Linksys XAC Series Manual de usuario

1

Product Overview

2

router

3

•

•

•

•

•

•

•

4

Linksys XAC-Series

Product Overview

Wall-mounting placement

The router has two wall-mount slots on its bottom panel The distance between the

slots is 82 mm Two screws are needed to mount the router

Wall-mounting template

Print this page at 100%

Cut along the dotted line, and place on the wall to drill precise spacing

note

suggested mounting Hardware

7-8 mm

3-5 mm

1 5-2 mm

5

Setting Up Your Router

Linksys XAC-Series

Linksys is not responsible for damages incurred by unsecured wallmounting

hardware

Follow these instructions:

1. Determine where you want to mount the router Make sure that the wall you use is smooth,

flat, dry, and sturdy Also, make sure the location is within reach of an electrical outlet

2. Using the template on the next page, drill two holes into the wall

3. Insert screws leaving 3 mm of the heads exposed

4. Position the router so the wall-mount slots line up with the two screws

5. Place the wall-mount slots over the screws and slide the router down until the screws fit snugly into the wall-mount slots

6

Setting Up Your Router

Linksys XAC-Series

Setting Up Your EA-Series Router

7

Setting Up Your Router

Linksys XAC-Series

8

Setting Up Your Router

Linksys XAC-Series

How to connect to Linksys Smart Wi-Fi

Use Linksys Smart Wi-Fi to configure your router from any computer that has an

Internet connection

To open Linksys Smart Wi-Fi:

1. Click the Linksys Smart Wi-Fi icon on your desktop

- OR -

Open a Web browser and go to

2. Enter the e-mail address and password you set up earlier, and click Sign

In

How to change router settings

Use Linksys Smart Wi-Fi to change settings on your router and set up special

features such as parental controls and guest access

NOTE:

For additional help on any menu, click Help at the top of the screen

To change router settings:

1. Open Linksys Smart Wi-Fi and log in to your account

2. In the menu on the left, click an option:

•Device List lets you see and manage all network devices connected

to your router View devices on your main network and your guest

9

Setting Up Your Router

Linksys XAC-Series

network, disconnect the devices, or display information about each

device
