Lucent Technologies DSL Element Management System NavisAccess Manual de usuario

NavisAccess™ DSL

Element Management System

Features

Integrated and automated network start-up – Includes

auto-discovery of network devices, flexible network

views and subscriber provisioning

Advanced real-time performance and fault monitoring –

Centralizes remote management of devices, services

and device/service groups, including chassis, software

and configuration file change control

Comprehensive visualization tools

– Enhances secure access to NavisAccess™ DSL EMS 

 features, functions and data through user groups 

 you specify

– Helps you better manage your network via reports

 based on historical usage performance trends and

 capacity needs

Scalability for network growth management

– Supports more than 500,000 ports on a single,

 logical system and scales to meet the needs of the

 largest access providers

– Ensures that your future network growth is

 accommodated by an existing flexible

 management system

•

Benefits

Speeds network start-up time – Deploys rapidly so you

can configure, provision and manage DSL devices and

services immediately

Reduces time to resolve network problems - Facilitates

quick identification and resolution of fault conditions

via advanced fault management capabilities

Enhances fault and device management – Provides

abilities to detect and recover lost traps while

maintaining connections to the monitored Stinger®

DSLAM

Increases end-user satisfaction

– Speeds and facilitates service provisioning process

 with a simple, easy to use GUI-based DSL port

 provisioning feature

– Enables you to store frequently used port

 configurations in templates for quick, accurate

 provisioning

•

The advanced NavisAccess™ DSL EMS

graphical user interface (GUI) provides

service level views of your Lucent Stinger®

DSLAMs, enabling you to centrally

monitor and manage the performance

of each DSL line in the network.

NavisAccess™ DSL Element Management System (EMS) software accelerates configuration and deployment for Digital Subscriber

Line (DSL) access and services supporting your Lucent Stinger®family of DSLAM products. NavisAccess™ DSL EMS software

simplifies day-to-day operations for DSL access services over Stinger®DSLAM products in your network and provides the

foundation for your Fault, Configuration, Accounting, Performance and Security (FCAPS) functionalities. Scalable to more than

500,000 Stinger®device ports, NavisAccess™ DSL EMS software enables you to monitor the performance of every DSL line in

your entire network.

NavisAccess™ DSL EMS is a key component of Lucent’s powerful Navis®iOperations EMS portfolio of products that simplify

deployment, configuration and management of Lucent network equipment. Navis®EMS solutions help you make the most of

your Lucent network investments, streamline daily operations and offer revenue-enhancing services.

Configuration Management

- Device configuration and software management –

 automates routine, error-prone tasks involved in configuring

 network devices and loading new versions of software across

 a large network

- Physical view of the Stinger®DSLAM allows:

• Discovery of trunk and Control Module (CM) sparing

  configuration

• Recognize Line Protection Module (LPM) LPM-R

  (redundancy supporting), LPM-RP (port level or enhanced

  redundancy supporting) IRM (Interface Redundancy

  Module) or CLT (Copper Line Test Module)

• Standby versus Active CM indication

• Trunk module switchover indication

• Line-under-test indication

• Redundant line switchover indication

• Associated event display filtered for device being viewed

• Initiate loop tests and view the results in minutes

Scalability

- Distributed system architecture allows for high scalability,

 supporting more than 500,000 DSL lines.

Service and Support

Backed by Lucent Worldwide Services for industry-leading

service and support

Hardware

NavisAccess™ DSL hardware specifications vary based on

number of DSLAMs to be managed, number of operators

logged into NavisAccess™ servers, availability of WAN

bandwidth, etc. These specifications are made available based

on your specific requirements.

Release 7.3 Specifications

- True Access®Operating System 9.4-185.2, 9.3-170.3

- 48port ADSL MRT 19”

- Support for Connection Admission Control (CAC) feature

- Support for Reliable Trap delivery - to Stinger®Access

 Concentrator and Navis®NFM

Supported Stinger®Products

- Stinger®FS DSL Access Concentrator

- Stinger®FS+ DSL Access Concentrator

- Stinger®LS DSL Access Concentrator

- Stinger®RT DSL Access Concentrator

- Stinger®MRT DSL Access Concentrator

NavisAccess™ DSL EMS Software Operations and Specifications

On-screen Displays

-Threshold monitoring – monitors individual lines for

 threshold crossing, including parameters affecting line quality

-Fault monitoring – provides screen-based view of every

 aspect of your Stinger®DSL network

-Inventory management and spares planning – easy-to-use

 screens and tools provide virtual views of each Stinger®

 DSLAM device on the network

Reporting

-Versatile reporting – customized reporting available to

 monitor device status, device chassis, DSL resources and events

-Multi-level security for network-wide control – ability to

 segregate security program based on network elements and

 create multiple level security controls to restrict access based

 on different feature combinations

Enhanced Device Management

-Monitors the state of network element (NE) connections

-In case of loss of management connection, notifies local

 operator and sends a trap to a higher order OSS

-After communication link is restored, recovers traps that

 were generated on the NE during the period of outage and

 forwards recovered traps to higher order OSS

Event and Fault Management

-SNMP Trap forwarding to higher order OSS

-Optional integration with Navis®Network Fault Management

 (NFM) software

-Hierarchical network map - Indication of highest severity

 alarms on network map

-User acknowledged/cleared alarms

-Auto-clearing of alarms based on user-specified notifications

-Audit trail of alarm processing

-Advanced GUI for high fault visibility

Advanced Thresholds

-Threshold monitoring parameters detect:

  • Loss of frame seconds

  • Loss of link seconds

  • Loss of power seconds

  • Loss of signal seconds

  • Errored seconds

Navis®iOperations Element

Management Software

Make the most of your Lucent network

investments

Navis®iOperations EMS solutions integrate seamlessly

with existing OSS systems to support automated

network provisioning, continuous synchronization of

network resources and consistently high QoS. They

feature a common, technology-independent framework

– which eases management with a consistent look and

feel across diverse domains and hardware systems.

Navis®iOperations is a comprehensive software

portfolio of multi-vendor, multi-technology Operations

Support Systems for wireline, wireless, optical, circuit

and data networks. Navis®iOperations systems are

developed on extensible, programmable platforms,

open APIs and advanced system architecture to

provide carrier class reliability and scalability, as well

as rapid and affordable integration into a Service

Provider’s preferred operations infrastructure.

Navis®iOperations are supported by Lucent

Worldwide Services (LWS), Systems Integrators, and

Service Provider partners who provide a

comprehensive suite of world-class planning,

deployment, operations and maintenance services.

To learn more, contact your Lucent Technologies sales

representative, authorized reseller or sales agent. You

can also visit our web site at

http://www.lucent.com/oss or call 1-888-426-2252.

External Interfaces

NavisAccess™ DSL EMS can be configured to forward SNMP

traps and events to upstream systems including network

management systems and operations support systems (OSS).

Demonstration Software Download

See how NavisAccess™ DSL EMS can help you save time and

money via a free 90-day demonstration software download is

available at:

http://www.lucent.com/products/applications/navis_demo.html

This document is provided for planning purposes only, and does

not create, modify or supplement any warranties which may be

made by Lucent Technologies relating to the products and/or

services described herein. The publication of information

contained in this document does not imply freedom from patent

or other protective rights of Lucent Technologies or third parties.

Navis and Stinger are registered trademarks and NavisAccess is

a trademark of Lucent Technologies Inc. All other trademarks

and registered trademarks are properties of their respective

holders.

Lucent Technologies Inc.
