Life Span Power Manual de usuario

POWER

USER’S

MANUAL

This is HIGH-POWER item; please DO NOT USE THE SAME OUTLET WITH OTHER

HIGH-POWER HOUSEHOLD APPLIANCE like air-conditioning etc.

Please choose an outlet exclusively for the machine and make sure the fuse is 10A.

Special tips:

1. Before installation and operation, please read this operation manual carefully.

2. Please save this manual for future reference.

3. Product may vary slightly from the item pictured due to model upgrades

http://www.lifespanfitness.com.au/

Table of Contents

1. Brief Description...........................................- 2 -

2. Main Technical Features ..................................- 2 -

3. Tips for Safety .............................................- 3 -

4. Installation: See “Installation sketch” .................- 4 -

5. Use and Operation ........................................- 4 -

6. Maintenance................................................- 8 -

7. Guides for malfunction .................................- 12 -

8. Warranty ..................................................- 13 -

9. Error and self-inspection ...............................- 14 -

10. Warranty Registration .................................- 17 -

- 1 -

1. Brief Description

power Treadmill (diagram 1) can help complete your goal of keeping fit together

with unique and elegant appearance. Easily read panel parameter. Easily

operated folding system realizes space-saving. Auto speed range 1-20km/h and

auto incline range1-20. All makes it hot home use fitness equipment.

Heart rate senso

Meter accessories Handle

Power switch Pillar accessories

Running belt

Footplate

Running belt adjustor

Pillar accessories

Safety key

Diagram 1: power Treadmill

2. Main Technical Features

Main use: Body and beauty building

This treadmill is for home use

Panel displays speed, time, distance, heart rate, calorie, MP3, body fat, etc.

Display Mode：LCD

Input voltage: 240V±10%

Frequency: 50HZ

Input current: ≤8A

Speed range: 1∽20km/h

Auto incline: 0-20 Levels

Time display range: 0:00∽99:59(minute: second)

Distance display range: 0.1~9.99kms

- 2 -

3. Tips for Safety

1) Insert the power plug into the socket directly. Current load should be less

than 10A

2) The constant running time is less than 2 hours, max weight is about

130kgs.

3) Place your treadmill on the clean floor，not on the thick carpet; otherwise

it will not be convenient for ventilation. Also please do not put the treadmill

in the moist place or outdoors; If there is something wrong with the

electrical wire, please replace it with the electrical wire provided by our

company. For the replacement, please contact with the local distributor.

4) The treadmill should be placed in the convenient position for electric

socket.

5) The freshman should grip the handrails when jogging and running until

familiarly. Please don’t stand on the running belt, after the machine is

power on (the safe key is at the appointed position).Please stand on the

footplates besides the treadmill, press the “start” button, it runs at the

lowest speed, at this time you can run on the belt.

6) While running, you should dress properly. Do not dress too loosely in case

your clothes are entangled by the machine .And please wear sport shoes

with soft sole.

7) Before taking down the protecting cover of the treadmill, please keep the

machine power off.

8) Don’t let children get close to the running treadmill to avoid unnecessary

injury.

9) Please make sure one end of the safe key has been placed in the appointed

position and the other end has been nipped to your clothes when you are

running on the machine. In this way, you can pull the safe key to stop the

machine immediately under the dangerous condition. Then you will not be

injured.

10)If you are enjoying other entertainment while running such as watching

TV, reading. Please be particularly careful. These activities will distract

your attention, which may make you lose your balance and get hurt.

11)Please pull the plug off from socket and keep the safe key when the

treadmill is unused.

12)Please don’t put anything under treadmill and don’t let your children play

near it after folding.

13)Please consult your doctor at first before running, if you have one of the

following diseases:

a) Cardiopathy, hypertension, sugar diabetes, respiratory disease,

smoking, and other chronic diseases, complication disease.

b) If you are over 35 years old and heavier than common weight.

c) Women in pregnant or in breasting period.

14)Please stop exercising immediately and consult your doctor when you feel

giddy, surfeit, thorax ache or other symptoms.

