Vela Pop Up Roof System

Class B

OWNER'S MANUAL

Rev: 07.27.2021 Page 2 CCD-0003922

TABLE OF CONTENTS

Introduction 2

Safety 3

Preparation 4

Operation 4

Closing the Pop-up Roof System 8

Troubleshooting 10

Maintenance 11

Care and Maintenance 11

Cleaning External Pop-up Roof Surfaces 11

Cleaning Internal Pop-up Roof Surfaces 11

Introduction

The Vela Pop-up Roof is a manually operated, van roof-mounted sleeper. The Pop-up Roof has a solid roof

with a canvas body that includes:

• a double bed,

• screened windows,

• hot or cold air circulation,

• ceiling courtesy lights,

• special storage shelving molded into the thermoformed lower section,

• pre-installations for LED lights,

• two flexible lamps with USB ports,

• a power socket and/or USB module,

• and the capability to top-mount a porthole or solar panel.

Additional information about this product can be obtained from lci1.com/support or by downloading

the free myLCI app. The app is available on Apple App Store® for iPhone® and iPad® and also on Google

Play™ for

Android™ users.

Apple App Store®, iPhone®, and iPad® are registered trademarks of Apple Inc.

Google Play™ and Android™ are trademarks of Google Inc.

For information on the assembly or individual components of this product, please visit:

https://support.lci1.com/beds/.

Note: Images used in this document are for reference only when assembling, installing and/or operating

this product. Actual appearance of provided and/or purchased parts and assemblies may differ.

Rev: 07.27.2021 Page 3 CCD-0003922

The “WARNING” symbol above is a sign that a procedure has a safety risk involved and may cause

death or serious personal injury and/or severe product or property damage if not performed safely

and within the parameters set forth in this manual.

Always wear eye protection when performing service, maintenance or installation procedures.

Other safety equipment to consider would be hearing protection, gloves and possibly a full face

shield, depending on the nature of the task.

The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury

and/or product or property damage if not safely adhered to and within the parameters set forth

in this manual.

Make sure unit is fully supported and secured per manufacturer's recommendations before working

on or underneath the unit or death, serious personal injury and/or severe product and property

damage, including voiding of the component warranty, may occur.

Moving parts can pinch, crush or cut. Keep clear and use caution.

Safety

Read and understand all instructions before installing or operating this product. Adhere to all safety labels.

This manual provides general instructions. Many variables can change the circumstances of the instructions,

i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This

manual cannot begin to plot out instructions for every possibility, but provides the general instructions,

as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the

provided instructions may result in death, serious personal injury, severe product and/or property damage,

including voiding of the LCI limited warranty.

Do NOT exceed the product's maximum speed limit of 80 mph (130 km/h).

Do NOT drive with the pop-up roof system opened or product damage may occur.

Do NOT drive with people or pets inside the pop-up roof system's sleeping area or personal injury

may occur.

Do NOT open pop-up roof if wind speeds exceed 25mph. Opening the pop-up roof in wind speeds

greater than 25 MPH could result in damage to the pop-up roof system.

Rev: 07.27.2021 Page 4 CCD-0003922

Operation

Fig. 1

ABC

1. Open the Pop-up Roof as follows:

A. From inside the camper van, release the clips on the two safety belts (Fig. 1A) by pressing on both

sides of the clip (Fig. 1B). The upper portion of the pop-up will move freely (Fig. 1C).

Fig. 2

Ladder

Hooks

Fig. 3

B. Attach the ladder supplied to the specific hooks (Fig. 2).

I. Climb the ladder to reach the release button (Fig. 3A).

Preparation

1. Make sure camper van is level.

2. Make sure camper van is properly supported and secured.

A. Engage brakes.

B. Chock all tires.

C. Make sure wind speeds do not exceed 25mph, if so the pop-up MUST remain in the closed

position or damage could occur.

Do NOT open pop-up roof if wind speeds exceed 25mph. Opening the pop-up roof in wind speeds

greater than 25 MPH could result in damage to the pop-up roof system.

Rev: 07.27.2021 Page 5 CCD-0003922

Fig. 4

II. Grab the handle with one hand (Fig. 4A), then at the same time press the release button

(Fig.4B) and push the handle upwards.

C. After unlocking the roof, grab both handles (Fig. 4A) and push the roof upwards.

Fig. 5 Fig. 6

Fig. 7

2. Brightness inside the sleeping area can be adjusted by means of two flexible lamps (Fig. 5) located on

the lower part of the pop-up.

A. The flexible lamps are controlled by pressing an integrated on/off switch (Fig. 6A) providing two

intensity levels.

B. Each flexible lamp contains a 5V DC, 2A USB port (Fig. 7A).

Rev: 07.27.2021 Page 6 CCD-0003922

3. Located at the interior of the entrance frame, there is at least one module with two 5V DC USB

ports(Fig. 8).

Note: Various kinds of electronic devices can be recharged and used, if they meet the provided current

limits and voltages.

