Linksys WRT54G-TM Manual de operación

The All-In-One Wireless-G Networking Solution with Wi-Fi

Phone Support

Product Data

Model WRT54G-TM

Wireless-G

Broadband Router

The Linksys Wireless-G Broadband Router is really three devices

in one box. First, there's the Wireless Access Point, which lets you

connect both screaming fast Wireless-G (802.11g at 54Mbps) and

Wireless-B (802.11b at 11Mbps) devices to the network. There's

also a built-in 4-port full-duplex 10/100 Switch to connect your

wired-Ethernet devices together. Connect four PCs directly, or

attach more hubs and switches to create as big a network as you

need. Finally, the Router function ties it all together and lets your

whole network share a high-speed cable or DSL Internet

connection, files, and other resources.

The Router automatically transitions live phone calls between the

T-Mobile wireless network and Wi-Fi when used with your T-

Mobile Wi-Fi enabled phone. Special software in the router makes

it push-button simple to configure the Wi-Fi link to your phone.

And you’ll get enhanced signal strength and battery performance

from your Wi-Fi phone versus standard routers.

Wi-Fi Protected Access™ 2 (WPA2) protects your data and privacy

with up to 128-bit industrial-strength encryption. The Router can

serve as a DHCP Server, has a powerful SPI firewall to protect your

PCs against intruders and most known Internet attacks, supports

VPN pass-through, and can be configured to filter internal users'

access to the Internet. Advanced configuration is a snap with the

web browser-based interface.

With the Linksys Wireless-G Broadband Router at the center of

your home or office network, you can share a high-speed Internet

connection, files, printers, and multi-player games with flexibility,

speed, security and simplicity!

All-in-one Internet-sharing Router,

4-port Switch, and Wireless-G

(802.11g) Access Point

Shares a single Internet

connection and other resources

with Ethernet wired and Wireless-

G and -B devices

Automatically transitions live calls

between the T-Mobile wireless

network and Wi-Fi when used with

your T-Mobile Wi-Fi enabled

phone

High security: Wi-Fi Protected

Access™ 2 (WPA2), wireless MAC

address filtering, powerful SPI

firewall

Broadband Router

Wireless-G

Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of

trademarks or registered trademarks of their respective holders.

Model WRT54G-TM

WRT54G-TM-DS-70605NC DF

Features

• Complies with 802.11g and 802.11b

(2.4GHz) Standards

• Unsurpassed Wireless Security with Wi-Fi

Protected Access™ 2 (WPA2)

• Enhanced Internet Security Management

Functions including Internet Access

Policies with Time Schedules

• All LAN Ports Support Auto-Crossover

(MDI/MDI-X) - No Need for Crossover

Cables

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

[email protected]m

Web: http://www.linksys.com

Linksys products are available in more than

50 countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit our

Worldwide Web Site at www.linksys.com.

Minimum Requirements Package Contents

• 500 MHz or Faster Processor

• 128 MB of RAM

• Internet Explorer 5.5 or Firefox 1.0 or Higher for

Web-based configuration

• CD-ROM Drive

• Windows 2000, XP or Vista

•NetworkAdapter

• Wireless-G Broadband Router

• Setup CD-ROM

•UserGuideonCD-ROM

• Power Adapter

• Ethernet Network Cable

• Quick Installation Guide

• FAQ (Frequently Asked Questions) Sheet

Specifications

Model WRT54G-TM

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.11g, IEEE 802.11b

Channels 11 Channels (US, Canada)

Ports/Buttons Internet: One 10/100 RJ-45 Port

LAN: Four 10/100 RJ-45 Switched Ports

One Power Port

One Reset Button

One Get Security Key

Cabling Type UTP CAT 5

LEDs Power, WLAN, LAN (1, 2, 3, 4), Internet

RF Power Output 18 dBm

UPnP able/cert Able

Security Features Stateful Packet Inspection (SPI) Firewall, Internet Policy

W i r e l e s s S e c u r i t y W i - Fi P r o t e c t e d A c c e s s ™ ( W P A ) , W i - F i P r o t e c t e d A c c e s s ™ 2 ( W P A 2 ) ,

WEP, Wireless MAC Filtering

Environmental

Dimensions 7.32" x 1.89" x 7.87"

(186 x 48 x 200 mm)

Weight 17 oz (0.482 kg)

Power External, 12V DC, 1A

Certification FCC, IC-03, CE, Wi-Fi (802.11b, 802.11g), WPA, WPA2, WMM

Operating Temp. 0° C to 40° C (32° F to 104° F)

Storage Temp. -20° C to 70° C (-4° F to 158° F)

Operating Humidity 10% to 85% Non-Condensing

Storage Humidity 5% to 90% Non-Condensing

Warranty 3-Years Limited