- 3 -

15)Please drink adequate water after taking exercises on our treadmill for

more than 20 minutes.

4. Installation: See “Installation sketch”

5. Use and Operation

5.1 Panel Keys and Function

（10）speed-down

（11）speed-up

（3）speed shortcut key

（9）safety key

（8）clear/set

（12）profile

（13）music

（2）on/off

（1）incline shortcut key

（15）LCD window

（4）incline-up

（5）incline-down

（7）body fat

（14）Mode

（6）select

（1）“incline short cut key”

Press this key, the incline goes directly to the chosen height.

- 4 -

（2）“on/off”

Under ready condition, press this key, it runs at the speed of 1.0km/h.

Under running condition, if it runs at speed more than 3.5km/h, it will slow

down then stop. During this stopping process, other keys are not available.

If it runs at speed less than

3km/h, then it stops immediately.

（3）“speed short cut key”

Under running condition, press this key, speed can be set to the value

directly.

（4）“incline up”

Press this key, you can choose the incline you need, except for the alarm

condition.

（5）“incline down”

Press this key, you can choose the incline you need, except for the alarm

condition.

（6）“select”

Under ready condition, press this key to enter “distance running” mode, it

has four kinds, U1~U4, under this mode, the treadmill will record your

total running distance automatically (minimum unit is 500m). And you also

can record it by press “clear/set” key after stop the treadmill, its minimum

unit is 100m. The records will remain after you shut off the power supply.

（7）“body fat”

Under ready condition, press this key to evaluate your body fat.

Press once, it will show SEX, press “speed up” and “speed down” key to

select.

Press this key again, it will show AGE, press “speed up” and “speed down”

key to select your age. (From 10~99years)

Press this key again, it will show HEIGHT, press “speed up” and “speed

down” key to select your height. (From 50~250cm)

Press this key again, it will show WEIGHT, press “speed up” and “speed

down” key to select your weight. (From 20~200KGS)

Then press “enter” key to get your Bodyfat.

Explanation:

Body fat < 19: too thin.

Body fat 19~25: normal

Body fat 26~30: overweight

Body fat > 30: fat

（8）“clear/set”

Under ready condition, press this key once, it will clear all the operation.

Under ready condition, press this key for 3 seconds continuously, time,

distance and calorie can be set. Press “speed-up” or “speed-down” keys,

time, distance and calorie can be set. Then press “on/off” key, the machine

will run at 1.0km/h. And the set figures will be counted down, when it

comes to “0”, machine stops. Under running situation, press “reset/set”, all

- 5 -

the figures will be kept to “0” except for speed. Then manual model comes.

（9）“safety key”

Under urgent condition, pull this key, machine stops immediately.

（10）“speed down”

Under running condition, press this key, speed can be speeded down to the

one you need.

（11）“speed up”

Under running condition, press this key, speed can be speeded up to the

one you

need.

（12）“profile”

Under ready condition, press this key to enter own programs mode, you

have 3 own programs, C1~C3, please set your programs at first.

Select the program at first, then press “clear/set” key to edit it.

Press “speed up” and “speed down” key to select the speed you want, from

1~16km/h, then press “profile” to set the speed of next minute. After set all

the speeds for 16minutes, you may press “start/stop” key to run your

program.

（13）“music”

Press this key to open or shut the speaker amplify.

（14）“Mode”

Under ready condition, press this key to choose running program. There is

P1-P99, 99 programs in total.

（15）LCD window

a. “incline”: It shows auto incline (range: 0-20 Levels)

b. “distance”: It shows the distance (range: 0 km-9.99km)

c. “time”: It shows time（range:00:00 -99:99）

d. “speed”: It shows speed (range: 1km/h-20km/h）

e. “cal/pulse”: It shows the pulse when it has, if without pulse, it shows

calorie (range: 0-999 calorie）

f. : It will be displayed when MP3 function is in use.

