METROLOGIC INSTRUMENTS, INC.
MS7120 Orbit®Presentation
Laser Scanner
Installation and User’s Guide
00-02408D_unit_7120_Cover_Oct_2005.qxd 10/26/2005 11:31 AM Page 1
Copyright
© 2005 by Metrologic Instruments, Inc. All rights reserved. No part of this
work may be reproduced, transmitted, or stored in any form or by any means
without prior written consent, except by reviewer,
who may quote brief passages in a review, or provided for in the Copyright
Act of 1976.
Products and brand names mentioned in this document are trademarks of
their respective companies.
ii
TABLE OF CONTENTS
Introduction................................................................................................1
Scanner and Accessories..........................................................................2
Operational Notes .....................................................................................3
Installation
For RS232, OCIA and IBM 46XX Interfaces.........................................4
For Keyboard Wedge Interface.............................................................5
For Stand Alone Keyboard Interface.....................................................6
Notes for USB Interface ........................................................................7
Notes for MS7120-00 'Laser Emulation' ...............................................7
Scanner Parts............................................................................................8
Audible Indicators......................................................................................9
Visual Indicators ......................................................................................10
Failure Modes..........................................................................................11
Labels......................................................................................................12
Maintenance............................................................................................12
Scan Volume Specifications
Optimal Low Density (Default) ............................................................13
Optimal High Density ..........................................................................13
Close...................................................................................................14
Normal.................................................................................................14
Far.......................................................................................................15
Depth of Field by Minimum Bar Code Element Width
Optimal Low Density (Default) ............................................................16
Optimal High Density ..........................................................................17
Close...................................................................................................18
Normal.................................................................................................19
Far.......................................................................................................20
iii
TABLE OF CONTENTS
Installing the Optional Wall/Counter Mount .............................................21
Troubleshooting Guide ............................................................................22
RS-232 Demonstration Program .............................................................27
Applications and Protocols ......................................................................28
Design Specifications ..............................................................................29
Default Settings .......................................................................................31
Scanner and Cable Terminations............................................................36
Limited Warranty .....................................................................................39
Notices ....................................................................................................40
Patents ....................................................................................................44
Index........................................................................................................45
1
INTRODUCTION
Orbit®is an aggressive, omnidirectional laser bar code scanner.
Lightweight and rugged, Orbit is small in size, but BIG in performance.
Designed for applications where counter space is limited, Orbit is the
ideal presentation scanner for retail, convenience, liquor and specialty
stores. In addition, Orbit’s unique, contoured shape allows it to be
picked-up and used as a hand-held scanner when scanning large or
bulky items.
Engineered with a large, easy-to-find optimal scan area, Orbit increases
the first pass read rate for maximum productivity. The scanning head can
be tilted vertically a full 30° for added flexibility when scanning various
sized objects. These features increase the scanning throughput without
increasing the scanner size.
SCANNER INTERFACE
7120-00 Laser Emulation, RS-232 Transmit/Receive
7120-9 OCIA and RS-232 Transmit/Receive (Full RS232 Configurable)
7120-11 IBM 46XX and Full RS-232C
7120-41 Full RS-232C/Light Pen Emulation
7120-47 Keyboard Wedge, Stand-Alone Keyboard and RS-232
Transmit/Receive
7120-62 Ruby with Verifone, RS232
7120-67 Full RS-232C (OCIA Configurable)
Orbit offers a great deal of features to the consumer:
•Fully automatic scanning operation
•PowerLink compatible
•Data editing
•7 beeper tones
•Programmable depth of field
•Easy programming
2
SCANNER AND ACCESSORIES
BASIC KIT
Part # Description
MS7120 Orbit®Presentation Laser Scanner
00-02407 MetroSelect®Programming Guide
00-02408 MS7120 Installation and User’s Guide*
* Available on the Metrologic website - www.metrologic.com
OPTIONAL ACCESSORIES
Part # Description
AC to DC Power Transformer- Regulated 5.2VDC @ 650 mA output.
45-45593 120V United States
45-45591 220V-240V Continental European
45-45592 220V-240V United Kingdom
46-46803 220V-240V Australia
46-46983 220V-240V China
54-54xxx PowerLink Cable with built in power jack
Standard - 2.1m (7') straight cord, short strain relief
53-53xxx PowerLink Cable with built in power jack
Optional - 2.7m (9') coiled cord, long strain relief
xxx specifies connection to the host.
54-54002 Keyboard Wedge PowerLink Cable with Adapter Cable
54-54020 Stand Alone Keyboard PowerLink Cable
Other items may be ordered for the specific protocol being used. To order additional items,
contact the dealer, distributor or call Metrologic’s Customer Service Department at
1-800-ID-METRO or 1-800-436-3876.
3
SCANNER AND ACCESSORIES
OPTIONAL ACCESSORIES
Part # Description
MVC** Metrologic Voltage Converter Cable
+12VDC to +5.2VDC or -12VDC to +5.2VDC
MX009-2** MX009 USB Converter Cable
** Contact a Metrologic customer service representative for additional
information on the MVC and MX009 cable series and the host connections
available.
45-45619 Counter/Wall Mount Kit
Other items may be ordered for the specific protocol being used. To order
additional items, contact the dealer, distributor or call Metrologic’s Customer
Service Department at 1-800-ID-METRO or 1-800-436-3876.
OPERATIONAL NOTES
Metrologic recommends using the external power supply provided with the
scanner when operating the MS7120. When using power supplied by the host,
the host system should supply a minimum of 250 mA of current @ 5VDC.
Orbit is shipped from the factory programmed with default settings. To configure
the MS7120 scanner to meet the host system’s specific needs, refer to the
MetroSelect Programming Guide (MLPN 00-02407B) for instructions on how to
enter the program mode and select the appropriate bar codes.
