Linksys BEFVP41 - EtherFast Cable/DSL VPN Router Manual de operación

Model

Product Data

WIRED

BEFVP41 (UK/EU)

Add IPSec VPN to Your Broadband Network

An Internet con-

nection-sharing

Router with built-in

VPN capability

Connect four local PCs

directly, or daisy-chain out

to more hubs and switches

as your network grows

Securely connect

from your home

office to the corpo-

rate network via VPN

Or use VPN client software

to securely connect to

your office when traveling

The EtherFast Cable/DSL VPN Router from Linksys is the ideal solution for remotely accessing a network

securely over the Internet using cutting-edge encryption and authentication methods.

Built from the popular standard Linksys 4-Port Router Model BEFSR41, the VPN Router expands its functional-

ity and security features by utilizing 56-bit DES and 168-bit 3DES encryption, and Internet Key Exchange

(IKE). A built-in IPSec co-processor from Hifn allows for complete data privacy for the access and

exchange of your most sensitive data from your home to your corporate network or between remote

branch offices without the additional cost of IPSec VPN client software for each computer. Mobile workers

can also connect to a corporate network using an IPSec based VPN client software solution. The EtherFast

Cable/DSL VPN Router is capable of conducting up to 50 simultaneous IPSec VPN tunnels while allowing

additional savings with no upgrade fees or technical support costs.

The VPN Router is compatible with other major IPSec VPN devices and IPSec VPN client software as well as

virtually all major operating systems and standards, which makes the setup and use simple for home and

corporate office. The EtherFast® Cable/DSL VPN Router is a simple solution for your broadband needs.

Cable/DSL VPN

with 4-Port 10/100 Switch

EtherFast®

Router

Product Data

Model

Features

• Full IPSec Virtual Private Net-

work (VPN) Capability

• Supports DES and 3DES

Encryption Algorithms

• Supports MD5 and SHA

Authentications Algorithms

•SupportsIKEKeyManage-

ment

• Supports Up to 50 IPSec Tun-

nels Simultaneously

• Compatible with Other IPSec

VPN Products

• Acts as a DHCP Server for Your

Existing Network

• Hardware Security Co-Proces-

sor by Hifn Inside

• NAT, PPPoE, IP Filter, and MAC

Filter Support

• Built-in 4-Port 10/100 Switch for

Sharing Broadband

Web: http://www.linksys.com/international

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com/inter-

national.

BEFVP41 (UK/EU)

Specifications

Model Number BEFVP41

Standards IEEE 802.3 (10BaseT), IEEE 802.3u (100BaseTX)

Ports One 10/100 RJ-45 Port (Internet)

Four 10/100 RJ-45 Ports (Ethernet)

Cabling Type 10BaseT, 100BaseTX: UTP Category 5 or better

LEDs Power, Internet, Ethernet (1-4)

Security Features DES (56-bit), 3DES (168-bit), MD5, SHA

Warranty 2 Years

Environmental

Dimensions (W x H x D

) 186 mm x 48 mm x 154 mm

Unit Weight 0,36 kg

Power External, 12V 1A

Certifications FCC Class B, CE Mark Commercial

Operating Temp. 0ºC to 45ºC

Storage Temp. -20ºC to 70ºC

Operating Humidity 0% to 90%, Non-Condensing

Storage Humidity 5% to 90%, Non-Condensing

BEFVP41_v2-UK/EU-DS-4108NC-KL

Package Contents

• Cable/DSL VPN Router

• AC Power Adapter

• User Guide (PDF on CD)

•QuickInstall

Minimum Requirements

• Broadband connection and Cable/DSL modem

• TCP/IP Protocol

• CD-ROM Drive

• Internet Explorer 5.0 or Netscape 6 for web-

based configuration

• Network adapter

•Networkcable

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2003

Cable/DSL VPN Router

with 4-Port 10/100 Switch

EtherFast®
