Lippert Thin Shade 806621 Instrucciones de instalación

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

Window Replacement with Thin Shade KitWindow Replacement with Thin Shade Kit

Kit #Kit # DescriptionDescription

806621 Window glass (tinted), exterior frame, interior

frame, window release tools, Thin Shade

Table of Contents

Introduction ............................................ 2

Safety ................................................... 2

Resources Required ................................... 2

Parts List ................................................ 2

Remove Existing Window .............................. 3

Option A: Screw-Type Window ........................ 3

Option B: Snap-In Window ............................ 3

Install New Window .................................... 5

Install Thin Shade ...................................... 5

Notes .................................................... 7

Entry Door Window

Replacement with

Thin Shade Kit

Installation and

Owner’s Manual

(For Aftermarket Applications)

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

Introduction

This document provides the procedures to replace the

window in LCI RV entry door with the LCI Thin Shade with

a snap-together window frame.

Additional information about this product can be obtained

from support.lci1.com or by downloading the free myLCI

app. The myLCI app is available for free on Apple App

Store®for iPhone®and iPad®and also on Google Play™for

Android™users.

App Store®and iPad®are registered trademarks of

Apple Inc.

Google Play™and Android™are trademarks of Google Inc.

Safety

Resources Required

• One or two people, depending on task

• Phillips screwdriver (for screw-type windows)

• Block of wood

• Rubber mallet

MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP

CLEAR AND USE CAUTION.

Parts List

PN 806621 Window Replacement with Thin Shade Kit

Letter Part # Description Qty

A711862 Outer window frame, 15” x 24” 1

B706073 Glass; dark tint - G20; 13 1/4” X

22 1/4” tempered 1

C786036 Inner window frame, 15” x 24” 1

D786037 Thin Shade, 11 7/8” x 21 1/2” 1

E429436 Kit of window release tools 16

FAILURE TO FOLLOW THE INSTRUCTIONS

PROVIDED IN THIS MANUAL MAY RESULT IN DEATH,

SERIOUS INJURY, UNIT DAMAGE OR VOIDING OF

THE COMPONENT WARRANTY.

NOTE: Part numbers are shown for identification purposes

only. Not all parts are available for individual sale. All parts

with a link to the Lippert Store can be purchased.

Read and understand instructions before servicing, installing

and/or operating this product. Adhere to all safety labels.

This manual provides general instructions. Many variables

can change the circumstances of the instructions, i.e., the

degree of difficulty, operation and ability of the individual

performing the instructions. This manual cannot begin to

plot out instructions for every possibility, but provides the

general instructions, as necessary, for effectively interfacing

with the device, product or system. Failure to correctly

follow the provided instructions may result in death, serious

personal injury, severe product and/or property damage,

including voiding of the LCI limited warranty.

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

Remove Existing Window

Option A: Screw-Type Window

1. Remove the 16 Phillips head screws from the interior

window frame (Fig.1A).

Fig.1

Option B: Snap-In Window

1. Slide the 16 release tools (Fig.2A) into the 16 slots (Fig.3)

around the outside perimeter of the interior window frame.

slots

Fig.2

Fig.3

A A A

interior frame

A A A

A A

interior frame

2. Support the window glass on the interior side to

prevent the glass from falling inward, causing it to pull

away from the interior frame.

NOTE: A second person is recommended to assist during

the removal of the interior frame.

3. Remove exterior frame and glass.

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

NOTE: There are grooves on the bottom of the release

tools that fit into the ribs of the frame, allowing the tool to

open the frame’s catch feature (Fig.4).

Fig.4

groove on release tool

interior frame

exterior

frame

2. Support the window glass on the interior side to

prevent the glass from falling inward, causing it to pull

away the interior frame.

NOTE: A second person is recommended to assist during

the removal of the interior and exterior frame.

3. Remove exterior frame and glass.

4. Remove release tools from interior frame.

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

Install New Window

1. Place the new outer frame with glass against the exterior

of the door (Fig.5).

interior

window

frame

with catch

feature

exterior

window

frame with

protrusions;

glass

installed

Fig.5

Install Thin Shade

1. Unlatch the small levers at the top of the window frame

in a left-to-right direction (Fig.6).

levers

Fig.6

2. Unlatch the levers at the bottom of the frame in a

right-to-left direction (Fig.6).

NOTE: Make sure the frame’s seal is positioned properly

against the door.

NOTE: The next step will require another person to assist

while preparing to install the interior frame.

2. While one person holds the exterior frame and glass

against the door, the other person snaps the interior frame

into the exterior frame. Make sure all 16 locking points click

into place.

3. Hold a wood block on one side of the frame and tap

the other side with a rubber mallet. The gap between the

frame and door will close when the seal is completely

compressed and the exterior frame touches the door.

4. Continue tapping the frame around its perimeter until all

16 points are fully locked.

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

Fig.7

3. Holding the top rail of the Thin Shade at an approximate

45-degree angle, insert one end of the rail into the corner

between the inner frame and glass (Fig.7A).

NOTE: Shade portion not shown for clarity.

4. Repeat this action on the opposite end of the top rail.

5. Press both ends of the rail up and latch in-place, moving

the top levers (Fig.6) in a right-to-left direction.

6. Holding the bottom rail at an approximate 45-degree

angle, insert one end into the corner between the inner and

outer frame (Fig.7B).

7. Repeat this action on the opposite end of the bottom rail.

8. Press both ends of the rail down and latch in-place,

moving the bottom levers in a left-to-right direction.

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

Notes

lci1.com 574-537-8900 Rev. 06.04.21CCD-0002703

Entry Door Window

Replacement with

Thin Shade Kit

Installation and Owner’s Manual

(For Aftermarket Applications)

Manual information may be distributed as a complete

document only, unless Lippert Components provides

explicit consent to distribute individual parts.

All manual information is subject to change without

notice. Revised editions will be available for free

download at lci1.com. Manual information is considered

factual until made obsolete by a revised version.

Please recycle all obsolete materials and contact

Lippert Components with concerns or questions.