5.2 Unload operating

a. Insert power plug into the socket with earth wire, turn the switch to “1”

position which is on the frame

b. Put the safe key in the right position, then circuit is on, press “on/off”, keep it

- 6 -

run in unload condition. Test the condition of running belt (testing from low

speed to high ones), after testing, press “on/off”.

c. If everything is ok, then start to run.

5.3 Meter operating instruction

5.3.1

a. Insert power plug into the socket with earth wire, turn the switch to “1”

position which is on the frame. Place the safety key to the appointed position.

After a few seconds, panel will show that the machine is ready.

b. Nip another end of safe key to your clothes, and stand on the footplate on both

sides.

c. Press“on/off” key, running belt moves at the lowest speed (1.0km/h). Speed

windows will display your running speed.

d. Start to run.

e. Press speed key or incline key to adjust speed and incline, speed window and

incline window will display your speed and incline .

f. To end your exercise in a safe way, please first press “on/off” key to close the

treadmill. Please do not leave the running belt until it stops slowly. Turn off the

power.

5.3.2 Heart Rate Testing

Our treadmill can test your heart rate via the heart rate sensor. The data is only

for reference.

5.4 Folding and Opening Treadmill

5.4.1 Folding

Firstly lift and fold the back part of the frame board by hand till you hear a light

sound, which means the folding system has been locked. At this time running

board can’t be turned to the opposite direction

5.4.2 Opening

Put the folded treadmill in a capacious position when you want do exercise. Then

pull the adjusting parts by hand to keep it unlocked. Press the back part by your

hands down to about 10%, release it, then it will open automatically.

- 7 -

6. Maintenance

Reasonable cleaning/lubricating should be made to extend the life time of this

unit. Performance is maximized when the belt and mat are kept as clean as

possible.

WARNING: THE MAT/DECK FRICTION MAY PLAY A MAJOR ROLE IN THE FUNCTION

AND LIFE OF YOUR TREADMILL AND THAT IS WHY WE RECOMMEND YOU CONSTANTLY

LUBRICATE THIS FRICTION POINT TO PROLONG THE USEFUL LIFE OF YOUR

TREADMILL. FAILING TO DO THIS MAY VOID YOUR WARRANTY.

WARNING: UNPLUG POWER CORD BEFORE MAINTENANCE.

WARNING: STOP TREADMILL BEFORE FOLDING.

6.1 Maintenance and servicing

AFTER EACH USE (DAILY)

Clean and inspect, following these steps:

• Turn off the treadmill with the on/off switch, then unplug the power cord at the

wall outlet.

• Wipe down the running belt, deck, motor cover, and console casing with a damp

cloth. Never use solvents, as they can cause damage to the treadmill.

• Inspect the power cord. If the power cord is damaged, contact Lifespan Fitness.

• Make sure the power cord is not underneath the treadmill or in any other area

where it can become pinched or cut.

• Check the tension and alignment of the running belt. Make sure that the

treadmill belt will not damage any other components on the treadmill by being

misaligned.

EVERY WEEK

Clean underneath the treadmill, following these steps:

• Turn off the treadmill with the on/off switch, then unplug the power cord at the

wall outlet.

• Fold the treadmill into the upright position, making sure that the lock latch is

secure.

• Move the treadmill to a remote location.

• Wipe or vacuum any dust particles or other objects that may have accumulated

underneath the treadmill.

• Return the treadmill to its previous position.

- 8 -

EVERY MONTH -IMPORTANT!

• Inspect all assembly bolts of the machine for proper tightness.

• Turn off the treadmill with the on/off switch, then unplug the power cord and wait 60 seconds.

• Remove the motor cover. Wait until ALL LED lights turn off.

• Clean the motor and lower board area to eliminate any lint or dust particles that may have

accumulated. Failure to do so may result in premature failure of key electrical components.

EVERY 6 MONTHS

It may be necessary to lubricate your treadmill running deck at least once every

six months to maintain optimal performance of your treadmill (refer to section

4.4 for information). Only use lubricant provided by Lifespan Fitness! Please

contact Lifespan Fitness with questions about applying lubricant to your

treadmill.

