IS 339 ECN 3607 Page 1 of 11

Installation, Operating and Servicing

Instructions

Electric Auto-Fill Water Boilers

EB3F, EB4F, EB6F, EB6TF

Please make a note of your product details for

future use:

Date Purchased:_________________________

Model Number:__________________________

Serial Number:__________________________

Dealer:_________________________________

_______________________________________

IS 339 ECN 3607 Page 2 of 11

CONTENTS

Important Information

Warnings and Precautions

Technical Data

Checklist of Enclosures

Installation and Commissioning

3-5

Operating Instructions

5-7

Cleaning

7-8

Servicing, Maintenance and Component Replacement

Fault Finding

Spare Parts List

Accessories

Service Information and Guarantee

IMPORTANT INFORMATION

Read these instructions carefully before using this product, paying particular

attention to all sections that carry warning symbols, caution symbols and notices.

Ensure that these are understood at all times.

WARNING!

This symbol is used whenever there is a risk of personal injury.

CAUTION!

This symbol is used whenever there is a risk of damaging your Lincat product.

NOTE:

This symbol is used to provide additional information, hints and tips.

KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 339 ECN 3607 Page 3 of 11

WARNINGS AND PRECAUTIONS

This appliance must be installed, commissioned and serviced by a qualified person

in accordance with national and local regulations in force in the country of

installation.

If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualified person.

Ensure that the plug/socket is accessible at all times.

Strip plastic coating and clean the appliance before use.

During operation parts may become hot - avoid accidental contact.

Disconnect this appliance before servicing, maintenance or cleaning.

TECHNICAL DATA

Model

Height

(mm)

Width (mm)

Depth (mm)

Weight (kg)

EB3F

655

290

465

EB4F

EB6F

455

EB6TF

CHECK LIST OF ENCLOSURES

Warranty card

Instructions manual

Drip tray and insert

Inlet hose with ¾” BSP connection

Filterflow badge

Sample of de-scaling agent

INSTALLATION AND COMMISSIONING

This appliance must be earthed.

An equipotential bonding terminal is provided to allow cross bonding with other

equipment.

IS 339 ECN 3607 Page 4 of 11

If replacing the plug connect the terminals as follows:

Green and Yellow wire Earth E

Blue wire Neutral N

Brown wire Live L

The fixed wiring insulation must be protected by insulated sleeving having a

temperature rating of 60 Deg C.

Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary

polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)

Install this appliance on a level surface ensuring all vents are unobstructed.

The serial plate is located on Fig 1 (F).

Instructions for wall mounting are supplied with the wall mounting kits (see

Accessories).

Model

Power (kW)

Ambient

temperature Deg C

Water inlet

pressure (bar)

Water inlet

pressure (kPa)

EB3F

3.0

5 to 30

1 to 8

100 to 800

EB4F

4.5

EB6F

6.0

EB6TF

6.0

Electrical supply

The EB3F is supplied with a 13 amp plug.

The EB4F is supplied with a bulkhead cable connector. Connect a 2.5mm2 3 core

cable.

The EB6F and EB6TF are supplied with a bulkhead cable connector. Connect a

4mm2 single or 3 phase cable.

Means of isolation with at least 3mm contact separation in all poles must be

incorporated into the fixed wiring of these appliances.

Water supply and waste connection (All)

Connect the supplied white water inlet hose to the inlet connection point on the

base of the boiler and the other end to the mains supply via an accessible isolating

tap with a ¾” BSP thread.

Use the hose set supplied with the appliance - any previous hose set is not to be re-

used.

If required, the drip tray can be connected to a waste water outlet using a ½”

bulkhead connector (not supplied). Knock out the blank in the tray base. If cables

IS 339 ECN 3607 Page 5 of 11

are required to exit at either side of the boiler the thinner section between the

moulded base sides may be cut away with a hacksaw.

Ensure the metal overflow pipe protrudes through the metal base of the boiler.

OPERATING INSTRUCTIONS

Fig 1

Only qualified or trained personnel should use this appliance.

First Use

Switch on the water and electricity supplies. Leave the boiler to fill for 30 minutes.

Drain off approximately 5 litres of water to remove any loose carbon particles from

the filter.

IS 339 ECN 3607 Page 6 of 11

Regular Operation

The boiler starts automatically when the water supply is turned on. During the

heating cycle, only small quantities of water are added to ensure hot water is

always available at the tap.

