Linksys SFE1000P Manual de operación

BUSINESS SERIES

PRODUCT DATA

Model: SFE1000P

8-Port 10/100 Ethernet

Switch with PoE

Linksys One-Ready, Secure, Reliable,

Managed Ethernet Switching with PoE

The SFE1000P is an 8-port fully-managed 10/100 Ethernet switch with 2 Gigabit

copper or optical interfaces for connecting to a core switch. It is Linksys One-

Ready, allowing it to be used in both Linksys One and non-Linksys One networks. Its

intelligence, small size and fan-less design make it ideal for a small office, conference

room, or training room.

For wireless or Voice Over IP (VoIP) deployments, the SFE1000P supports the IEEE

802.3af standard for Power over Ethernet (PoE). With automatic load sensing, the power

control circuitry automatically detects PoE on end devices before providing power. (PoE

is limited to the fixed 10/100 Base-T/TX ports.) The unit can provide maximum output

power of up to 15.4W per PoE port on 4 ports, or up to 7.5W per PoE port on 8 ports

simultaneously. The unit provides independent overload and short-circuit protection for

each port. LED indicators indicate the power status for each PoE port.

With the enhanced quality of service (QoS) and traffic-management features provided by

the SFE1000P, voice and video data can be prioritized, ensuring clear and reliable voice

communications. An intuitive, secure management interface enables you to easily set up the

QoS parameters, along with the other advanced security and performance features, resulting

in an optimized, more secure network.

Linksys One integrates data networking and low-cost VoIP service with applications and

other business services into one simple solution for small businesses. Because the SFE1000P

is Linksys One-Ready, it can be seamlessly integrated into a Linksys One data or data/voice

network. Linksys One technology is automatic and self-configuring. Once connected, a Linksys

One Service Router will discover the SFE1000P, automatically configure it, and make it available

to other users on the network.

Provides IEEE 802.3af PoE

to IP phones, cameras, or

access points

Dual gigabit uplinks

provide increased

bandwidth and

redundancy

Provides maximum security

and traffic control with

policing, shaping, access

control lists, and QoS

Linksys One-Ready—

simple, automated

installation with

Linksys One services

routers present

SFE1000P

PRODUCT DATA

BUSINESS SERIES

Features

8 - 10/100 switched RJ-45•

ports deliver up to 200 Mbps

of throughput per port

2 - 10/100/1000 switched RJ-•

45/Mini-GBIC combo ports

PoE on the 10/100 ports•

supply up to the IEEE 802.3af

maximum—15.4W per port

for up to 4 ports, or 7.5W per

port on 8 ports

5.6 Gbps non-blocking,•

store-and-forward switching

mechanism

Simplified QoS management•

enabled by queuing

techniques using 802.1p,

Diffserv or ToS traffic

prioritization specifications

WebView management•

allows switch configuration

and monitoring using a

standard web browser

Secure remote management•

of the switch via SSH and

SSL secure channel network

protocols

802.1q-based VLANs enable•

segmentation of networks

for improved performance

and security

Private VLAN edge simplifies•

network isolation for guest

connections or autonomous

networks

Automatic configuration•

of VLANs across multiple

switches through GVRP/

GARP

Automatic MDI/MDIX•

detection support

8-Port 10/100 Ethernet Switch with PoE

Specifications

Model SFE1000P

Ports 8 RJ-45 connectors for 10BASE-T and 100BASE-TX

2 RJ-45 connectors for 10BASE-T/100BASE-TX/1000BASE-T with 2 SFP slots

Console port

Auto MDI/MDI-X

Auto-negotiate/Manual setting

Buttons None

Cabling Type UTP CAT 5 or better for 10BASE-T/100BASE-TX

UTP CAT 5e or better for 1000BASE-T

LEDs 10/100 Link/Act, PoE, 2 Giga Link/Act, Speed, System

Power over Ethernet

802.3af Complaint Supplies up to IEEE standard maximum of 15.4W on 4 10/100 ports or

up to 7.5W on 8 10/100 ports

Performance

Switching Capacity 5.6 Gb non-blocking

Forwarding Rate 4.17 Mpps wire-speed performance

Layer 2

MAC Table Size 8K

Number of VLANs 256 active VLANs (4096 range)

VLAN Port-based and 802.1q tag-based VLANs; Management VLAN

HOL Blocking Head-of-line blocking prevention

Management

Web User Interface Built-in web user interface for easy browser-based configuration

(HTTP/HTTPS)