• Turn off the treadmill with the on/off switch, and then unplug the power cord at

the wall outlet.

• Loosen both the rear roller bolts. (For best results, place two removable marks

on both sides of the frame and note roller position).Once the belt is loosened,

take the bottle of lubricant and apply it to the entire top surface of the running

deck. Tighten both rear roller bolts (matching up the marks for proper position)

to original position. After you have applied lubricant, plug in the power cord, key,

start the treadmill and walk on the belt for two minutes to spread the lubricant.

• Lubricate the air shocks with Teflon based spray.

EVERY 2 YEARS

It is necessary that you change your treadmill motor brushes once every 2 years

to avoid damaging your motor. If you fail to change the brushes this may cause

the motor to burn out, voiding any warranty.

SERVICING: IF YOU FAIL TO COMPLY WITH LIFESPAN’S MAINTENANCE AND

SERVICING STEPS ABOVE, YOU MAY VOID YOUR WARRANTY. IF YOU REQUIRE A

SKILLED LIFESPAN REPRESENTATIVE TO UNDERTAKE ONE OF THE STEPS ABOVE,

PLEASE EMAIL US AT [email protected].

6.2 General Cleaning

Use a soft, damp cloth to wipe the edge of the belt and the area between

the belt edge and frame. A mild soap and water solution along with a nylon

scrub brush will clean the top of the textured belt. This task should be done

once a month. Allow to dry before using.

- 9 -

Tabla de contenidos

Otros manuales de Rueda de andar de Life Span

Life Span

Life Span TR7000i Manual de usuario

Life Span

Life Span TORQUE II Manual de usuario

Life Span

Life Span BOOMER Manual de usuario

Life Span

Life Span Pursuit Max Treadmill Manual de usuario

Life Span

Life Span entertainer Manual de usuario

Life Span

Life Span BOOST Manual de usuario

Life Span

Life Span Traction II Manual de usuario

Life Span

Life Span M3 Manual de usuario

Life Span

Life Span TR800-DT Manual de usuario

Life Span

Life Span Echo Manual de usuario

Life Span

Life Span PRO 1 Manual de usuario

Life Span

Life Span Pursuit 3 Manual de usuario

Life Span

Life Span Walkstation L1 Manual de usuario

Life Span

Life Span CORSAIR FREERUN 100 Manual de usuario

Life Span

Life Span Relay Manual de usuario

Life Span

Life Span PRO Series Manual de usuario

Life Span

Life Span TR2000i Touch Manual de usuario

Life Span

Life Span GOLD Manual de usuario

Life Span

Life Span TR1200i Manual de usuario

Life Span

Life Span BOOST-R Manual de usuario

Life Span

Life Span TR2000e Manual de usuario

Life Span

Life Span Jazz Manual de usuario

Life Span

Life Span PRO Series Manual de usuario

Life Span

Life Span Workplace DT-5 Manual de usuario

Manuales populares de Rueda de andar de otras marcas

Treadly

Treadly TREADLY 2 Manual de usuario

HEALTH ONE

HEALTH ONE Walk Ro Manual de usuario

NordicTrack

NordicTrack NTL12941 Manual de usuario

NordicTrack

NordicTrack T7.5 S Manual de usuario

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manual de usuario

Merax

Merax MS282992 Manual de usuario

FYTTER

FYTTER RU-2SX Manual de usuario

Precor

Precor 903 Manual de usuario

FitLogic

FitLogic freewill d225 Manual de usuario

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manual de usuario

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manual de usuario

Stamia

Stamia InMotion II Manual de usuario

Smooth Fitness

Smooth Fitness EVO 3i Manual de usuario

NordicTrack

NordicTrack NETL81810.0 Manual de usuario

Schwinn

Schwinn 830/Journey 8.0 Manual de usuario

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manual de usuario

Spirit

Spirit XT8 Manual de usuario

NordicTrack

NordicTrack T 14.0 Treadmill Manual de usuario