The boiler is designed to be permanently switched on: it is only necessary to turn it

off for de-scaling or maintenance.

Water is drawn off through the tap (E).

Adjustment –Water temperature, screen backlight and contrast

Consult Fig 1.

Turn power off and on again. The FilterFlow screen (B) is displayed on the control

panel (A).

Press and hold the power button (D) until the software version is displayed. Press

the function button Fn (C) and the temperature will be displayed.

Press the power button to cycle through the values 70-96 Deg C. Press the Fn

button to select the required value.

The backlight adjustment screen is displayed next. Press the power button to cycle

through values 1-25. Press the Fn button to select the required value.

The contrast adjustment screen is displayed next. Press the power button to cycle

through values 35-60. Press the Fn button to select the required value.

Press the power button to exit.

Standby

If the boiler is to be left unused for any length of time, turn the element off by

pressing the power button.

Filter replacement

The filter display shows the estimated life remaining in the filter cartridge (Fig 2). A

reminder message is displayed when the filter needs changing. The boiler can be

used without a filter, but scale will build up quickly and water taste may be affected.

IS 339 ECN 3607 Page 7 of 11

Fig 2

To replace the filter:

Twist the base of the filter (G) 90 degrees to the left and lower the cartridge out of

the appliance. It will contain a small amount of water.

Remove the black cap and place it on the new filter.

Re- insert the filter into the recess and lock in place by twisting to the right.

Press and hold the Fn button for 5 seconds to reset the filter life.

Drain off approximately 5 litres of water to remove any loose carbon particles from

the filter.

CLEANING

Do not use a water jet or steam cleaner, and do not immerse this appliance.

Clean all panels with warm water and mild detergent, do not use abrasive

materials. Dry with a soft cloth.

Slide out and empty the drip tray (H) regularly, and wipe the dispensing tap spout

daily to remove lime scale deposits.

De-scaling

The boiler should be de-scaled regularly to maintain efficient operation and water

quality. The frequency depends on the hardness of the water and timely

replacement of the filter.

The de-scaling procedure must be performed by trained personnel as it

requires the removal of panels from the boiler giving access to live electrical

components.

FILTER

READY

STANDBY

CLEAR

CHANGE

FILTER

IS 339 ECN 3607 Page 8 of 11

De-scaling the boiler at the end of the working day gives the de-scaling agent

several hours to work. Lincat recommend our own de-scaling agent MS19,

available from our Spares department.

Wear protective clothing.

Isolate the boiler from the electrical supply.

Turn off the power and allow the water to cool to 60 Deg C.

Using a 3mm Allen key, remove the screw in the top of the boiler.

Remove the insulation from the top of the tank. Unscrew and remove the tank lid.

Add the de-scaling agent slowly to avoid eruption of the water, following the

manufacturer’s instructions.

Replace tank lid and outer lid and attach an ‘Out of Use’ notice to prevent use

during de-scaling.

Turn on the electricity and run the boiler normally for 30 minutes. Isolate the boiler

and allow the water to cool.

Remove both outer and tank lids again. Inspect the tank and level sensor housings

for scale deposits. If necessary repeat the de-scaling process.

Drain and flush all de-scaling agent as follows:

Remove the drip tray.

Remove the front panel by unscrewing the two screws behind the drip tray.

Connect a hose from the overflow pipe to a bucket and open the service valve to

drain the water from the tank.

Flush the tank with clean water, shut the valve and replace the front cover.

Replace the drip tray and tank lid, ensuring the gasket is sealing the top of the tank

correctly.

Re-fit the outer lid and turn on the boiler.

SERVICING, MAINTENANCE AND

COMPONENT REPLACEMENT

Other than replacing the filter, all servicing, maintenance and component

replacement on these appliances should be carried out by one of our recommended

service engineers.

IS 339 ECN 3607 Page 9 of 11

The control panel displays information that can help with fault diagnosis. Before

calling for service, draw off a litre of water, clear the fault code by pressing the Fn

button and turn the boiler off and on again at the supply. If the fault persists, call

service for advice.

