Lilliput BM280-4K Manual de usuario

Lilliput BM280-4K

User Manual

VDH Video Data Handels GmbH

Kohlentwiete 14

22761 Hamburg

www.videodata.de

IMPORTANT SAFETY INSTRUCTIONS

Please read User Guide before using this product.

Please keep User Guide for future reference.

Please read the cautions to prevent possible danger and loss of

property.

FEATURES

4K Ultra-HD resolution

Ultra HD 4K screens containing 8.3 million pixel

(3840×2160),

so the resolution is four times that of Full HD.

Which makes the innovative 4K screen ultimate in

cinematic displays.

Big unit, large view

It features 28" 16:9 LED display, 170° wide viewing

angles,

enjoy Consistent Images from Any Perspective.

Strongly recommend for directors!

Precise color

1000:1 high contrast, 450cd/m2 brightness, so you

can enjoy sharper, more detailed images and richer

colors than ever before.

Carry-on suitcase

The suitcase improves the monitor robustness &

portability, also speeds up heat radiating. It makes

monitor more stable and reliable.

Specially suitable for live shooting and post

production.

Metal housing

A good protection from damage with all aluminum

main body, to extend the life time of your monitor.

Rich interfaces

The monitor comes with 3G-SDI, HDMI, VGA, DVI &

Audio interfaces. Multiple inputs meet the best need

of various professional display solutions.

CAUTIONS

Please do not place the display screen towards the ground.

Please avoid heavy impact or drop onto the ground.

Please do NOT use chemical solutions to clean this product. Please

wipe with a clean soft cloth to maintain the brightness of the surface.

Please do not block any vent hole.

Please follow the instructions and trouble-shootings to adjust the

product. Other improper adjustment may result in damage. Any further

adjustment must be performed or conducted by a qualified technician.

Please unplug the power and remove the battery if long-term no-use,

or thunder weather.

Contents

1. PRODUCT DESCRIPTION .............................................................................................4

2. SUN SHADE INSTALLATION..........................................................................................7

3. MENU SETTING..............................................................................................................8

4. ACCESSORIES ............................................................................................................. 11

5. PARAMETERS ................................................................................................................8

6. TROUBLE SHOOTING....................................................................................................9

YP-05151108-2

1、PRODUCT DESCRIPTION

Front

1. Speaker

2. SDI

Signal switch to SDI mode when light on.

3. HDMI 1 ~ 4

Signal switch to HDMI mode when light on.

4. DVI

Signal switch to DVI mode when light on.

5. VGA

Signal switch to VGA mode when light on.

6. MENU/ENTER

Press to enter menu.

Press to enter option in the menu.

7. ◄

Select option in the menu.

Decrease the option value.

Before enter the menu, single press to activate volume, press again

to switch among of volume, brightness, contrast, color, hue,

sharpness and backlight.

8. ►

Select option in the menu.

Increase the option value.

9. EXIT

Back or exit.

10. F1~F4 User definable buttons

Default function options:

F1：Display Mode F2：Display Rotate

F3：Safety Marker F4：Aspect

（functions can be customized by long keep pressing any one of the 4

buttons）

11．Power indicating light (green light: working).

12．Earphone jack

Back

1. Handle

2. VESA 75×75 & VESA 100×100 mounting port

3. Connector protector

Preventing connectors from damage.

4. TALLY port

5. VGA input port

6. DVI input port

7. HDMI input port×4。

HDMI 1: HDMI2.0, support 4K 60Hz

HDMI 2, HDMI 3&HDMI 4: HDMI1.4, support 4K 30Hz

8. Audio L/R

9. SDI input/output ports

10. XLR power port

11.Power switch

‖is battery power; ○ is power off; | is DC power

2. SUN SHADE INSTALLATION

1. Put the sun shade on the suitcase, and match the magnets on both

sides.

2. As shown below after finished.

3. MENU SETTING

Please check whether the device is connected well or not.

3-1. F1~F4 user definable shortcut buttons

Long keep pressing any one of the 4 buttons for 3-5 seconds to

activate shortcut menu setting. Option selected will be highlighted as

white; option will be highlighted as yellow, unavailable option will be

highlighted as gray.

Select option via “◄/►” buttons.

Then press “MENU” button to confirm to set as default option.

Functions can be customized to meet user’s needs: center marker,

safety marker, aspect ratio, under scan, check field, image freeze,

peaking, display mode and image flip.

