LG M1994D Manual de usuario

Please read this manual carefully before operating

your set.

Retain it for future reference.

Record model number and serial number of the set.

See the label attached on the back cover and quote

this information to your dealer when you require

service.

OWNER’S MANUAL

MM119999DD

MM220099DD

MM222299DD

Trade Mark of the DVB Digital Video

Broadcasting Project (1991 to 1996)

IIDD NNuummbbeerr((ss))::5573 : M199 D

557 : M209 D

5575 : M229 D

PREPARATION

FRONT PANEL CONTROLS

■

This is a simplified representation of the front panel. The image shown may be somewhat different from your

set.

INPUT MENU VOL PROK

PROGRAMME

Buttons

VOLUME

Buttons

Button

INPUT

Button

INPUT

Button

AA TTyyppeeBB TTyyppee

Power

Button

Hea phone

Button

INPUT MENU VOL PROK

PROGRAMME

Buttons

VOLUME

Buttons

Button

INPUT

Button

Power

Button

Hea phone

Button

PREPARATION

BACK PANEL INFORMATION

PCMCIA (Personal Computer Memory Car

International Association) Car Slot

(This feature is not available in all countries.)

Power Cor Socket

This set operates on AC power. The voltage is in icat-

e on the Specifications page. Never attempt to

operate the set on DC power.

HDMI Input

Connect a HDMI signal to HDMI IN.

Or DVI (VIDEO) signal to HDMI IN with DVI to HDMI

cable.

RGB/DVI Au io Input

Connect the au io from a PC.

Optical Digital Au io Out

Connect igital au io from various types of eguip-

ment

RGB INPUT (PC)

Connect the output from a PC.

SERVICE ONLY PORT

DVI-D Input

Connect the output from a PC.

RS-232C IN (CONTROL & SERVICE) PORT

Connect to the RS-232C port on a PC.

Component Input

Connect a component vi eo/au io evice to these

jacks.

Euro Scart Socket (AV1/AV2)

Connect scart socket input or output from an exter-

nal evice to these jacks.

Antenna Input

Connect over-the-air signals to this jack.

■

This is a simplified representation of the back panel. The image shown may be somewhat different from your

set.

AV 1 AV 2

AC IN

AUDIO IN

(RGB/DVI) OPTICAL

DIGITAL

AUDIO OUT

VIDEO

COMPONENT

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D

HDMI

AV 1

V 1

AV 2

V 2

ANTENNA IN

AC IN

910

87 1211

64 5

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefully place the product screen side down on a

cushioned surface that will protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw handle

Screw

PREPARATION

DETACHING STAND

Place the set screen side down on a cushion or

soft cloth.

Detach the monitor to the Stand Base by turn-

ing the screw to the left.

Turn the screw by using the screw handle 4

Pull the stand base.

■

The image shown may be somewhat different from your set.

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inches on each si e an from the wall.

4 inches

PREPARATION

POSITIONING YOUR DISPLAY

■

The image shown may be somewhat different from your set.

Adjust the position of the panel in various ays for maximum comfort.

•• TTiilltt rraannggee

LOCATION

Position your set so that no bright light or sunlight falls directly onto the screen. Care should be taken

not to expose the set to any unnecessary vibration, moisture, dust or heat. Also, ensure that the set is

placed in a position to allo a free flo of air. Do not cover the ventilation openings on the back cover.

-5

~ -2

~ 18

WWaarrnniinngg::

When adjusting the angle of the screen,do not put your

finger(s)in bet een the head of the monitor and the stand

body.You can hurt your finger(s).

PREPARATION

KENSINGTON SECURITY SYSTEM

- The pro uct is equippe with a Kensington Security System connector on the back panel. Connect the

Kensington Security System cable as shown below.

- For etaile installation an use of the Kensington Security System, refer to the user’s gui e provi e with

the Kensington Security System.

For further information, contact hhttttpp::////wwwwww..kkeennssiinnggttoonn..ccoomm, the internet homepage of the

Kensington company. Kensington sells security systems for expensive electronic equipment such as note-

book PCs an LCD projectors.

NOTE

- The Kensington Security System is an optional accessory.

NOTES

a. If the pro uct feels col to the touch, there may be a small “flicker” when it is turne on.

This is normal, there is nothing wrong with pro uct.

b. Some minute ot efects may be visible on the screen, appearing as tiny re , green, or blue spots.

However, they have no a verse effect on the monitor's performance.

c. Avoi touching the LCD screen or hol ing your finger(s) against it for long perio s of time.

Doing so may pro uce some temporary istortion effects on the screen.

PREPARATION

AV 3

L/MONO

AUDIO

VIDEO

S-VIDEO

AUDIO

VIDEO

AV 1 AV 2

ANTENNA

EJECT

HDMI/DVI IN 1 HDMI IN 2

PCMCIA

CARD SLOT

RS-232C IN

AV 3

L/MONO

AUDIO

VIDEO

S-VIDEO

AUDIO

VIDEO

AV 1 AV 2

ANTENNA

EJECT

HDMI/DVI IN 1 HDMI IN 2

PCMCIA

CARD SLOT

RS-232C IN

■For optimum picture quality, adjust antenna direction.

■An antenna cable and converter are not supplied.

■To prevent equipment damage, never plug in any power cords until you have finished connecting all equipment.

Multi-famil Dwellings/Apartments

(Connect to wall antenna socket)

Single-famil Dwellings /Houses

(Connect to wall jack for outdoor antenna)

Out oor

Antenna

(VHF, UHF)

Wall

Antenna

Socket

RF Coaxial Wire (75 ohm)

ANTENNA CONNECTION

Antenna

UHF

Signal

Amplifier

VHF

■In poor signal areas, to get better picture quality, install a signal amplifier to the antenna as shown above.

■If signal needs to be split for two TVs, use an antenna signal splitter for connection.

EXTERNAL EQUIPMENT SETUP

Connect the SET-TOP outputs to the CCOOMMPPOONNEENNTT IINN

VVIIDDEEOOsockets (YP

BPR) on the set.

Connect the audio cable from the SET-TOP to CCOOMMPPOO--

NNEENNTT IINNAAUUDDIIOOsockets of the set.

Press the IINNPPUUTTbutton to select Component.

HD RECEIVER SETUP

■To prevent the equipment amage, never plug in any power cor s until you have finishe connecting all equipment.

■

The image shown may be somewhat ifferent from your set.

When connecting with a component cable

Signal

80i/576i

80p/576p

720p/1080i

1080p

Component

Yes

HDMI

Yes

VIDEO

COMPONENT

AUDIO