Message displayed

Possible causes

Corrective action

FILTER DESCALE

CAUTION

SEE MANUAL

STANDBY CLEAR

Scale on level sensors

Boiler overfilling

Descale

Check water inlet valve

FILTER NO WATER

FAULT

SEE MANUAL

STANDBY CLEAR

Water turned off

Inlet hose kinked or

blocked

Water pressure too high or

low

Drain valve open

Check water supply and

drain valve

Call service if fault

persists

FILTER NOT HEATING

FAULT

SEE MANUAL

STANDBY CLEAR

Boil dry/overheat protector

tripped

Temperature sensor fault

Element failed

PCB fault

Faulty or loose connection

Check connections

Call service if fault

persists

FILTER THERMISTOR

FAULT

SEE MANUAL

STANDBY CLEAR

Temperature sensor fault

Call service

FAULT FINDING

IS 339 ECN 3607 Page 10 of 11

Part Number

Description

Used on

CO206

¼” to 3/8” elbow

All

CO215

Contactor

All excluding EB3F

DV02

Service valve

All

EBM05

Outer lid

EB3F, EB4F

EBM08

Outer lid

EB6F, EB6TF

EL235

Element 3kW

EB3F, EB6F, EB6TF

EL241

Element 4.5kW

EB4F

FC02

Filter cartridge

All

FH02

Filter head

All

GA48

Lid gasket

EB3F, EB4F

GA51

Lid gasket

EB6F, EB6TF

LE47

Level sensor insulator

All

LE48

Upper level sensor

All

LE49

Lower level sensor

All

PI12

Inlet hose

All

PL202

Mains cable

EB3F

PR74

Circuit board

EB3F

PR75

Circuit board

EB4F

PR76

Circuit board

EB6F, EB6TF

SL20

Tap union nut

All

SL21

Tap circlip

All

SL29

Tap

All

SO23

Solenoid valve

EB4F, EB6F, EB6TF

SO24

Solenoid valve

EB3F

TH87

95ocutout thermostat

All

TH88

120ocutout thermostat

All

TH98

Thermistor

All

Part Number

Description

Used on

BR49

Wall mounting kit

EB3F, EB4F

BR50

Wall mounting kit

EB6F, EB6TF

FC02

Replacement filter cartridge

All

SPARE PARTS LIST

ACCESSORIES

Otros manuales para EB3F

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Caldera de Lincat

Lincat

Lincat EB3 Guía del usuario

Lincat

Lincat Opus OG7003 Guía del usuario

Lincat

Lincat EB3F/PB Manual del propietario

Lincat

Lincat WMB5F/B Manual del propietario

Lincat

Lincat WMB3F/B Manual del propietario

Lincat

Lincat EB3HC Manual de servicio

Lincat

Lincat WMB3F/B Manual de usuario

Lincat

Lincat EB3FX/HC/PB Manual del propietario

Lincat

Lincat WMBFX Series Manual del propietario

Lincat

Lincat M3F Manual del propietario

Lincat

Lincat EB3FX Manual del propietario

Lincat

Lincat LWB2 Manual del propietario

Lincat

Lincat M7F Manual del propietario

Lincat

Lincat EB3F Instrucciones de funcionamiento

Lincat

Lincat EB3FX/HC Manual del propietario

Lincat

Lincat Opus 800 Series Guía del usuario

Lincat

Lincat LWB2 Manual de funcionamiento

Manuales populares de Caldera de otras marcas

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manual de usuario

Radijator

Radijator BIO max 23.1 Manual de usuario

Brunner

Brunner BSV 20 Manual de usuario

Buderus

Buderus Logamax GB062-24 KDE H V2 Manual de usuario

Potterton

Potterton 50e Hoja de datos

UTICA BOILERS

UTICA BOILERS TriFire Manual de usuario

Joannes

Joannes LADY Series Manual

ECR International

ECR International UB90-125 Manual de instrucciones

Froling

Froling FHG Turbo 3000 Manual de usuario

Froling

Froling P4 Pellet 8 - 105 Manual de usuario

U.S. Boiler Company

U.S. Boiler Company K2 Manual de usuario

Henrad

Henrad C95 FF Manual de usuario

NeOvo

NeOvo EcoNox EF 36 Manual de usuario

Potterton

Potterton PROMAX SL 12 Manual de usuario

Eco Hometec

Eco Hometec EC 25 COMPACT Manual de usuario

Viessmann

Viessmann VITODENS 200 Guía

Baxi

Baxi Prime 1.24 Manual de usuario

REXNOVA

REXNOVA ISA 20 BITHERMAL Manual de usuario
