

○

90°C

60°C (default)

40°C

20°C

cold

1200

2:10

Synthetic

Normally soiled synthetic and

polycotton ﬁbres. This is a shorter

and gentler wash to the cotton cycle

and suitable for delicate clothes

washing. The detergent quantity

may need reducing due to the nature

of the fabrics.

2.5

●

○

60°C

40°C (default)

20°C

cold

800

1:45

Wool

For woollen articles and silk fabrics

labelled as machine washable. This

program may also be used for

handwash articles. Use detergent

speciﬁc to woollens and delicates.

1.5

●

○

40°C (default)

20°C

cold

400

1:25

Underwear

Speciﬁcally designed for underwear

with a stronger rinse setting and

extra wash cycle.

5.0

●

○

90°C

60°C

40°C (default)

20°C

cold

1200

1:48

Drum

Clean

Use this program for drum cleaning.

With a high temperature wash at 90°

it cleans the drum of detergent

residue, dirt and bacteria. Do not

add any detergent or clothes to the

washer when using this program. It

is recommended you perform a

drum clean after every 40 washes.

90°C (default)

400

1:30

Spin

This separate spin program will drain

any excess water and spin only.

5.0

1200

0:15

Cotton

Intensive

Similar to the cotton wash, this

program offers an additional wash

and rinse cycle to ensure no

detergent residue remains on the

laundry. Suitable for baby clothes

and those with skin allergies.

5.0

●

○

90°C

60°C

40°C (default)

20°C

cold

1200

2:20

Quick

A quick wash for small loads of

lightly soiled articles.

1.5

●

○

40°C

20°C

cold (default)

1200

0:15

● must ○ optional X not available

Tabla de contenidos

Otros manuales de Arandela de Midea

Midea

Midea MA500W21/W Manual de usuario

Midea

Midea MLV45N1B Series Manual

Midea

Midea FP-90LTL060GETL-N Manual de usuario

Midea

Midea MFW-EC850 Manual de usuario

Midea

Midea MF200W85B Series Manual de usuario

Midea

Midea DMWM55 Manual de usuario

Midea

Midea MJ70N68P Manual de usuario

Midea

Midea DMWM55G2 Manual de usuario

Midea

Midea MAV10-A2804PS/01FM-US Manual de usuario

Midea

Midea MA200W80/G-MV Manual de usuario

Midea

Midea MFW-801S Manual de usuario

Midea

Midea MTWM60 Manual de usuario

Midea

Midea RW145 Manual de usuario

Midea

Midea MAE180-2404TPS/01FM Manual de usuario

Midea

Midea MFL80-DU1403B/C14E-EU Manual de usuario

Midea

Midea FP-90LTT060GMTM-B Manual de usuario

Midea

Midea MAE50-S1102GPS Manual de usuario

Midea

Midea MLV47C3AWW Manual

Midea

Midea FP-90LST060GMTL-N Manual de usuario

Midea

Midea MTW55 Manual de usuario

Midea

Midea Sicily Glory G01 Manual de usuario

Midea

Midea MAV160-A2808PS/01FM-US Manual de usuario

Midea

Midea C01 Manual de usuario

Midea

Midea MF700S Manual de usuario

Manuales populares de Arandela de otras marcas

Tricity Bendix

Tricity Bendix AW 1000 W Guía del producto

Panasonic

Panasonic NA-F60L5WRB Manual de usuario

GE WSLP1500 Manual

Electrolux

Electrolux EWF1284EDW Manual de usuario

Bosch

Bosch WAN2829BSN Manual de usuario

LG TV2516DV3B Manual de usuario

LG TH2517DSAV Manual de usuario

VESTEL

VESTEL CMH-XL 7510 TE Manual de usuario

AEG

AEG 74335 Manual de operación

Johnson

Johnson JWF721A Manual de usuario

Beko

Beko WTE7604XLW0 Manual de usuario

Danby

Danby DTT100A1WDB Instrucciones de montaje

Amica

Amica WA 14 Ex Manual de usuario

Daewoo

Daewoo DWD-F1222 Manual de usuario

Bosch

Bosch WAS28461AU Manual de usuario

Miele

Miele PW 6080 Vario Manual de usuario

Finlux

Finlux FLX108CF220 Manual de usuario

Whirlpool

Whirlpool 3LBR5132AN0 Manual de usuario
