M2 Antenna Systems 6M5XHP Manual de usuario

M2 Antenna Systems, Inc. 4402 N. Selland Ave. Fresno, CA 93722

Tel: (559) 432-8873 Fax: (559) 432-3059 Web: www.m2inc.com

REV A

Model .........................................6M5XHP

Frequency Range.......................50.0 To 50.5 MHz

*Gain, (FS)f ................................11.54 dBi

Front to back ..............................21 dB Typical

Beamwidth ...............................E=42° H=52°

Feed type ...................................Direct feed

Feed Impedance........................50 Ohms Unbalanced

Maximum VSWR........................1.1 @ 50.175

Input Connector..........................SO-239

Power Handling..........................1.5 kW, Higher avl.

Boom Length / Dia......................216” / 1-1/2”

Maximum Element Length..........113”

Turning Radius:..........................134”

**Stacking Distance....................15’-21’H & 19’-23’ W

Mast Size....................................1-1/2” to 2” Nom.

Wind area / Survival...................2.2 Sq. Ft. / 100 MPH

Weight / Ship Wt.........................13 Lbs. / 16 Lbs.

M2 Antenna Systems, Inc.

Model No: 6M5XHP

FEATURES:

The 6M5XHP is the latest computer optimized version of our popular 6M5X. The 6M5XHP has been re-designed

to use a hairpin type direct feed. We just made a good thing better, maintaining a low wind load and great performance

for its size. The 6M5XHP will compliment the rest of your antenna system and not overload your tower. The 6M5XHP is

perfect for the Ham trying 6 meters for the first time or the seasoned vet who may stack them for lower angle of radiation

or even some EME use.

SPECIFICATIONS:

*Subtract 2.14 from dBi for dBd / FS = Free Space / ** H = High / W = Wide

6M5XHP DIMENSION SHEET

TOOLS REQUIRED: Screwdriver, 11/32 wrench, socket or spintite, a 7/16" and 1/2" wrench or socket, tape measure.

**Please be sure to slip Driven Element Clamp Block

on to the boom before adding the next boom section**

6M5XHP BALUN DETAIL

GENERIC COMPRESSION CLAMP DETAIL

6M5XHP PARTS & HARDWARE

DESCRIPTION......................................................................................... QTY

BOOM SECTION #1: 1.5” X .065 X 60” SOE........................................... 1

BOOM SECTION #2: 1.5” X .065 X 60” SOE........................................... 1

BOOM SECTION #3: 1.5” X .065 X 60” SOE........................................... 1

BOOM SECTION #4: 1.5” X .065 X 45” ...................................................1

DE ELEMENT CENTER, .50” X .049 X 19”.............................................. 2

ELEMENT HALF TUBES, .375” X .049 X SEE CHART...........................8

DRIVEN ELEMENT TIP, .375” X .049 X 39.188” ..................................... 2

ELEMENT SUPPORT ROD, 1/4” X 10” ...................................................8

HARIPIN ROD, .188” X 16.5”...................................................................1

FIBERGLASS DE CENTER, .375” X 10” (M2AFG0017).......................... 1

DE HAIRPIN BLOCK, .50” X .250 X .625”................................................2

ELEMENT MOUNT BLOCK, .500” X .500 X 3”........................................ 4

DE CLAMP BLOCK 1.50” X .500 X 2.626” (M2ADE0094)....................... 1

BALUN PLATE, .125” X 1.5” X 3”.............................................................1

BOOM TO MAST PLATE, 4” X .1875 X 6” (M2APT0022)........................ 1

(3) FAIRITE 1:1 VHF BALUN ASSEMBLY (SO-239) (FGBL0700).........1

PENETROX / ZINC PASTE CUP.............................................................1

ASSEMBLY MANUAL..............................................................................1

HARDWARE:

COMPRESSION CLAMP, 1/2”................................................................. 2

U-BOLT AND CRADLE, 2".......................................................................2

U-BOLT AND CRADLE, 1-1/2”.................................................................4

LOCKWASHER, 5/16, SS........................................................................16

NUT, 5/16-18, SS.....................................................................................16

BOLT, 1/4-20 X 1/2”, SS .......................................................................... 1

SCREW, 8-32 X 2”, SS ............................................................................5

SCREW, 8-32 X 1-3/4”, SS ......................................................................6

SCREW, 8-32 X 1”, SS ............................................................................10

SCREW, 8-32 X 1/2”, SS .........................................................................2

SET SCREW, 8-32 X 1/4”, SS ................................................................. 2

NUT, 8-32, SS.......................................................................................... 2

LOCKNUT, 8-32, SS................................................................................21

ALLEN HEAD WRENCH, 5/64”................................................................ 1

M2ANTENNA SYSTEMS, INC.

4402 N. SELLAND AVE.

FRESNO, CA 93722

(559) 432-8873 FAX: 432-3059

www.m2inc.com Email: [email protected]