Fig. 8

4. Windows— with mosquito nets—positioned along the perimeter of the pop-up roof (Fig. 9) can be

opened to further ventilate the sleeping area.

Fig. 9

A. To open the windows of the pop-up roof for better ventilation, open the zipper (Fig. 10).

B. Roll down the window covering towards the base of the window (Fig. 9A).

C. Fasten the covering in-place with the straps located at the base (Fig. 11).

Fig. 10 Fig. 11

Rev: 07.27.2021 Page 7 CCD-0003922

D. Closing all pop-up widows protects against cold and rain (Fig. 12).

Fig. 13

Fig. 14

E. Opening all pop-up windows improves ventilation against heat build-up and helps to refresh the

sleeping area (Fig. 13).

Closed Window

Open

Window

5. The Vela Pop-up Roof System comes equipped with a 51" x 78" (1300 mm x 2000 mm) double

bed (Fig. 14).

Fig. 12

Rev: 07.27.2021 Page 8 CCD-0003922

A. To reach the bed, attach the supplied ladder to the two hooks (Fig. 15).

B. Climb the ladder to the bed, sit on the surface of the sleeping area, then rotate your torso.

Fig. 15

Ladder

Hooks

Closing the Pop-up Roof System

To close the pop-up, do as follows:

1. Attach the supplied ladder on the hooks (Fig. 15).

2. Climb the ladder to inspect the pop-up roof to make sure the windows are properly closed (Fig. 16). If

necessary, zip the windows closed (Fig. 17).

Closed

Window Zipper

Closed

Window

Fig. 16 Fig. 17

3. After making sure all windows are closed, grip both roof handles (Fig. 18) and pull down as evenly as

possible. Do NOT completely close the pop-up roof at this point.

4. Make sure that the canvas is folded correctly inside to prevent jamming of the built-in mechanism or

the locking latch.

5. Walk around the vehicle and visually inspect the pop-up roof for any canvas material sticking out of

the frame. If necessary, carefully tuck in any protruding material.

6. From inside the vehicle, continue to lower the roof until it is completely closed.

Note: A clicking sound should be heard, signifying the locking system has engaged.

Moving parts can pinch, crush or cut. Keep clear and use caution.

Rev: 07.27.2021 Page 9 CCD-0003922

7. To make sure the pop-up's locking system has been engaged, perform the following:

A. Grab the handles on the roof with both hands and push upwards.

B. If the upward pressure on the roof does not change its position significantly on both sides, then

the locking system is properly engaged.

C. If the roof changes position, the locking system is not properly engaged. Repeat steps 4-6, then

check the locking system again for proper engagement.

8. Clip the safety belts (Fig. 19) closed to secure the roof.

Fig. 18

Handles

Fig. 19

Closed

Safety Belt

Safety

Belt

9. Inspect the outside of the Pop-up Roof System to make sure it has completely closed (Fig. 20).

Closed Pop-up Roof

Fig. 20

Rev: 07.27.2021 Page 10 CCD-0003922

10. After the Pop-up Roof System has been fully closed, the camper van may be driven.

Do NOT exceed the product's maximum speed limit of 80 mph (130 km/h).

Do NOT drive with the pop-up roof system opened or product damage may occur.

Do NOT drive with people or pets inside the pop-up roof system's sleeping area or personal injury

may occur.

What is Happening Why? What Should Be Done?

Pop-up latching

clamps won't release.

Latch release track

blocked.

Check latching release track for dirt, debris and

obstructions. Clean track of any dirt and debris.

Clear any obstructions.

Latch release track

damaged.

Do not attempt to repair damaged components

at the risk of voiding the LCI limited warranty.

Contact the Lippert Care Center.

Pop-up latching

clamps won't clamp

shut.

Latch clamping

mechanism blocked.

Check latching clamp mechanism for dirt, debris

and obstructions. Clean mechanism of any dirt

and debris. Clear any obstructions.

Latch clamping

mechanism damaged.

Do not attempt to repair damaged components

at the risk of voiding the LCI limited warranty.

Contact the Lippert Care Center.

Pop-up doesn't fully

extend.

Support arm track

blocked.

Check support arm track for dirt, debris and

obstructions. Clean track of any dirt and debris.

Clear any obstructions.

Support arm track

damaged.

Do not attempt to repair damaged components

at the risk of voiding the LCI limited warranty.

Contact the Lippert Care Center.

Pop-up doesn't fully

retract.

Support arm track

blocked.

Check support arm track for dirt, debris and

obstructions. Clean track of any dirt and debris.

Clear any obstructions.

Support arm track

damaged.

Do not attempt to repair damaged components

at the risk of voiding the LCI limited warranty.

Contact the Lippert Care Center.

Troubleshooting

The following troubleshooting chart only covers basic operational concerns. If other concerns exist other

than what is listed in the troubleshooting chart, contact the Lippert Care Center at (574) 537-8900.

A. If wheel chocks have been used, make sure they have been removed before driving.

B. If engaged, release brakes before driving.

C. Do NOT exceed the product's maximum speed limit of 80 mph (130 km/h).