SNMP SNMP version 1, 2c, and 3 with support for traps

SNMP MIBs RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like MIB, RFC1493

Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge), RFC2819

RMON MIB (groups 1,2,3,9 only), RFC2737 Entity MIB, RFC 2618 RADIUS

Client MIB, RFC 1215 Traps, and Private PoE MIB

Remote Monitoring (RMON) Embedded RMON software agent supports four RMON groups (history,

statistics, alarms, and events) for enhanced traffic management,

monitoring, and analysis)

Firmware Upgrade Web browser upgrade (HTTP) and TFTP

Port Mirroring Traffic on a port can be mirrored to another port for analysis with a

network analyzer or RMON probe.

Other Management Traceroute

Secure Socket Layer (SSL)

Secure Shell (SSH)

RADIUS

SSL security for web user interface

DHCP client

BootP

SNTP

Xmodem upgrade

Cable diagnostics

PING

Telnet client (SSH secure support)

Security

IEEE 802.1x 802.1x - RADIUS authentication, MD5 encryption

Access Control Lists (ACLs) Drop or rate limit based on source and destination MAC or IP address,

protocol, TOS/DSCP, port, VLAN, and Ethertype

Availability

Link Aggregation Using IEEE 802.3ad LACP, up to 8 ports in up to 8 groups

Storm Control Broadcast, multicast and unknown unicast

Spanning Tree IEEE 802.1D Spanning Tree, IEEE 802.1w Rapid Spanning Tree, and

IEEE 802.1s Multiple Spanning Tree

PRODUCT DATA

BUSINESS SERIES

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

Web: www.linksys.com

Linksys products are available in more

than 50 countries, supported by

12 Linksys Regional Offices throughout

the world. For a complete list of local

Linksys Sales and Technical Support

contacts, visit our worldwide website

at www.linksys.com

Check the product package and contents for specific features supported. Specifications are subject to change without notice.

Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries.

respective holders.

8030110NC-KO Model: SFE1000P

Features

User/Network port-•

level security via 802.1x

authentication and MAC-

based filtering

Increased bandwidth (up•

to 8x) and link redundancy

with Link Aggregation

Control Protocol (LACP)

Enhanced rate-limiting•

capabilities, including back

pressure to control the rate

of data flow into and out of

a port

Provides multicast,•

broadcast, and flood control

Port mirroring for•

noninvasive monitoring of

switch traffic

Jumbo frame support - up to•

1632 bytes

Supports SNMP v1, v2c,•

and v3

Fully rack-mountable using•

included rack-mounting

hardware

IGMP (v1/v2) Snooping Provides for fast client joins and leaves of multicast streams and limits

bandwidth-intensive video traffic to only the requestors

Supports 256 multicast groups

Quality of Service

Priority Levels 4 hardware queues

Scheduling Priority queuing and weighted round robin (WRR)

Class of Service Port-based

802.1p VLAN priority-based

IPv4/v6 IP Precedence/TOS/DSCP-based

TCP/UDP port-based

Diffserv

Classification and Re-marking ACLs

Rate Limiting Ingress policer

Egress rate control

Standards

802.3 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet,

802.3ab 1000BASE-T Gigabit Ethernet, 802.3z Gigabit Ethernet,

802.3x Flow Control, 802.3 ad LACP,802.3af PoE, 802.1D STP,

802.1Q/p VLAN, 802.1w Rapid STP, 802.1s Multiple STP,

802.1x Port Access Authentication

Environmental

Dimensions 12.01" x 1.73" x 6.69" (305 x 44 x 170 mm)

Weight 3.02 lb (1.37 kg)

Power External AC power adapter

Certification FCC Part15 Class A, CE Class A, UL, cUL, CE mark, CB

Operating Temp. 32 to 104°F (0 to 40°C)

Storage Temp. -4 to 158°F (-20 to 70°C)

Operating Humidity 10 to 90%, Non-condensing

Storage Humidity 10 to 95%, Non-condensing

Package Contents

One SFE1000P with 8 10/100 Base-T and 2 Gig combo ports with SFP or RJ-45•

One AC power adapter with power cord•

Two rack-mounting kits with 8 screws•

One CD-ROM with User Guide (PDF) included•

One registration card•

Console cable•

Minimum Requirements

Web-based configuration—Java-enabled web browser•

Cat5 Ethernet network cable•

TCP/IP, network adapter, and network operating system (such as Microsoft Windows or Linux) installed on•

each computer in the network