Default options:

F1：Display Mode F2：Display Rotate

F3：Safety Marker F4：Aspect

3-2. ◄/ ►Buttons Operation

Under non menu screen, press ◄/► buttons to activate volume bar,

Use “ ◄/ ►”buttons to select the desired option.

Press the “MENU“ button to select Volume, Brightness, Contrast,

Saturation, Hue, Sharpness, Backlight, Menu and Exit.

3-3. MENU Operation

When power on, press “MENU” on the device, The menu of function

setting will display on the screen.

Press ◄/ ► button to choose menu;

Then press “MENU”button to confirm;

Press “EXIT”button to return / exit menu.


Brightness 0~100

Contrast

0~100

Color Space

Native / REC709

Saturation

0~100

Hue

0~100

Sharpness

0~4

Temperature 9300，7500，6500，5800，User

Backlight

0~100

\Function

Center Marker

ON, OFF

Safety Marker OFF，95%，93%，90%，88%，85%，80%

Aspect Marker Full Screen，17:9, 16:9，4:3，1.85:1，2.35:1

Aspect Full Screen，17:9, 16:9，4:3，1.85:1，2.35:1

Underscan

ON, OFF

Pixel-to-Pixel ON, OFF

Check Filed OFF, Red, Green, Blue

Freeze Input ON, OFF

False Color ON, OFF

Peaking ON, OFF

Display Mode 1P，2P LR，2P TB，2P PIP，4P

Display Setting

Display Rotate 0°，90°，180°，270° Available when single

display.

LR Ratio

0~4

Available when dual

display on left and

right.

Input Swap

Select Region

Menu setting to region selected according to users’ needs.

Input

Signal switch to region selected according to users’ needs.

Audio

Volume 0~100

Audio Source Analog，Digital 1，Digital 2，Digital 3，Digital 4

。

VGA

Auto Adjust Press to confirm after selected.

Only for

adjusting

VGA

signal

modes.

H Position 0~100

V Position 0~100

Clock 0~100

Phase

0~100

System

Reset

Press to confirm after selected.

Menu Time

5~60s

OSD H Position

0~100 (To set menu display area)

OSD V Position

0~100 (To set menu display area)

Transparency 0~255 (To set menu transparency)

OSD Rotate 0°，90°，270°

Border Width

0~10

Border Color R, G, B, W

Info

To display current information.

4、ACCESSORIES

1. Folding sun shade cover 1 piece

2. Carry-on suitcase 1 piece

3. 15V DC adapter 1 piece

4. Adapter fixing belt 2 pieces

5. Battery plate bracket 1 piece

6. V-mount or Anton bauer mount 1 piece

7. TALLY connector (in bulk) 1 piece

8. Manual 1 copy

9. WHDI Accessories 1 pair (optional)

5、PARAMETERS

Panel

28”LED backlight

Resolution

3840×2160

Aspect Ratio 16：9

Brightness

300cd/

㎡

Contrast

1000: 1

Viewing Angle

170°/ 160°(H/V)

Input Voltage DC 12~24V（XLR）

Input Signal HDMI, VGA，DVI and 3G-SDI

Power Consumption

≤ 48W

Operating Temperature -0℃~60℃

Storage Temperature -20℃~60℃

Dimension（LWD）

670×425×45mm

761×474×173mm（with case）

Weight 9.4kg/21kg（with case）

6、TROUBLE SHOOTING

1. Only black-and-white display.

Check whether the color saturation is properly setup or not.

2. Power on but no pictures.

Check whether the cables of HDMI, VGA，DVI and 3G-SDI are correctly

connected or not. Please use the standard power adapter coming with

the product package. Improper power input may cause damage.

3. Wrong or abnormal colors.

Check whether the cables are correctly and properly connected or not.

Broken or loose pins of the cables may cause a bad connection.

4. When on the picture shows size error.

Press “MENU → Function → Underscan” to zoom in/out pictures

automatically when receiving HDMI signals

5. Other problems.

Please press “MENU” button and choose “MENU→ System→ Reset

→confirm”

6. According to the ISP, the machine cannot function properly.

ISP for program upgrades, non-professionals do not use. Please reboot

your device if press accidentally!

7. No Sound.

Press HDMI button if no sound; if still unavailable, please contact the

technician.

8. No signal displayed when connecting with HDMI 1

Please long press HDMI 1 button for 3-5 seconds to activate HDMI signal.

Note: due to constant effort to improve products and

product features, specifications may change without

notice.
