MS700i Series Laser Bar

Code Projection Scanner

Installation and User’s Guide

MLPN 2178

Printed in USA

October 1998

iii

Table of Contents

Introduction .................................................. 1

Unpacking List ................................................. 2

Scanner Connections to the Host ................................... 3

Configuration of the Scanner to the Host System ...................... 4

Cloning Feature ................................................ 5

Version 11 IBM 46XX Scanner ................................... 6

Configuring the Scanner .................................. 7

Configuring the IBM 46XX ............................... 8

IBM 4683 and 4693 Terminals Driven by a 46XX Store

Controller Running 4680.OS or 4690.OS ............ 8

IBM 4684 and 4694 Systems .............................. 8

Scanner Installation to a PC Keyboard Port ....................... 9, 10

PC Application Note ........................................... 11

Installation of the MS700 Series Stand ............................. 12

Attaching the Scanner to the Stand ................................ 13

MS700iand MS720iFeatures ................................... 14

Visual Indicators ........................................... 15-18

Volume Settings ............................................... 19

Labels ....................................................... 20

InfraRed (IR) Object Sensor ..................................... 21

Symbol Orientation ............................................ 22

Active Scan Region for the MS700iand MS715iScanner ............. 23

Horizontal Scan Width vs. Distance for the MS700iand MS715iScanner .24

Active Scan Region for the MS720iScanner ........................ 25

Horizontal Scan Width vs. Distance for the MS720iScanner ........... 26

Depth of Field for the MS700iand MS715iScanner .................. 27

Depth of Field and Symbol Specification for the MS700iand MS715i.28, 29

Depth of Field for the MS720iScanner ............................ 30

Depth of Field and Symbol Specification for the MS720i........... 31, 32

Maintenance .................................................. 33

Applications and Protocols ...................................... 33

Appendix A

Specifications ...................................... 34, 35

Appendix B

Default Settings ..................................... 36-41

Appendix C

Pin Assignments .................................... 42-46

Appendix D

Warranty and Disclaimer ............................. 47, 48

Appendix E

Notices ........................................... 49, 50

Appendix F

Patents ............................................... 51

Volume Control Card ....................................... 52, 53

Index .................................................... 53, 54

Introduction

The MS700iSeries Scanners are high throughput projection scanners that

incorporate the latest in VLD (Visible Laser Diode) ASIC/VLSI and surface

mount technologies. Each scanner consumes only 8 watts of power and can

directly connect to many host systems that can support a scanning device. One

thoughtful feature is a “sleep mode” that turns the laser and motor off when not

in use. Other features include easy-to-see LED indicators that can be viewed

from the top or front and a volume control card that can be scanned to control

volume levels. There are two programming methods: through the

ScanSelect™ programming guide or through ScanSet™ (an IBM PC

compatible software program.)

With a scan speed of 2,000 lines per second, these scanners aggressively scan

poorly printed bar codes and read torn and bent UPC, EAN and JAN bar

codes immediately on the first pass at any roll angle. For close scanning, the

MS700iand MS715i’s depth of field of 0.0mm - 178mm (0" - 7") is ideal. To

accommodate applications where scanning items farther away from the scan

window is preferred, the MS720i’s depth of field of 178mm - 381mm (7" -

15") is ideal.

Unpacking List

The shipping carton should contain the following:

!Installation and User’s Guide (MLPN: 2178)

!ScanSelect™ Scanner Programming Guide (MLPN: 2186)

!Volume Control Card (MLPN: 2346)

!MS700i/MS715i or MS720iLaser Bar Code Projection Scanner

!Power Supply (optional)

!Communication cable with connection for power supply (optional) or

Communication Cable (optional)

!Stand #45483 (optional)

Scanner Connections to the Host

To maintain compliance with applicable standards, all circuits connected to the

scanner must meet the requirements for SELV (Safety Extra Low Voltage)

according to EN 60950. To avoid potential problems, do not power up the

scanner until the communication cable is secured to the host.

1. Turn off the host system.

2. Connect the 25-pin D-type connector on the scanner’s head cable to the

communication cable. Connect the other end of the communication

cable to the host device. (If the scanner will not receive power from a

transformer, skip to Step 5.)

3. If the scanner will receive power from an external power source, check

the AC input requirements of the transformer to make sure the voltage

matches the AC outlet. (A socket-outlet can be installed near the

equipment so it will be easily accessible.)

