Marantz PM7005 Manual de usuario

Integrated Amplier

PM7005

English

Français

EsPaÑOl

Quick Start Guide

Guide de démarrage rapide

Guía de inicio rápido

Thank you for choosing a Marantz ampliﬁer. This guide

provides step-by-step instructions for setting up your

ampliﬁer.

Please do not return this unit to the store – call for

assistance.

If you need help… :

If you need additional help in solving problems, contact

Marantz customer service in your area.

1-855-ONE-Marantz

1-855-663-6272

Call for Assistance:

Monday – Friday 10:00AM to 10:00PM E.S.T,

Saturday 12:00PM to 8:00PM E.S.T

For frequently asked questions please visit

http://marantz.custhelp.com/app/answers/list

For US and Canada only

Welcome Before You Begin

Required for Basic connections

CD player

Speaker systems

Speaker cables

Required for PC or Mac Audio

connections

Computer USB cable

These drawings are for illustrative purposes only and may not represent the

actual product(s).

What’s In the Box

Quick Start Guide Integrated

Ampliﬁer

Owner’s Manual Power cord

Safety Instructions Remote control

unit

Warranty

(for USA /

for CANADA)

R03/AAA batteries

1Install batteries in the

remote control unit

R03/AAA batteries

There are seven steps to the setup

process.

1Install batteries in the remote control unit

2Connect the speakers to the ampliﬁer

3Connect the CD player to the ampliﬁer

4Plug the power cord into a power outlet

5Turn the ampliﬁer’s power on

6Begin playback

7Enjoying music using PC or Mac

Setup

2Connect the speakers to the ampliﬁer

(R)

(L)

Connecting the speaker cables

qPeel off about 3/8 inch (10 mm)

of sheathing from the tip of the

speaker cable, then either twist

the core wire tightly or apply

solder to it.

wTurn the speaker terminal

counterclockwise to loosen it.

eInsert the speaker cable’s core

wire to all the way into the

speaker terminal.

rTurn the speaker terminal

clockwise to tighten it.

3Connect the CD player to the ampliﬁer

AUDIO

OUT

R L

CD player

4Plug the power cord into a power outlet

Power cord (supplied)

Connect to household

power outlet

(AC 120 V, 60 Hz)

5Turn the ampliﬁer’s power on

Reduce the volume to the minimum level.

Press the power operation button.

6Begin playback

Press SPEAKERS on the unit.

SPEAKERS indicator lights.

Set the input source to “CD”.

Play the CD player.

Adjust the volume.

7Enjoying music using PC or Mac

Download the driver for this unit from

the Marantz web site and install it on

your PC.

•Drivers do not need to be installed for Mac OS.

•Download the driver software from the Marantz

website.

•Operation will not occur correctly if connected to

the computer before the dedicated driver has been

installed.

•For instructions on operation, refer to the owner’s

manual.

Connect to PC or Mac.

Computer installed

with a media

player

Plug that ﬁts the shape of the

connection device connector

Type B

Type A

Power on.

7.1) Connect to PC or Mac
