Logitech PRO FOLIO SLIM Manual de usuario

SLIM FOLIO PRO

Complete Setup Guide

English 3

SLIM FOLIO PRO

For iPad Pro 11-inch and iPad Pro 12.9-inch (3rd generation)

KNOW YOUR PRODUCT

Holder for Apple Pencil

(2nd gen) and other

digital pencils

Magnetic latch

USB-C

charging port

Charging and pairing

indicator light

iPad holder

Magnetic dock

Shortcut keys

Keyboard

English 4

Sl im Fol io P ro

Bluetooth

______

31 2 #

______

XXXXXX

SETTING UP THE CASE

1. Lay keyboard case at and slide iPad into

thebottom part of the holder.

2. Snap the top corners in place to secure iPad.

TURNING ON THE KEYBOARD

This product has an automatic wake/sleep feature.

Anytime you dock the iPad in the upright typing

position, the keyboard will automatically turn on.

When lifted out of type mode, the keyboard will

automatically turn o to save battery.

PAIRING IPAD WITH KEYBOARD

1. Place iPad in the upright typing position.

Theindicator light will blink, which means

thekeyboard is ready to pair.

Light isn’t blinking?

Go to iPad Settings > Bluetooth > On. Then press

the Bluetooth button located in the top row of

your keyboard. Hold for 2 seconds until the status

light blinks. The keyboard is discoverable for 2

minutes.

2. Go to Settings > Bluetooth > Devices > Slim Folio Pro.

3. A 6-digit code will appear on your iPad screen.

Using the Slim Folio Pro keyboard, type in the

numbers.

4. Press the ENTER key. Now you’re ready to type!

Note: If you want to use another iPad with this

keyboard case, you will need to go through the

pairing process again.

English 5

THREE USE MODES

Type mode

Fold the latch back until it magnetizes to the front

of the case. Dock iPad in the upright position and

type away.

Sketch mode

Lift iPad from magnetic dock and collapse into

sketch mode. Since the keyboard is only on when

iPad is in type mode, there is no need to worry about

unintentional typing.

Read mode

Open the case and fold the keyboard back. The

magnetic latch will keep the two sides of the case

held together while you read. Since the keyboard is

only on when iPad is in type mode, there is no need

to worry about unintentional typing.

REMOVING YOUR IPAD

1. To detach your iPad from the case, lay it on

aatsurface.

2. Push back the top corners of the case, one at

a time, and then lift your iPad out of the cradle.

HOW TO STORE APPLE PENCIL (2ND GEN)

The sides of Slim Folio Pro are left open, so you can

magnetically attach Apple Pencil (2nd gen) to the

side of the iPad Pro while the case is on. There is also

a slit on the inside of the Slim Folio Pro magnetic

latch to keep Apple Pencil (2nd gen) secure in transit.

English 6

LED LIGHT INDICATORS

SHORTCUT KEYS

LED Behavior Status

Blinking green Battery is charging

Solid green Battery is fully charged (100%)

Red Battery level is low (less than 10%), recharge the battery

Blinking white Fast: Keyboard is in discovery mode, ready for pairing

Slow: Keyboard is trying to reconnect to iPad

Solid white Bluetooth™pairing or reconnection is successful

ctrl

shift

CHARGE THE BATTERY

To check battery life, press the battery check button.

If the status light is red, the keyboard needs to be

charged. Use a USB-C cable. This is the same cable

that is used to charge iPad Pro 11-inch and 12.9-inch

(3rd generation).

1. Plug one end of the USB-C cable into the iPad

charging port. Plug the other end into a USB-C

port on your computer or a wall power adaptor.

2. Charge the battery until the status light turns

solid green.

BATTERY INFORMATION

• A fully charged battery provides about 3 months

of use when the keyboard is used about two hours

a day.

• Charge the battery if the status light turns red

briey after the keyboard turns on.

• The keyboard enters sleep mode automatically

ifnot used for a while in the typing position.

Pressany key to wake it.

• Once iPad is disconnected from magnetic

dock,the keyboard will automatically shut o

tosave power.

Home

Switch

language

Search Virtual

keyboard

track

Play/

pause

track

Mute Volume

down

Volume

Lock

screen

Bluetooth Battery

check

Keyboard

brightness

down

Keyboard

brightness

English 7

BATTERY REMOVAL FOR RECYCLING

1. Pry o top cover of the keyboard with a screwdriver.

2. Detach battery from circuit board and remove battery.

3. Seperate your product and battery from household

waste for recycling, where possible, according to

locallaws.

4. For more information, contact your local authority or

place of purchase or visit www.logitech.com/recycling

Battery