4. Plug the transformer into the side of the female D-type connector

located on the communication cable. Plug the transformer into the AC

outlet to supply power to the scanner.

5. Power up the host system.

Note: When the scanner first receives power, the LEDs will flash and

then the scanner will beep once. After the scanner performs this

startup sequence, the green LED will remain on for a specified

time indicating that the laser is on.

Configuration of the Scanner to the Host System

The scanner is shipped from the factory programmed to a set of default

conditions. These default conditions are in the Default Settings section of this

guide pages 36-41 and in the ScanSelect™ Scanner Programming Guide. The

default settings in the ScanSelect guide have an asterisk that appears before

the brief definition next to the bar code.

For the scanner to properly communicate with the host system, it needs to be

programmed to meet the specific scanning needs. Since each host system is

unique, configure the scanner to match the host system requirements.

Configure the scanner by entering program mode and scanning the appropriate

bar codes that appear in the ScanSelect Scanner Programming Guide. (When

using ScanSet™, refer to the ScanSet documentation for information on how

to configure the scanner.)

1. Connect the scanner to the host system (Refer to the Scanner

Connections to the Host section in this guide).

2. Enter program mode by scanning the ENTER/EXIT program mode bar

code as the first bar code after a power up cycle. (The unit will beep

three times)

3. Scan the appropriate bar code(s) that appear in the ScanSelect Scanner

Programming Guide. (Reveal only one bar code to the scanner each

time. With your hand, cover the bar code that is not to be scanned.)

4. Exit program mode by scanning the ENTER/EXIT program mode bar

code again. (The new options will be saved and the scanner is ready for

normal operation.)

Note: Non-RS-232 interfaces chosen in Section B of the ScanSelect

Programming Guide do not match the default settings loaded when

the same interface is selected with ScanSet.

CLONING

Cloning Feature

To program several scanners with the same settings, use the Cloning feature.

This is done by connecting the cloning cable (MLPN: #51544) between two

scanners.

1. Turn off both scanners.

2. Connect the cloning cable between the two scanners.

3. Turn both scanners on by plugging in the transformers.

4. Once each scanner is ready, scan the cloning bar code with the scanner

that has the settings that need to be transferred to the other scanner.

Version 11 IBM 46XX Scanner

Output Format: IBM RS-485 serial input/output for the 4680 and 4690

(46XX) point-of-sale terminals

The Version 11 46XX interface can be used in several different ways. Both the

46XX terminal and the scanner must be configured to match each other.

Warning:Power to the scanner and 46XX terminal should be turned off

before making physical connection.

The 4680 and 4690 series terminals have different types of physical ports for

connecting bar code scanners. Scanner ports include Port 5B, Port 17, and

Port 9? (? = A, B, C, or E). A Port 9 type connector is present on all versions

of the 46XX families of terminals. That is one reason it is the normal point of

connection for Metrologic scanners. Another reason is that there is enough 12

volt power available to operate many Metrologic scanners. If the terminal

configuration requires use of a different physical port for connecting bar code

scanners, contact Metrologic to get particular adaptor cable information.

No matter what port is in use for the physical connection, all devices use a

common communications bus inside the 46XX terminal. Each device uses a

different address when it must communicate. The terminal must be configured

to look for a device at a logical address.

The IBM 1520 mode/address was selected as a default because it was the first

IBM 46XX family scanner to support UPC/EAN, Code 39 and Interleaved 2

of 5. The Version 11 scanner formats Codabar, Code 128, and Code 93 using

the Code 39 function code designation supported by the IBM device driver for

this scanner type. Other emulation modes currently available are the IBM

3687-2 Port 17 fixed scanner and the Port 9B IBM 4500 CCD hand-held bar

code reader. One of these other emulation modes may be needed depending on

which operating system (4680.OS, 4690.OS, POS/DOS or DOS/RIPPS) is in

use at the site.

Note: The IBM 4683 and IBM 4684 terminals have a good proven track

record of supplying power to Metrologic scanners. The IBM 4693

and IBM 4694 terminals may be restricted from supplying power to

certain scanner models. Specifically, Metrologic currently

recommends using an external power supply for the scanner when

connecting to an IBM 4694. Metrologic has no recommendations at

this time for IBM 4693 terminals.

