Lightolier 6706MS38U Manual de usuario

6706MS38U

Decorative, Discus, CFL, 1 Lt. 38W

Page 1 of 2

Job Information Type:

Job Name:

Cat. No.:

Notes:

Ordering Information

Catalog Number Finish Wattage Voltage Lamping

6706MS38U matte silver 38W 120V/277V F38/2D/827/4P Lightolier Catalog Number: 56943

F38/2D/835/4P Lightolier Catalog Number: 56944

ADA Compliant

9 ⅞" (251mm) dia.

8 ¼" (210mm) dia.

1 516"

(33mm)

(102mm)

13 1516" (354mm) dia.

18" (457mm) dia.

(25mm)

6706MS38U

Decorative, Discus, CFL, 1 Lt. 38W

Page 2 of 2

Philips Lightolier

e: [email protected]

t: (508) 679-8131

w: www.lightolier.com

6706MS38U May 31, 2011

Specifications are subject to change without notice.

Job Information Type:

Features

1. Diffuser: Acrylic, injection molded and bonded into one piece

assembly; 0.12" minimum thickness; 70% light transmission.

Lights evenly without discernible hot spots. Integral tabs

provide “twist-lock” installation; no loose hardware, no

tools required.

2. Housing: Polycarbonate, injection molded. Shatter resistant.

Integral bosses retain diffuser without loose hardware.

3. Ballast: Electronic; High power factor; Class P.

See Electrical/Ballast.

4. Lamp: 2D CFL by GE. GR10q-4 base

5. Lamp Socket: Polycarbonate, 4-Pin, GR10q-4 base.

6. Trim Ring: 16 gauge die formed aluminum.

Brushed aluminum finish

Mounting

Ceiling or wall (ADA compliant). Mounts to standard

4" outlet box.

Options

• Shatter resistant polycarbonate diffuser. Add TP to end of

catalog number.

+ Designates made to order only. Consult factory for lead times.

Electrical/Ballast

38W Lamp

120V 277V

Total Input Watts: 33 33

Max Line Current: .29 .13

Power Factor: >.98 >.98

Ballast Factor: .80 .80

THD: <10% <10%

Min. Starting Temp: 0ºF 0ºF

Labels

UL Listed. Suitable for damp locations.

ADA Compliant

9 ⅞" (251mm) dia.

8 ¼" (210mm) dia.

1 516"

(33mm)

(102mm)

13 1516" (354mm) dia.

18" (457mm) dia.

(25mm)
