Marantz PM5005 Manual de usuario
.
Integrated Amplifier
PM5005
Owner’s Manual
You can print more than one page of a PDF onto a single sheet of paper.
Contents Connections Playback
Settings
Tips Appendix
1
Front panel Rear panel
Remote control
unit
Index
Accessories 4
Inserting the batteries 5
Operating range of the remote control unit 5
Features 6
High quality sound 6
High performance 6
Easy operation 7
Part names and functions 8
Front panel 8
Rear panel 10
Remote control unit 11
Connections
Connecting speakers 17
Speaker A/B connection 18
Bi-wiring connection 19
Connecting a playback device 20
Connecting a recording device 21
Connecting devices with remote control connectors 22
Performing operations by RC on this unit without visual contact 22
Remotely connecting Marantz audio devices 22
Connecting the power cord 23
Playback
Turning the power on 25
Selecting the speakers for audio output 26
Selecting the input source 26
Adjusting the volume 26
Turning off the sound temporarily (Muting) 26
Adjusting the tone 26
Playing CDs 27
Recording 28
Contents Connections Playback
Settings
Tips Appendix
Contents
2
Front panel Rear panel
Remote control
unit
Index
Settings
Setting the Auto Standby mode 30
Turning Auto Standby mode off 30
Turning Auto Standby mode on 30
Setting the remote signal receiving function 31
Disabling the remote signal receiving function of the remote
control unit 31
Enabling the remote signal receiving function of the remote
control unit 31
Setting remote control codes 32
Setting remote control codes for the remote control 33
Setting remote control codes for this unit 33
Tips
Tips 35
Troubleshooting 36
Appendix
Explanation of terms 40
Specifications 41
Index 43
Contents Connections Playback
Settings
Tips Appendix
3
Front panel Rear panel
Remote control
unit
Index
Thank you for purchasing this Marantz product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
.
.
Quick Start Guide CD-ROM (Owner’s Manual) Safety Instructions
.
.
.
Power cord Remote control unit (RC002PMCD) R03/AAA batteries
Contents Connections Playback
Settings
Tips Appendix
4
Front panel Rear panel
Remote control
unit
Index
Inserting the batteries
1Remove the rear lid in the direction of the arrow and
remove it.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
R03/AAA batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
Approx. 7 m
30°
Contents Connections Playback
Settings
Tips Appendix
5
Front panel Rear panel
Remote control
unit
Index
Features
High quality sound
0All-discrete current feedback amplifier
This unit uses a high-speed current feedback amplifier circuit for its
preamplifier and power amplifier so that signals from the Super Audio
CD player can be amplified with high fidelity. The high-speed current
feedback amplifier reproduces a natural sound space.
0High-power output
This unit features a slimline body, but comes with a large power supply
unit for dynamic music reproduction with high power.
0High quality audio design
This unit has a high quality audio design such as minimized signal path,
use of high sound quality parts, and large power circuit, which is
possible only in discrete audio components.
0Phono input connectors for connecting turntables
This unit is provided with a phono amplifier so that you can directly
connect a turntable and play records (Only the MM cartridge can be
used). (v p. 20)
0Two-sets of speaker output terminals
In addition to using two sets of speakers (Speakers A and Speakers B),
you can connect to bi-wiring speakers with separate input terminals for
high range and low range. (v p. 19)
The unit adopts screw terminals that can connect thick audio cables.
High performance
0Tone control function
This unit has a tone control function for adjustment of bass (low
frequency) and treble (high frequency) sound to produce your preferred
tone. (v p. 27)
0LOUDNESS function
This unit is provided with a LOUDNESS function that makes it easier to
hear music played back at a low volume level. (v p. 27)
Contents Connections Playback
Settings
Tips Appendix
6
Front panel Rear panel
Remote control
unit
Index
Easy operation
0Remote control compatible with CD players and network audio
players
The remote control provided with this unit can control Marantz CD
players and network audio players in addition to this unit. (v p. 12)
This unit can also switch between three remote control codes. When
using three units in the same area, you can set a different remote
control code for each unit to control them independently. (v p. 33)
Contents Connections Playback
Settings
Tips Appendix
7
Front panel Rear panel
Remote control
unit
Index
Part names and functions
Front panel
.
iQ
3
Q
4
Q
0
Q
1
Q
2
ou
rteqw y
APower operation button (X)
This turns the power on/off. (v p. 25)
BPower indicator
This is lit as follows according to the power status:
0Power on : Off
0Standby : Red
0Power off : Off
0When the protection circuit is activated : Red (blinking)
Contents Connections Playback
Settings
Tips Appendix
8
Front panel Rear panel
Remote control
unit
Index
.
r t ye
iuQ
3
Q
4
Q
0
Q
1
Q
2
o
CInput source select knob (INPUT SELECTOR)
This selects the input source. (v p. 26)
DInput indicators (v p. 26)
EMUTE indicator
This lights while the sound is muted. (v p. 26)
FVOLUME knob
These adjust the volume level. (v p. 26)
GHeadphones jack (PHONES)
Used to connect headphones.
Turn off speaker output when using headphones. (v p. 26)
NOTE
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
HBASS control knob
This setting adjusts the volume level for the bass. (v p. 26)
ISOURCE DIRECT button/indicator
This turns SOURCE DIRECT mode on/off.
(v p. 27)
JTREBLE control knob
This setting adjusts the volume level for the treble. (v p. 26)
KSpeaker switching buttons/indicators (SPEAKERS A/B)
These select the speaker for audio output. (v p. 26)
LLOUDNESS button/indicator
This turns the LOUDNESS mode on/off.
(v p. 27)
MBALANCE control knob
This adjusts the balance of the volume output from the left and right
speakers. (v p. 26)
NRemote control sensor
This receives signals from the remote control unit. (v p. 5)
8, 0, b and c can be adjusted when 9 is off (SOURCE DIRECT mode is off).
Contents Connections Playback
Settings
Tips Appendix
9
Front panel Rear panel
Remote control
unit
Index
Rear panel
.
oitre Q
0
q w
y u
ASIGNAL GND jacks
Used to connect a turntable. (v p. 20)
BAC inlet (AC IN)
Used to connect the power cord. (v p. 23)
CTurntable input connectors (PHONO)
Used to connect a turntable. (v p. 20)
DTuner input connectors (TUNER)
Used to connect a tuner. (v p. 20)
ECD input connectors
Used to connect a CD player. (v p. 20)
FNetwork audio player input connectors (NETWORK)
Used to connect a network audio player.
(v p. 20)
GRecorder input/output connectors (RECORDER 1)
Used to connect the input/output connector of a recorder. (v p. 21)
HRecorder input/output connectors (RECORDER 2)
Used to connect the input/output connector of a recorder. (v p. 21)
ISpeaker terminals (SPEAKERS)
Used to connect speakers. (v p. 17)
JRemote control input/output connectors (REMOTE CONTROL)
Used to connect to a Marantz audio device that is compatible with the
remote control function. (v p. 22)
Contents Connections Playback
Settings
Tips Appendix
10
Front panel Rear panel
Remote control
unit
Index
