Lilin IPG012ES Manual de usuario
MERIT LILIN ENT. CO., LTD
http://www.meritlilin.com
INSTRUCTION MANUAL
66-IPG012CSE
IPG012ES
D/NCMOSHDIPCAMERA
IMPORTANT SAFEGUARDS
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
shock to persons.
accompanying the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
CAUTION
Do not drop or strike this equipment.
Do not install the equipment near any naked flames or heat
sources.
Do not expose this unit to rain or excessive moisture, avoid
smoke and dust.
Do not cover cloth or to install this unit in poorly ventilated
places.
Do not continue to operate if there appears to be fault.
Do not touch the power connection with wet hands.
Do not damage the power cord or leave it under pressure.
Sensitive electronics inside are vulnerable to excessive shock.
Excessive heat could damage this unit.
Please the camera in an environmental housing for protection.
If the camera gets wet, unplug it and have it checked by
qualified service personnel.
This may lead to overheating.
If the unit ceases to function, contact qualified service
personnel for help.
Risk of short circuit or electric shock.
Risk of fire or shock circuit.
1
CONGRATULATIONS
Thank you for purchasing this D/N CMOS HD IP Camera. You now
own one of the many fine CCTV products we manufactured. This
product has been carefully inspected under rigid quality control
and should reach you in perfect condition. With reasonable care,
it will provide years of reliable performance.
We recommend that you read this installation and operation
manual thoroughly before installing and operation your new
system.
Here you will find all the information you need to set up and use
the system. If any questions are not answered in the manual,
please contact your dealer.
Before proceeding, please read and observe all instructions and
warnings contained in this manual. Retain this manual with the
original bill of sale for future reference and, if necessary, warranty
service.
When unpacking your new camera, check for missing or damaged
items. If any item is missing, or if damage is evident,
I . Contact your dealer for
assistance.
DO NOT
NSTALL OR OPERATE THIS PRODUCT
2
WARRANTY INFORMATION
Please complete the following product purchase information. The
factory will requests this information when contacted for technical
support, or warranty repair. It is also valuable in case of loss or
theft.
Purchase Date
Serial Number
Model Number
IPG012ES is an indoor HD IP camera built-in H.264 AVC(Advanced Video
Coding) video compression.
H.264 AVC video compression engine supports high definition video quality,
720P resolution, bandwidth efficiency with PPPoE and DDNS.
Also it provides higher bit rate of internet and diverse alarm functions such as
external alarm or movement video detection e-mail or FTP. Moreover,
IPG012ES can do remote surveillance with Java or iPhone cell phone. The
software R&D engineer can use HTTP protocol(HTTPAPI) to develop related
software, and integrate them with existing application software system.
Executive Summary
3
6
2
1
PART DESCRIPTION
4
HD
HD
112mm
54mm
LAN
POWER
RESET
DC12V
VIDEO OUT
CARD
AUDIO IN AUDIO OUT
LEVEL
IRIS
+5V COM. GND
N.O. DIN
SD
43
5
7
8
9
10
56mm
11
12
13
14 15
16
1. LENS MOUNT CAP
FOCAL LENGTH ADJUSTMENT RING AND LOCKING SCREW
CAMERA MOUNTING BRACKET
MICROPHONE
AUTO IRIS CONNECTOR(4PIN SOCKET)
Supplies control signals to an auto iris lens(jack not supplied).
7. POWER LED
Power ON/OFF indicator.
8. RESET KEY
To restore the server to factory default setting.
9. RJ-45 NETWORK CONNECTOR AND INDICATOR LEDS
Green(LINK): While cable of network is connecting the LED is light.
Orange(ACT): When data is communicating, the LED is flashed.
(This network camera support PoE.)
Prevent damages to the image sensor and to keep dust away.
2.
Use this ring to adjusts the back-focal distance or picture focus. Rotate this
ring clockwise or counterclockwise for a CS-mount lens.
Use the locking screw to lock the focal length.
3.
The mounting bracket mounted underneath the main body can be mounted to
either the top or bottom of the camera using the attached screws(M2.6x5.0).
4.
Built-in highly sensitive capacitive microphone.
5. LIGHT SENSOR
Day and night function auto mode detect.
6.
5
10. IRIS LEVELADJUSTMENT VOLUME
Adjusts the signal level when DC control type auto iris lens is in use.
11.SDCARDSLOT
This network camera is compliant with SD/SDHC card.
12. AUDIO INPUT RCA CONNECTOR
Audio signal input.
13. AUDIO OUTPUT RCA CONNECTOR
Audio signal output.
14. DC12V POWER INPUT JACK
DC12V 10% power input.
15. LIVE VIDEO BNC JACK
Plug the video input of monitor to the BNC jack and adjust focus and zoom.
16. ALARM IN/OUT TERMINAL
DIN input terminal can be switched to alarm input
or day/night external control input.
6
+5V COM. GND
N.O. DIN
+5V Output: Max. output 50mA.
N.O./COM.: Max. load +60V/100mA.
DIN terminal can be set either N.O. (normally open) or N.C. (normally
close) mode.
12345
7
IR CUT REMOVABLE EXTERNAL CONTROL SETUP
Access into web page setup menu, under schedule menu, enable External
Control option, the alarm input function will be turned off, DIN input is
switched to day/night external control mode.
External input mode: normally open(NO) or normally closed(NC) mode is
selectable.
External input dwell: may select 1, 2, 5, 10, 15, 20, 30 seconds delay time
interval to avoid wrong operation caused by headlight
of the front light.
AUDIO INPUT MODE SETUP
Access into web page setup menu, under audio adjustment setup menu,
may select Audio Input mode to either camera front microphone or rear's
Audio In (Line IN).
INSTALLATION
ThelensmustbeeitheraCorCSmount type. The protrusion behind the
mounting surface must be within the following limits:
SUITABLE LENSES
C - mount lens CS - mount lens
9mmorless 4mmorless
8