4
INSTALLATION FOR RS232, OCIAAND IBM 46XX INTERFACES
1. Turn off the host system.
2. Plug the male 10-pin RJ45 end of
the PowerLink cable into the 10-pin
jack on the MS7120.
3. Connect the 9 pin female end of
the PowerLink cable to the host
device.
Note: Skip to #6 if receiving power
from the host system.
4. Plug the power supply’s L-shaped
plug into the power jack on the
PowerLink cable.
5. Check the AC input requirements
of the power supply to make sure
the voltage matches the AC outlet.
The outlet should be installed near
the equipment and be easily
accessible. Connect AC power to
the transformer.
6. Turn on the host system.
Note:
a. When the scanner first receives power, the green LED will turn
on. Then the scanner will beep once and the red LED will flash
simultaneously.
b. Plugging the scanner into the serial port of the PC does not
guarantee that scanned information will appear at the PC. A
software driver and correct configuration setting are also required
for proper communication to occur.
Caution:
To maintain compliance with applicable standards, all circuits connected to the scanner must meet the
requirements for SELV (Safety Extra Low Voltage) according to EN 60950.
To maintain compliance with standard CSA C22.2 No. 950/UL 1950 and norm EN 60950, the power
source should meet applicable performance requirements for a limited power source.
5
INSTALLATION FOR KEYBOARD WEDGE INTERFACE
1. Turn off the PC/Host.
2. Connect the male 10-pin RJ45 end of
the PowerLink cable to the jack on
the MS7120.
3. Connect the L-shaped plug of the
power supply into the power jack on
the PowerLink cable.
4. Make sure the AC input requirements
of the power supply matches the AC
outlet. Plug the power supply into the
AC outlet. The outlet should be near
the equipment and easily accessible.
5. Disconnect the keyboard from the PC.
Note the type of connector on the
keyboard and keyboard port on the PC.
6. The “Y” end of the PowerLink cable
terminates to female 5-pin DIN and
a male 6-pin mini DIN connector. If
necessary attach the supplied
adapter cable to the appropriate
end of the “Y” cable.
7. Connect one end of the “Y” cable to the Keyboard and other end of
the “Y” to the Keyboard port on the PC.
8. Power up the PC.
Manufacturer’s Recommendation:
Powering Orbit directly from the computer can sometimes cause
interference with the operation of the scanner or the computer. Not all
computers supply the same current through the keyboard port, explaining
why a scanner will work on one computer and not another. Metrologic
recommends using an external power supply. For additional information
contact a Metrologic customer service representative.
Caution:
To maintain compliance with applicable standards, all circuits connected to the scanner must meet the
requirements for SELV (Safety Extra Low Voltage) according to EN 60950.
To maintain compliance with standard CSA C22.2 No. 950/UL 1950 and norm EN 60950, the power
source should meet applicable performance requirements for a limited power source.
6
INSTALLATION FORSTANDALONE KEYBOARD INTERFACE
1. Turn off the host system.
2. Plug the male 10-pin RJ45 end of
the PowerLink cable into the
10-pin jack on the MS7120.
3. Connect the PowerLink cable to the
keyboard port on the host system.
4. Plug the power supply’s L-shaped
plug into the power jack on the
PowerLink cable.
5. Check the AC input requirements
of the power supply to make sure
the voltage matches the AC outlet.
The outlet should be installed near
the equipment and be easily
accessible. Connect AC power to
the transformer.
6. Turn on the host system.
Manufacturer’s Recommendation:
Powering Orbit directly from the computer can sometimes cause
interference with the operation of the scanner or the computer. Not all
computers supply the same current through the keyboard port, explaining
why a scanner will work on one computer and not another. Metrologic
recommends using an external power supply. For additional information
contact a Metrologic customer service representative.
Caution:
To maintain compliance with applicable standards, all circuits connected to the scanner must meet the
requirements for SELV (Safety Extra Low Voltage) according to EN 60950.
To maintain compliance with standard CSA C22.2 No. 950/UL 1950 and norm EN 60950, the power
source should meet applicable performance requirements for a limited power source.
Otros manuales para MS7120 Orbit
2
Tabla de contenidos
Otros manuales de Lector de código de barras de Metrologic
Metrologic
Metrologic MK9535-79C5M38 - Metrologic MS9535 VoyagerBT Manual de usuario
Metrologic
Metrologic Stratos MS2x20 Series Instrucciones de instalación y funcionamiento
Metrologic
Metrologic MH941 Manual de usuario
Metrologic
Metrologic IS4910 Series Manual de operación y mantenimiento
Metrologic
Metrologic MS1890 Focus Manual de usuario
Metrologic
Metrologic MS7600 Manual de usuario
Metrologic
Metrologic StratosE MS2122 Manual de usuario
Metrologic
Metrologic IS3480-00 Manual de usuario
Metrologic
Metrologic Eclipse MS5145 Manual de usuario
Metrologic
Metrologic Fusion MS3780 Manual de usuario
Metrologic
Metrologic MK1690-61A38 Manual de usuario
Metrologic
Metrologic IS3480 QuantumE Manual de usuario
Metrologic
Metrologic MK9520-37A38 Manual de usuario
Metrologic
Metrologic MS 1690 Focus Series Manual de usuario
Metrologic
Metrologic MS1633 FocusBT Manual de usuario
Metrologic
Metrologic Stratos MS2xxx Series Instrucciones de instalación y funcionamiento
Metrologic
Metrologic MS1633 FocusBT Manual de usuario
Metrologic
Metrologic Genesis MS7580 Manual de usuario
Metrologic
Metrologic MS9530 Series Manual de usuario
Metrologic
Metrologic Cubit MS6520 Series Manual de usuario