Configuring the Scanner

Located in the Version 11 scanner are two computer boards. One board is for

decoding and the other for 46XX IO processing. The decode board is

configured using ScanSet™ or ScanSelect™ while the IO board is configured

with an internal DIP Switch bank.

For UPC/EAN scanning, the decode board should be set as follows:

Enable IBM 4680 Communication

Enable UPC/EAN

Beep after Transmit

Enable Communication Timeouts

Transmit UPC-A Check Digit

Transmit UPC-E Check Digit

These settings configure the decode board to beep after transmitting the data to

the terminal device driver. If the data does not clear the communications buffer

within two seconds, it is discarded without giving the operator a good scan

indication. This accommodates newer versions of the IBM device drivers that

enable/disable scanning in many different situations.

The default setting of the interface board is to emulate the IBM 1520 hand

scanner that supports UPC/EAN and alphanumeric code types. The following

is a list of switch settings for the internal interface board that handles the

46XX SIOC communications.

There are eight DIP switches on the board that are both software and hardware

switches.

Switch 1 Switch 2 Emulation Mode

OFF OFF Port 5B, IBM 1520 Model 2 Laser Scanner

(default setting)

OFF ON Port 9B, CCD (IBM 4500/Opticon)

ON OFF Port 17, IBM 4014 Adaptor for 3687-2 to 468X

ON ON Reserved

Switch 3 Reserved (Should be OFF)

Switches 4, 5, 6, and 7 Must be ON

Switch 8 Should be OFF (Reserved)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lector de código de barras de Metrologic

Metrologic

Metrologic MS6200 Pulsar Series Manual de usuario

Metrologic

Metrologic Stratos MS2xxx Series Instrucciones de instalación y funcionamiento

Metrologic

Metrologic MK3780-31A62 Manual de usuario

Metrologic

Metrologic Genesis MS7580 Manual de usuario

Metrologic

Metrologic MS6200 Pulsar Series Manual de usuario

Metrologic

Metrologic MS 1690 Focus Series Manual de usuario

Metrologic

Metrologic MS9590 VOYAGERGS series Manual de usuario

Metrologic

Metrologic IS4225 ScanGlove Manual de usuario

Metrologic

Metrologic Genesis MS7580 Manual del propietario

Metrologic

Metrologic MS1633 FocusBT Manual de usuario

Metrologic

Metrologic TwinScan IS220 Manual de usuario

Metrologic

Metrologic IS1000 Series Manual de usuario

Metrologic

Metrologic MS7120 Orbit Manual de usuario

Metrologic

Metrologic S4800 microQuest Series Manual de usuario

Metrologic

Metrologic IS4910 Series Manual de operación y mantenimiento

Metrologic

Metrologic Stratos MS2x20 Series Instrucciones de instalación y funcionamiento

Metrologic

Metrologic MS860i Mini-Slot Manual de usuario

Metrologic

Metrologic ScanQuest IS4110 Manual de usuario

Metrologic

Metrologic MS6720 Manual de usuario

Metrologic

Metrologic MS2020 Stratos Manual de usuario

Metrologic

Metrologic Stratos MS2420 Manual de usuario

Metrologic

Metrologic MS6130 MX003 Manual de usuario

Metrologic

Metrologic StratosS MS2222 Manual de usuario

Metrologic

Metrologic StratosE MS2122 Manual de usuario

Manuales populares de Lector de código de barras de otras marcas

POSMicro

POSMicro Datalogic PowerScan D7100 Manual de usuario

Marson

Marson MT780 Guía de configuración rápida

NCR

NCR RealPOS Manual de usuario

Motorola

Motorola SE3300 Guía de configuración rápida

Element

Element P130BT Manual de usuario

Motorola

Motorola Symbol LS3008 Manual de instalación y operación

Meec tools

Meec tools OBD-II / VAG Manual de usuario

SICK

SICK CLP 100 Manual de usuario

Royal Tag SA

Royal Tag SA I-Read Manual de usuario

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manual de usuario

Meteor

Meteor 8310 Manual de usuario

Denso

Denso BHT-500B Manual de usuario

Datalogic

Datalogic Heron HD3130 Manual de usuario

Motorola

Motorola MP6000 Instrucciones de montaje

Newland

Newland NLS-HR15-BT Manual de usuario

ARTDEV

ARTDEV AS-1310 Manual de usuario

Aopos

Aopos AS290 Manual de usuario

ENS

ENS 367-5455 Manual de usuario
