M-system R3-PA4B Manual de usuario

R3-PA4B

P. 1 / 3 EM-8383 Rev.2

BEFORE USE ....

Thank you for choosing M-System. Before use, please check

the contents of the package you received as outlined below.

If you have any problems or questions with the product,

please contact M-System’s Sales Office or representatives.

■ PACKAGE INCLUDES:

Totalized pulse input module ..................................... (1)

■ MODEL NO.

Check that model No. described on the specification label is

exactly what you ordered.

■ INSTRUCTION MANUAL

This manual describes necessary points of caution when you

use this product, including installation, connection and basic

maintenance procedures.

INSTRUCTION MANUAL

MODEL R3-PA4B

LOW SPEED TOTALIZED PULSE INPUT MODULE

(4 points, isolated)

POINTS OF CAUTION

■ HOT INSERTION/REMOVAL OF MODULES

Removing or replacing modules does not affect other modules

on the same backplane. It is possible to replace them without

removing the power supply. However, replacing multiple

modules at once may greatly change line voltage levels. We

recommend that you replace them one by one.

■ ENVIRONMENT

• Indoor use

• When heavy dust or metal particles are present in the air,

install the unit inside proper housing with sufficient ventila-

tion.

• Do not install the unit where it is subjected to continuous

vibration. Do not subject the unit to physical impact.

• Environmental temperature must be within -10 to +55°C

(14 to 131°F) with relative humidity within 30 to 90% RH in

order to ensure adequate life span and operation.

■ WIRING

• Do not install cables (power supply, input and output) close

to noise sources (relay drive cable, high frequency line, etc.).

• Do not bind these cables together with those in which noises

are present. Do not install them in the same duct.

■ AND ....

• The unit is designed to function as soon as power is

supplied, however, a warm up for 10 minutes is required for

satisfying complete performance described in the data sheet.

INSTALLATION

Use the Installation Base (model: R3-BSx).

R3-PA4B

P. 2 / 3 EM-8383 Rev.2

COMPONENT IDENTIFICATION

■ DIMENSIONS mm (inch)

TERMINAL CONNECTIONS

Connect the unit as in the diagram below.

130 (5.12)

27.5 (1.08) 109 (4.29) POSITIONING

GUIDE

TERMINAL

COVER

20–M3

SCREW

6.2

(.24)

SW1SW2

SW3

■FRONT VIEW ■SIDE VIEW

ERR LED

RUN LED

Gain

Count Reset

Set the Count Reset SW to OFF to start counting.

■SIDE DIP SW

•Gain: SW3

SW GAIN INPUT

1 (*)2

SW3-1 OFF ON Input 1

SW3-2 OFF ON Input 2

SW3-3 OFF ON Input 3

SW3-4 OFF ON Input 4

(*) Factory setting

■STATUS INDICATOR LED

RUN indicator: Bi-color (red/green) LED;

Red when the bus A operates normally;

Green when the bus B operates normally;

Amber when both buses operate normally.

ERR indicator: Bi-color (red/green) LED;

Red with the excitation abnormality;

Green in normal operating conditions.

R3-PA4B

P. 3 / 3 EM-8383 Rev.2

■ CONNECTION DIAGRAM

M-SYSTEM WARRANTY

M-System warrants such new M-System product which it manufactures to be free from defects in materials and workmanship during the 36-month period following the date that such

productwasoriginallypurchasedifsuchproducthasbeenusedundernormaloperatingconditionsandproperlymaintained,M-System'ssoleliability,andpurchaser'sexclusiveremedies,

under this warranty are, at M-System's option, the repair, replacement or refund of the purchase price of any M-System product which is defective under the terms of this warranty. To

submit a claim under this warranty, the purchaser must return, at its expense, the defective M-System product to the below address together with a copy of its original sales invoice.

THIS IS THE ONLY WARRANTY APPLICABLE TO M-SYSTEM PRODUCT AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. M-SYSTEM SHALL HAVE NO LIABILITY FOR CONSEQUENTIAL, INCIDENTAL OR

SPECIAL DAMAGES OF ANY KIND WHATSOEVER.

M-System Co., Ltd., 5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN, Phone: (06) 6659-8201, Fax: (06) 6659-8510, E-mail: [email protected]

WIRING INSTRUCTIONS

■SOLDERLESS TERMINAL mm (inch)

Refer to the drawing below for recommended ring tongue

terminal size. Spade tongue type is also applicable. Solderless

terminals with insulation sleeve do not fit. Applicable wire

size: 0.3 – 0.75 mm2

3.2 (.13) dia.

4 min.

(.16)

12 (.47) max.

6 max.

(.24)

3 (.12) max.

EXC +

INP TERM. 1

INP TERM. 2

INP TERM. 3

COM

INTERNAL POWER

BUS A

BUS B*

*For dual redundant communication.

BUS CONNECTOR

Input 1

EXC +

INP TERM. 1

INP TERM. 2

INP TERM. 3

COM

Input 2

EXC +

INP TERM. 1

INP TERM. 2

INP TERM. 3

COM

Input 3

EXC +

INP TERM. 1

INP TERM. 2

INP TERM. 3

COM

Input 4

■Input Connection Example (Input 1)

• Open Collector

12VDC

20kΩ

1kΩ7.5kΩ
