Lorex D242B Series Manual de usuario

Digital Video Recorder (DVR)

Quick Setup Guide

D242B Series

lorex.com

Contents

Package contents and dimensions...........................................1

Using the mouse.............................................................................10

Back panel overview......................................................................2

Using the quick menu...................................................................11

Setup

Step 1: connect cameras................................................ 3

Step 4: connect monitor/TV............................................7

Step 2: connect router......................................................5

Step 5: connect power......................................................8

Step 3: connect mouse....................................................6

Step 6: Lorex Setup Wizard.............................................9

Motion and smart motion detection..........................................12

Using deterrence features............................................................13

Changing the recorder’s output resolution..............................17

Playback and search.....................................................................18

Backup..............................................................................................19

Remote viewing

Before you start.................................................................20

Connect to the app...........................................................21

Lorex Home app live view................................................22

Package contents and dimensions

• 1080p HD Security DVR

• Power adapter

• Ethernet cable

• USB mouse

• HDMI cable

12.7” / 324mm

9.8” / 249mm

2.1”

53mm

Back panel overview

1 2 3

6 9

754 8

1. Video Inputs: Connect cameras*

2. Audio In/Out: Connect microphone/speaker*

3. HDMI port: Connect monitor*

4. LAN Port: Connect router*

5. RS-485: Connect Pan-Tilt-Zoom cameras*

Note:

The 8 channel DVR recorder in this guide is for illustration only. Your recorder may appear

different, with all the same ports in different locations.

*Not included/sold separately.

6. VGA Port: Connect monitor*

7. USB Port: Connect mouse or USB stick*

8. Power Port: Connect power

9. Power Switch: Power on/off

BNC connector Video input

Power adapter

Setup step 1 — Connect cameras

To connect cameras directly to the DVR:

1. Connect the extension cable’s male power head and BNC connector to the camera.

2. Then connect the other end of the BNC connector to a video input on your DVR.

3. Connect the female power head to the included power adapter.

IMPORTANT: Test your cameras prior to selecting a permanent mounting location by

temporarily connecting the cameras and cables to your DVR.

Notes:

• The extension cable must be a single stretch of cable between the

recorder and camera. You cannot connect multiple extension cables to

each other.

• This guide covers connecting cameras to your security recorder only.

For full instructions on installing your cameras and mounting tips,

please refer to your camera’s documentation at lorex.com.

Setup step 2 — Connect router

Connect the recorder

to your router using the

included Ethernet cable.

Note: To receive automatic rmware

updates and access your system remotly

with mobile apps, a high speed Internet

connection is required. A minimum upload

speed of 3.5Mbps is required. All other

system features can be used without an

Internet connection.

Setup step 3 — Connect mouse

Connect the included USB

mouse to the USB port on

the recorder.

To copy your video recordings

and to perform a rmware

upgrade, connect a USB stick

or ash drive to the USB port on

the front panel of the recorder.

Setup step 4 — Connect monitor/TV

Connect the recorder to

a monitor/TV using the

included HDMI cable or a

VGA cable (not included).

Note: To optimize picture

quality, set the recorder’s

video output to match

the resolution of your

monitor. See ‘Changing

the recorder’s output

resolution’ page 17 for

details.
