Life Span TR800 Manual de usuario

Folding Treadmill

Owners Manual

For safe use and product knowledge, please

completely read this Product OWNERS MANUAL.

TR800 / TR1200i

v. 1.2

TR800 / TR1200i

Folding Treadmill

Welcome to LifeSpan

Congratulations in taking a step forward to increase your level of physical activity or add

variety to your current exercise program. Physical activity is now more than ever a necessity

to keep your body healthy and ﬁt. Whether your motivation is to Lose Weight, manage a

Chronic Disease like diabetes, train for a sporting event or just live a Healthy Lifestyle,

LifeSpan products can help you achieve your health and ﬁtness goals.

In this manual we have included exercise information that is speciﬁc to each of these 4 key

motivations for exercise. We also invite you to the LifeSpan Fitness website at

www.LifeSpanﬁtness.com where we include additional information and tools to help you

maintain your exercise program and achieve your health and ﬁtness goals.

ers who say they prefer to exercise in the comfort and privacy of their own homes. Each

Home series product is designed and manufactured to exceed your expectations for quality

and durability, simple assembly and ease of operation.

Please read this manual thoroughly before assembly and operation of your new LifeSpan

equipment. It includes information on proper operation, safety precautions, product assem-

bly and ongoing maintenance.

Remember that some types of service should only be performed by a qualiﬁed service techni-

cian. In the instance that service is required, please contact your authorized LifeSpan

retailer or log on to our website and select the Customer Support option. Complete the inform

tion requested and we will respond to your inquiry within 1 business day.

PCE Health and Fitness

PO Box 981316

Park City, Utah 84098-1316

Phone: 801.973.9993

Fax: 801.973.9923

www.lifespanﬁtness.com

Neither PCE Health and Fitness nor its representatives can accept responsibility for any

damages or injury incurred as a result of information presented in this manual except under

the terms of the product warranty.

Welcome

Limited Home Use Warranty

Important Safety Precautions

Assembly Instructions

Console Overview

Treadmill Operations

Innovative Features

Program Overview

Belt Lubrication and Treadmill Maintenance

Belt Tensioning and Alignment

Moving and Storage

Troubleshooting

Engineering Mode

Extended Warranty

Serial Number Information

Date and Time, Workout Time,

Calories, Step Count, Distance,

Heart Rate, Speed, Incline

Multi-Color LCD

Manual, Preset (17), User Set-up

(2), Heart Rate Control (2)

15 Rows by 20 Columns

Audio Center with in / out jacks

and integrated speakers

Grip Pulse with Receiver

(chest strap not included)

Workout Time, Calories,

Distance, Heart Rate, Speed,

Incline

Blue backlit LCD

Manual, Preset (17), User Set-up

(2), Heart Rate Control (2)

15 Rows by 20 Columns

Grip Pulse

TR1200i

TR800

.6 - 10

0 - 12

18” x 52”

2.0“ tapered

.75” Phenolic Deck with 8 Bumper

Suspension

1.75 HP Continuous Duty DC

Motor

650 lb. Max Lift Rating

275 lbs

67” L x 31” W x 54” H

.5 - 11

0 - 15

TR800 / TR1200i

Folding Treadmill

Motor

1 3

Speed Range

Incline Levels

Running Belt Size

Roller Size

Deck

Drive Motor

Lift Motor

Maximum User Weight

Dimensions

20” x 56”

2.5” tapered

1” Phenolic Deck with 8 Bumper

Suspension

2.5 HP Continuous Duty DC

Motor

800 lb. Max Lift Rating

300 lbs

71” L x 34” W x 54” H

TR800 and TR1200i Folding Treadmills

Treadmill

Motor:

TR800 TR1200i

Lifetime

3 Years

1 Year

and complete the form to request assistance,

or call 877-654-3837 x4 for a customer support agent.

The customer may be responsible to pay for the Service Technician’s travel time where travel in excess of

20 miles is required.

card received by

received

registration

TR800 / TR1200i

Folding Treadmill

this treadmill

To reduce the risk of electric shock, unplug the treadmill from the wall outlet when not in use,

before performing any maintenance, or before moving the treadmill.

Do not lean against or climb on the treadmill. Doing so may result in the treadmill tipping and

falling and could result in serious personal injury.

Do not hang or place items on the treadmill. Doing so could result in shifting the weight

balance of the treadmill causing it to tip over or fall causing serious personal injury.

Do not operate with the side rails removed.

Keep the treadmill on a solid surface, with the side rails and front a minimum of two feet from any

walls or furniture. Make sure that the area behind the treadmill remains completely clear during

use. A minimum of 4 feet of clearance is required for safety reasons.

Do not operate where aerosol spray products are being used or where oxygen is being administered.

Never place the power cord under carpeting or place any object on top of the cord, this may

Use this exercise product for its intended use as described in this Owner’s Manual. Do not use

attachments that are not recommended by PCE Heath and Fitness.

Do not leave your treadmill running while not in use.

treadmill at all times.

Grounding Instructions

Never use extension cords between the treadmill and the wall outlet.

This product is for use on a nominal 120 volt (non GFI) circuit, and has a grounding plug similar to

the illustration below. Never remove or otherwise bypass the eletrical ground terminal.

Gounded Wall Outlets

Treadmill

Plug

Gounded

Socket

Danger: Improper connection of the equipment

grounding conductor can result in the risk of

or service person if you are in doubt as to whether

the product is properly grounded. Do not modify

in the outlet, have the proper outlet installed by a

Note: Read all instructions and save for future use.

Do not wear clothing or jewelry that might catch on any part of the treadmill.

This treadmill is equipped with a safety key. If the key is removed from the display, the treadmill will

immediately stop. Always clip the cord that is attached to the safety key to a part of your clothing so

the key will be pulled from the display, stopping the treadmill, in case of an emergency.

treadmill

Item# description

1 Main Frame

5 Console

6 Accessory Tray

7 Back cover

9 Left handrail cover-outer

10 Right handrail cover-outer

11 Left handrail cover-inner

12 Right handrail cover-inner

13 Base cover-Left

14 Base cover-Right

15 Safety bar cover

Wrench-17mm

Wrench-5mm

Wrench-6mm M4*10L (4pcs)

M8*70L (2pcs)

Wrench-13mm

Tools and Screws included in Hardware Bag 9

Left handlebar support

Right handlebar support

Handlebar

25 Console housing

Plate console housing

frame mount

TR800 / TR1200i

Folding Treadmill

Step 2: Handlebar Support Post Assembly

A. Remove the screw (A) and nut (E) that are pre-assembled on the frame from each side of the

base using the 6 mm Allen wrench and 17 mm open end wrench provided in your tool kit.

These two screws will prevent the handlebars from rotating up into their upright position.

B. Stand the support posts and handlebars up into their operating position and re-attach the

screws (A) and nuts (E) removed in step 2A.Tighten securely.

C. Attach the left (13) and right (14) base covers using a Phillips screwdriver and 2 machine screws (G)

on each side. The 4 base cover attaching screws are located in the hardware bag.

Step 1: Unpacking Treadmill

Cut packaging straps and remove.

Remove the box top.

C. Remove small parts and packaging material and unwrap parts.

Cut corners of the bottom box and remove all packaging material to begin assembly. The

treadmill can be assembled in the box. No need to pick the treadmill up to remove it from box.
