ALTER SMARTVISION

2’ X 4’ RECESSED DIRECT/INDIRECT FLUORESCENT

2 LAMP, T8, 5 1/2” DEEP

MICROPERFORATED MESH LAMP SHIELD

STATIC

Efficiency 58.4%.

Broadcast 4: Broadcast control requires no programming of

the iGEN ballasts. Dimming message are sent with a global

address from the master Alter Smart Vision luminaire

to up to 3 slaves luminaire with an iGEN address able

ballast (DA). Each ballast receives the same command and

responds unifomity.

Swing down microperforated lamp shield for easy

relamping and maintenance.

Lamp shield specially cut to accomodate Smart

Vision sensor.

Alter soft white film on inside of mesh conceals lamp

image providing balance between reflected and

direct light.

Fully recessed luminaire and lamp compartment.

95% Reflective Alter soft white paint finish.

Specular interior reflector.

One piece body for easy installation.

Easy access to ballast through lamp

compartment.

Fits standard T-Grid ceilings.

Optional acrylic drop-down visual element.

MOUNTING METHODS/FEATURES DIMENSIONS

FIXTURE TYPE

JOB INFORMATION:

VOLTS

L30-80

QVS2GPFOB232

Suited to standard exposed Slot T-grid ceilings

Ceiling compatibility

Suited to standard exposed T-grid ceilings

Swing down optical system for

easy relamping and maintenance

Microperforated mesh lamp shields

Genlyte Thomas Company

integrated motion and light sensor with

optional dimming infrared remote control

OB = One-piece lamp shield

with sensor

ORDERING INFORMATION Explanation of Catalogue Number Example: QVS2GPFOB232120DS

SPECIFICATIONS

MATERIALS: One piece chassis constructed from die formed

20 gauge cold rolled steel. Reflectors - 95% reflectance baked white

acrylic matte paint finish. Specular interior reflector. Soft white acrylic film

on inside of lamp shield conceals lamp image.

FINISH: Chassis exterior - phosphate undercoating, baked white acrylic

matte high reflectance paint finish.

ELECTRICAL: Rapid start HPF, thermally protected class “P” ballast (Bi-tube

type). If K.Os are within 3” of ballast use wire suitable for at least 90C.

LABELS: Listed by CSA, UL

QVS2GPFOB232

QVS

QUALITY

VISUAL

STATIC

FIXTURE

WIDTH

CEILING

TYPE

LAMP

SHIELD

LAMP

QUANTITY

LAMP/FIXTURE

LENGTH

120

VOLTAGE

120V

OPTIONS

Standard exposed

T-grid ceilings

(NOMINAL 24”)

32 = 32W T8

R =Radio Interface Filter

O =Emergency Lighting

System (for Canada)

N =Emergency Lighting

System (for U.S.)

Recessed direct

indirect soft light

optical system

PF =Micro-

perforated

BALLAST TYPE

LAMP SHIELD DETAILS

We reserve the right to change, materials and finish in any way that will not alter installed appearance or reduce function and performance.

ALTER SMARTVISION

2’ X 4’ RECESSED DIRECT/INDIRECT FLUORESCENT

OB 2 32

2’

DS = iGEN Broadcast 4 Sensor/ iGEN

ballast*

* For other voltage, consult your

Lightolier representative.

Genlyte Thomas Company

631 Airport Road, Fall River, MA 02720 - Tel. (508) 679-8131

C.F.I. Division of Canlyte, Inc.

525 Education Road, Cornwall, Ontario

Canada K6H 6C7 - (613) 938-6221
