Life Span STYLE Manual de usuario

Product may vary slightly from the item pictured due to model upgrades

Read all instructions carefully before using this product. Retain this owner’s manual for

future reference.

STYLE OWNER’S MANUAL

STYLE

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS 3

2. IMPORTANT ELECTRICAL INFORMATION 4

3. IMPORTANT OPERATING INSTRUCTIONS 5

4. ASSEMBLY INSTRUCTIONS 6

5. FOLDING INSTRUCTIONS 9

6. GROUNDING METHODS 10

7. OPERATION GUIDE 11

8. EXERCISE GUIDE 16

9. MAINTENANCE INSTRUCTIONS 18

10. EXPLODED DIAGRAM 22

11. PARTS LIST 23

12. TROUBLE SHOOTING GUIDE 25

13. WARRANTY REGISTRATION 27

STYLE

1. IMPORTANT SAFETY INSTRUCTIONS

WARNING - Read all instructions before using this treadmill.

It is important your treadmill receives regular maintenance to prolong its useful life. Failing to

regularly maintain your treadmill may void your warranty.

Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to

cleaning and/or service work.

DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY

USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.

Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.

Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and

treadmill may result.

Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of

the treadmill and any fixed object.

Place your unit on a solid, level surface when in use

Never allow children on or near the treadmill.

When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should

you fall or move too far back on the treadmill.

Keep hands away from all moving parts.

Never operate the treadmill if it has a damaged cord or plug.

Keep the cord away from heated surfaces.

Do not operate where aerosol spray products are being used or where oxygen is being administered.

Sparks from the motor may ignite a highly gaseous environment.

Never drop or insert any object into any openings.

The treadmill is intended for in-home use only and not suitable for long time running.

STYLE

To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug

from the outlet.

The pulse sensors are not medical devices. Various factors, including the user’s movement, may

affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in

determining heart rate trends in general.

Use the handrails provided; they are for your safety.

Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your

treadmill. Quality athletic shoes are recommended to avoid leg fatigue.

Allowed temperature: 5 to 40 degrees.

Remove the safety key after use to prevent unauthorized treadmill operation.

2. IMPORTANT ELECTRICAL INFORMATION

WARNING!

NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power

cord away from any moving part of the treadmill including the elevation mechanism and transport

wheels.

NEVER remove any cover without first disconnecting AC power.

NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,

near a pool, or in any other high humidity environment.

STYLE

3. IMPORTANT OPERATING INSTRUCTIONS

Be sure to read the entire manual before operating your machine.

Understand that changes in speed and incline do not occur immediately. Set your desired speed on

the computer console and release the adjustment key. The computer will obey the command

gradually.

Use caution while participating in other activities while walking on your treadmill, such as watching

television, reading, etc. These distractions may cause you to lose balance or stray from walking in

the centre of the belt; which may result in serious injury.

In order to prevent losing balance and suffering unexpected injury, NEVER mount or dismount the

treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the

belt during slow acceleration is proper after you have learned to operate this machine.

Always hold on to handrail while making control changes.

A safety key is provided with this machine. Remove the safety key will stop the walking belt

immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.

Do not use excessive pressure on console control keys. They are precision set to function properly

with little finger pressure.

STYLE

4. ASSEMBLY INSTRUCTIONS

PART LIST

NO.

Description

Specification

Qty.

NO.

Description

Specification

Qty.

main frame

Lock washer

lock washer

S=13, 14, 15

5# Allen Wrench

5mm

Bolt

M8*16

Screw

ST4.2*12

Left handle bar cover L

Left handlebar cover R

Right handle bar cover L

Right handlebar cover R

STYLE

STEP 1:

STEP 2:

STEP 3:

1. Open the carton

2. Extract the parts listed above

3. Place the Main Frame (1) onto level

ground

1. Using the 5# Allen wrench, screw through

the bolt (46) to Lock washer (66), then

lock the Left upright (3) onto MAIN

FRAME (1)

Note: Support the Uprights with your hands to

prevent them falling down and causing injury.

1. Raise the Computer and Upright tubes in

the direction of the arrows.

Note: Whilst erecting the uprights, make sure the

upright does not press against and damage the

wires inside the upright tubes. Keep holding the

upright and computer by hand so they do not fall

down and cause injury

STYLE

STEP 4:

STEP 5:

STEP 6:

1. Using the 5# Allen wrench, screw through

the bolt (46) to Lock washer(66), then lock

the Right upright (4) onto MAIN FRAME (1)

Note: Support the Computer with your hands to

prevent it falling down and causing injury.

1. Use the 5# Allen wrench, screw through the

bolt (46) to Lock washer (66), then lock the

COMPUTER (64) onto R&L upright (3,4).

1. With ST4.2*12 Screw (59), insert the

UPRIGHT COVER (25, 32, 40, 41)onto

the L&R handle bar.

STYLE

5. FOLDING INSTRUCTIONS

Folding:

Unfolding:

Support position A with your hand, then pull

up the running board following the arrow

direction until you hear a clicking sound of

the cylinder (10) locking into the round

tube.

Support position A with your hand ,

depress position B of the air pressure

control bar, then the base frame will

descend automatically

STYLE

6. GROUNDING METHODS

This product must be grounded. In the event of malfunction or breakdown, grounding reduces the

risk of electric shock. This product is equipped with a cord with an equipment-grounding conductor

and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed

and grounded in accordance with all local codes and ordinances.

DANGER

Improper connection of the equipment-grounding conductor can result in risk of electric shock.

Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly

grounded.

Do not modify the plug provided with the product –if it will not fit the outlet; have a proper outlet installed by

a qualified electrician.

This product is for use on a nominal 240-volt circuit and has a grounding plug that looks like the plug

illustrated in sketch A in following figure. Ensure the product is connected to an outlet having the same

configuration as the plug. No adapter should be used with this product.
