Metra Electronics 95-3527 Manual de usuario

INSTALLATION INSTRUCTIONS FOR PART 95-3527

95-3527

KIT FEATURES

•Double DIN Radio Provision

•Stacked ISO Units Provision

•A) Radio Housing • B) Double DIN Brackets • C) Double DIN Trim Plate

KIT COMPONENTS

Phillips Screwdriver • Panel Removal Tool

•Socket Set

1-800-221-0932

www.metraonline.com

TOOLS REQUIRED:

APPLICATIONS

Pontiac Grand Prix

2004-2007

B C

Dash Disassembly

-PontiacGrandPrix2004-07 .......................................1

Kit Assembly

-DoubleDINRadioProvision.......................................2

-StackedISOUnitsProvision.......................................3

Final Assembly ..........................................4

TABLE OF CONTENTS

95-3527

*Note:

Refer also to the instructions included with the aftermarket radio.

95-3527 DASH DISASSEMBLY

PONTIAC GRAND PRIX 2004-07

Disconnect the negative battery ter-

minal to prevent an accidental short

circuit.

Remove trim ring around key cylinder.

(Figure A)

Unclip and remove entire panel sur-

rounding radio including message

center and vents.

(Figure B)

To remove radio start at bottom of

stackand remove (8) 9/32” screws

from pocket, climate control, and

radio (4) on each side).

(Figure C)

Continue to kit assembly.

95-3527 KIT ASSEMBLY

DOUBLE DIN RADIO PROVISION

Slide the Double DIN radio into the

Double DIN bracket/radio housing

assembly and secure the unit to the

kit using the screws supplied with

the radio.

(Figure B)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

Snap the Double DIN brackets to the

inside edge of the radio housing.

(Figure A)

Snap the Double DIN trim-plate onto

the front of the housing/radio assem-

bly.

(Figure B)

95-3527 KIT ASSEMBLY

STACKED ISO UNITS PROVISION

Slide the stacked ISO units into the

Double DIN bracket/radio housing

assembly and securethe units to the

kit using the screws supplied with the

units.

(Figure B)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

Snap the Double DIN brackets to the

inside edge of the radio housing.

(Figure A)

Snap the Double DIN trim-plate onto

the front of the housing/radio assem-

bly.

(Figure B)

95-3527 FINAL ASSEMBLY

FINAL ASSEMBLY

(A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Locate the factory wiring harness in the dash. Metra recommends using the

proper mating adapter and making connections as shown. (Isolate and individ-

ually tape off the ends of any unused wires to prevent electrical short circuit.)

Re-connect the negative batteryterminal and test the unit for proper operation.

Reassemble radio and dash assemblies in reverse order of disassembly.

FINAL WIRING CONNECTIONS

Make wiring connections using the EIA color code chart shown belowand the instructions included with the

head unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and

individually tape off ends of anyunused wires to prevent electrical short circuit.

METRA / EIA WIRING CODE

12V Ignition / Acc. . . . . . . . . . Red

12V Batt / Memory. . . . . . . . . Yellow

Ground. . . . . . . . . . . . . . . . . . Black*

Power Antenna. . . . . . . . . . . . Blue

Amp Turn-On . . . . . . . . . . . . . Blue / White

Amp Ground. . . . . . . . . . . . . . Black / White

Illumination . . . . . . . . . . . . . . Orange

Dimmer .................Orange / White

Right Front (+) . . . . . . . . . . . . Gray

Right Front (-). . . . . . . . . . . . . Gray/ Black

Left Front (+) . . . . . . . . . . . . . White

Left Front (-). . . . . . . . . . . . . . White / Black

Right Rear (+) . . . . . . . . . . . . Violet

Right Rear (-) . . . . . . . . . . . . . Violet / Black

Left Rear (+) . . . . . . . . . . . . . Green

Left Rear (-) ..............Green / Black

*NOTE: When a Black wire is not present, ground radio to vehicle chassis.

All colors may not be present on all leads due to manufacturer’s specifications.

95-3527

NOTES

95-3527 INSTRUCTIONS

1-800-221-0932

www.metraonline.com
